Queclink GL100M Manual de usuario

GPS Locator GL100M

User Manual

TRACGL100MUM001

Revision: 1.00

http://www.queclink.com

[email protected]

GL100M User manual

TRACGL100MUM001 -1-

Document Title GL100M User Manual

Version 1.00

Date 2011-09-16

Status Release

Document Control ID TRACGL100MUM001

General Notes

Queclink offers this information as a service to its customers, to support application and

engineering efforts that use the products designed by Queclink. The information provided is

based upon requirements specifically provided to Queclink by the customers. Queclink has

not undertaken any independent search for additional relevant information, including any

information that may be in the customer’s possession. Furthermore, system validation of this

product designed by Queclink within a larger electronic system remains the responsibility of

the customer or the customer’s system integrator. All specifications supplied herein are

subject to change.

This device complies with part 15B, of the FCC rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference (2) this device must

accept any interference, including interference that may cause undesired operation.

WARNING:

Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

This document contains proprietary technical information which is the property of Queclink

Limited., copying of this document and giving it to others and the using or communication of

the contents thereof, are forbidden without express authority. Offenders are liable to the

a utility model or design. All specification supplied herein are subject to change without

notice at any time.

GL100M User manual

TRACGL100MUM001 -2-

Contents

Contents ............................................................................................................................................2

0. Revision history ............................................................................................................................3

1. Introduction...................................................................................................................................4

2. Product Overview .........................................................................................................................5

2.1. Appearance..........................................................................................................................5

2.2. Buttons/Mini USB Interface Description............................................................................5

2.3. Two Triple-Color LEDs Description...................................................................................6

3. Getting Started ..............................................................................................................................7

3.1. Parts List..............................................................................................................................7

3.2. Battery Charging .................................................................................................................7

3.3. Install SIM Card..................................................................................................................7

3.4. Turn on/Turn off..................................................................................................................8

3.5. Operating on function key...................................................................................................8

4. Troubleshooting and Safety info...................................................................................................9

4.1. Troubleshooting...................................................................................................................9

4.2. Safety info.........................................................................................................................10

GL100M User manual

TRACGL100MUM001 -3-

0. Revision history

Revision Date Author Description of change

1.00 2011-09-16 Cid Xu Initial

GL100M User manual

TRACGL100MUM001 -4-

1. Introduction

GL100M is a powerful GPS locator which is designed for vehicle, pets and asserts tracking. With

superior receiving sensitivity, fast TTFF and GSM frequencies 850/900/1800/1900. Its location

can be real time or schedule tracked by backend server or specified terminals. Based on the

embedded @Track protocol, GL100M can communicate with the backend server through

GPRS/GSM network, and transfer reports of emergency, Geo-fencing, device status and scheduled

GPS position etc… Service provider is easy to setup their tracking platform based on the

functional @Track protocol.

GL100M User manual

TRACGL100MUM001 -5-

2. Product Overview

2.1. Appearance

2.2. Buttons/Mini USB Interface Description

Button /Mini USB Interface Description

Power Key zTurn on GL100M

zTurn off GL100M (If power key is

enabled).

Function Key zGeo-Fence mode

Long press the key to enable/disable

Geo-Fence ID0

zGeo-Fence in current position mode

Long press the key to enable/disable

Geo-Fence ID0. If enable Geo-Fence ID0,

using the current position as the centre of

Geo-Fence 0.

zSOS mode (default)

GL100M User manual

TRACGL100MUM001 -6-

Long press the key to active SOS alarm

Mini USB interface Plug in the AC-DC power adapter to this

interface for charging battery.

2.3. Two Triple-Color LEDs Description

There are two triple-color LEDs in GL100M. Each LED shows red, green and blue to indicate

different state of GL100M. For better understanding, we call them Red LED 1, Green LED 1,

Blue LED 1 and Red LED 2, Green LED 2, Blue LED 2.

Light Color event State

The power key has been pressed light, It will be off after the key released.

