Queclink GV35 Manual de usuario

GV35 User manual

TRACGV35UM001

GPS Locator GV35

User Manual

TRACGV35UM001

Revision: 1.00

http://www.queclink.com

[email protected]

GV35 User manual

TRACGV35UM001 - 2 -

Document Title GV35 User Manual

Version 1.00

Date 2012-05-17

Status Release

Document Control ID TRACGV35UM001

General Notes

Queclink offers this information as a service to its customers, to support application and

engineering efforts that use the products designed by Queclink. The information provided

is based upon requirements specifically provided to Queclink by the customers. Queclink

has not undertaken any independent search for additional relevant information, including

any information that may be in the customer’s possession. Furthermore, system validation

of this product designed by Queclink within a larger electronic system remains the

responsibility of the customer or the customer’s system integrator. All specifications

supplied herein are subject to change.

This device complies with part 15B, part 22 and part 24 of the FCC rules. Operation is

subject to the following two conditions: (1) this device may not cause harmful interference

(2) this device must accept any interference, including interference that may cause

undesired operation.

WARNING:

Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Users must maintain a separation distance of at least 20cm from the EUT to satisfy RF

exposure compliance.

This document contains proprietary technical information which is the property of Queclink

Limited., copying of this document and giving it to others and the using or communication

of the contents thereof, are forbidden without express authority. Offenders are liable to the

registration of a utility model or design. All specification supplied herein are subject to

change without notice at any time.

GV35 User manual

TRACGV35UM001 - 3 -

Contents

1. Introduction...................................................................................................................................7

1.1. Reference.............................................................................................................................7

1.2. Terms and Abbreviations.....................................................................................................7

2. Product Overview .........................................................................................................................8

2.1. Check Part List....................................................................................................................8

2.2. Parts List..............................................................................................................................9

2.3. Interface Definition.............................................................................................................9

3. Getting Started ............................................................................................................................11

3.1. Opening the Case ..............................................................................................................11

3.2. Closing the Case................................................................................................................11

3.3. Installing a SIM Card........................................................................................................12

3.4. Power Connection.............................................................................................................12

3.5. Ignition Detection..............................................................................................................13

3.6. Digital Input......................................................................................................................13

3.7. Digital Output....................................................................................................................14

3.8. Relay .................................................................................................................................15

3.9. Device Status LED............................................................................................................16

GV35 User manual

TRACGV35UM001 - 4 -

Table Index

TABLE 1: GV35 PROTOCOL REFERENCE.........................................................................................7

TABLE 2: TERMS AND ABBREVIATIONS .........................................................................................7

TABLE 3: PART LIST .............................................................................................................................9

TABLE 4: DESCRIPTION OF 6 PIN CONNECTIONS.......................................................................10

TABLE 5: ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION.................................13

TABLE 6: ELECTRICAL CHARACTERISTICS OF THE DIGITAL INPUT.....................................13

TABLE 7: ELECTRICAL CHARACTERISTICS OF DDIGITAL OUTPUT.......................................15

TABLE 8: ELECTRICAL CHARACTERISTICS OF RELAY.............................................................15

TABLE 9: DEFINITION OF DEVICE STATUS AND LED.................................................................17

GV35 User manual

TRACGV35UM001 - 5 -

Figure Index

FIGURE 1. APPEARANCE OF GV35..............................................................................................8

FIGURE 2. THE 6 PIN CONNECTOR ON THE GV35..................................................................10

FIGURE 3. OPENING THE CASE..................................................................................................11

FIGURE 4. CLOSING THE CASE..................................................................................................11

FIGURE 5. SIM CARD INSTALLATION.......................................................................................12

FIGURE 6. TYPICAL POWER CONNECTION.............................................................................12

FIGURE 7. TYPICAL IGNITION DETECTION............................................................................13

FIGURE 8. TYPICAL DIGITAL INPUT CONNECTION..............................................................14

FIGURE 9. DIGITAL OUTPUT INTERNAL DRIVE CIRCUIT....................................................14

FIGURE 10. TYPICAL CONNECTION WITH LED .......................................................................15

FIGURE 11. TYPICAL CONNECTION WITH RELAY ..................................................................16

FIGURE 12. GV35 LED ON THE CASE..........................................................................................16

GV35 User manual

TRACGV35UM001 - 6 -

Revision History

Revision Date Author Description of change

1.00 2012-5-17 Cid Xu Initial

GV35 User manual

TRACGV35UM001

1. Introduction

The GV35 is a powerful GPS locator designed for vehicle or asset tracking. It has superior

receiver sensitivity, fast TTFF (Time to First Fix) and supports Quad-Band GSM

frequencies 850/900/1800/1900, its location can be monitored in real time or be

periodically tracked by a backend server or other specified terminals. The GV35 has

multiple input/output interfaces that can be used for monitoring or controlling external

devices. Based on the integrated @Track protocol, the GV35 can communicate with a

backend server through the GPRS/GSM network to transfer reports of Emergency,

geo-fence boundary crossings, low backup battery or scheduled GPS position as well as

many other useful functions. Users can also use GV35 to monitor the status of a vehicle

and control the vehicle by its internal relay output. System Integrators can easily setup

their tracking systems based on the full-featured @Track protocol.

1.1. Reference

Table 1: GV35 Protocol Reference

SN Document name Remark

[1] GV35 @Track Air Interface Protocol The air protocol interface between

GV35 and backend server.

1.2. Terms and Abbreviations

Table 2: Terms and Abbreviations

Abbreviation Description

GND Ground

NC Not Connected

IN1 Input Port

PWR External DC power input

OUT1 Output Port

IGN Ignition input

GV35 User manual

TRACGV35UM001

2. Product Overview

2.1. Check Part List

Before starting, check all the following items have been included with your GV35. If

anything is missing, please contact your supplier.

Figure 1. Appearance of GV35

GV35 User manual

TRACGV35UM001 - 9 -

2.2. Parts List

Table 3: Part List

2.3. Interface Definition

The GV35 has a 6 PIN interface connector. It contains the connections for power and I/O.

The sequence and definition of the 6PIN connector are shown in following figure:

Name Picture

GV35 Locator 74*49.5*24 mm

User Cable

Relay Inserted spring

Relay Inserted spring Protective sleeve

GV35 User manual

TRACGV35UM001 - 10 -

Figure 2. The 6 PIN connector on the GV35

Table 4: Description of 6 PIN Connections

Index Description Comment

1 GND Ground

2 NC

3 IN1 Digital input, negative trigger

4 PWR External DC power input, 9-16V

5 OUT1 Open drain output signal(max drive current is 150mA)

6 IGN Ignition input, positive trigger