The device receives a valid

command

light

When power on the terminal light for about 2 seconds

Red

When power off the terminal slow flash(about 2s once) until the terminal

is off.

network searching fast flash

network has been registered slow flash

Green

SIM pin locked ever-light

GPS is in fixing fast flash

LED1

Blue

GPS has fixed ever-light for about 4 seconds

The device is in charging fast flashRed

When the battery in low status slow flash(about 2s)

charging has completed ever-lightGreen

After inserting the charger light for 4 seconds to indicate the battery

status is checked

LED2

Blue The function key has been

pressed

The blue led2 will be light when the function

key is pressed. It will be off after the function

key released or the corresponding event

(SOS event or Gen-Fence 0 switch)

generated because of the key pressed for 3

seconds.

GL100M User manual

TRACGL100MUM001 -7-

3. Getting Started

3.1. Parts List

Name Picture Remark

GL100M Locater

The GSM/GPRS/GPS locator.

AC-DC Power Adapter

(Standard accessory)

It is used to charge the internal

battery of GL100M.

Screw Driver

(Standard accessory)

It is used to twist off/ tighten the

two screws on the side of GL100M

when install SIM card.

3.2. Battery Charging

zPlease connect AC-DC power adapter with GL100M.

zInsert the AC-DC power adapter into the power socket.

zDuring charging, the Red LED 2 is blinking quickly. When the battery is full charged, the

Green LED 2 will be solid.

zCharging time is about 4 hours.

Note: Before the first time using GL100M, please full charge the battery.

3.3. Install SIM Card

zUse a screw driver to twist off the two screws on the side of GL100M.

zThen remove the screws and SIM cover.

zInsert the SIM card into the SIM cover according to the direction shown.

zFinally, put the SIM cover into the SIM slot and tighten screws.

GL100M User manual

TRACGL100MUM001 -8-

3.4. Turn on/Turn off

zTurn on: Press the Power key at least 3 seconds and release it to turn on GL100M. At the

same time, Red LED 1 will light on for 2~3 seconds. Then Green LED 1 starts to blink

quickly which means searching the GSM network. After the GSM network is registered, it

turns to be slow blinking.

zTurn off: Press the Power key at least 3 seconds; Red LED 1 will slow flash until the terminal

is off. Please note the end-user can not power off GL100M when the power key is disabled by

protocol.

3.5. Operating on function key

zFirst please make sure the function key is enabled.

zWhen the function key is in Geo-Fence mode and the function key is enabled. To long press

the function key will enable/disable the Geo-Fence 0.

Note: “Check interval”, “Central Point” and “Radius” of Geo-Fence0 shall be preset.

zWhen the function key is in SOS mode, after long press for 3 seconds, the device will report

the current position according to the result of the latest GPS fixing and then start GPS fixing.

After the GPS fixing finishes or timeout, the device will report the SOS message according

the result of the GPS fixing..

GL100M User manual

TRACGL100MUM001 -9-

4. Troubleshooting and Safety info

4.1. Troubleshooting

Trouble Possible Reason Solution

The SIM card is not inserted. Please insert the SIM card into

GL100M.

The signal is too weak;

GL100M can’t register to the

network.

Please move GL100M into

place with good GSM

coverage.

System do not support hot plug. Before power on the terminal,

insert the SIM card first.

After GL100M is turned on,

the Green LED 1 flashes

quickly always.

PIN locked Using SIM card without

SIM-PIN, or unlock SIM-PIN.

The SIM card in GL100M

doesn’t support GPRS.

Try a GPRS supported SIM

card.

APN is wrong. Some APN can

not visit the internet directly.

Ask the network operator for

the right APN.

Messages can’t be reported

to the backend server by

GPRS.

The IP address or port of the

backend server is wrong.

Make sure the IP address for

the backend server is an

identified address in the

internet.

The function of power key was

disabled by AT+GTFKS.

Enable the function of power

key by AT+GTFKS.

Unable to power off

GL100M.

Unable to power off GL100M if

charger connected.

Disconnect charger, and try

again.

GL100M is turned on after

insert a charging cable.

The function of full power up

was enabled by AT+GTFKS.

Disable the function of full

power up byAT+GTFKS.

No response from UART

when configure GL100M

through UART

GL100M is in power saving

mode.

Remove the Data_Cable_M,

and plug it in again.After this

operation, GL100M will exit

from power saving mode for 10

seconds.

Please move GL100M to a

place with open sky.

It is better to let the top surface

face to sky. (The same surface

with indication LED)

GL100M can’t get

successful GPS fixing.

The GPS signal is weak.

GL100M will stop GPS if it

can’t get GPS fixing in 3

minutes (except in emergency
