Quantum StorNext QD7000 Manual de usuario

Changing Host Protocol in

Base System

StorNext QD7000

Firmware 8.40.xx.xx

6-68680-01 Rev A

ii Changing Host Protocol in Base System

Changing Host Protocol in Base System, 6-68680-01 Rev A, March 2018 Product of USA.

Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not

limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this

publication from time to time without notice.

Your right to copy this manual is limited by copyright law. Making copies or adaptations without prior written authorization of

Quantum Corporation is prohibited by law and constitutes a punishable violation of the law.

TRAEMARK STATEMENT

Artico, Be Certain (and the Q brackets design), DLT, DXi, DXi Accent, DXi V1000, DXi V2000, DXi V4000, GoVault, Lattus, NDX, the

Q logo, the Q Quantum logo, Q-Cloud, Quantum (and the Q brackets design), the Quantum logo, Quantum Be Certain (and the Q

brackets design), Quantum Vision, Scalar, StorageCare, StorNext, SuperLoader, Symform, the Symform logo (and design), vmPRO,

and Xcellis are either registered trademarks or trademarks of Quantum Corporation and its affiliates in the United States and/or

other countries. All other trademarks are the property of their respective owners.

Products mentioned herein are for identification purposes only and may be registered trademarks or trademarks of their respective

companies. All other brand names or trademarks are the property of their respective owners.

Quantum specifications are subject to change.

Changing Host Protocol in Base System iii

Preface

Note: The 8.40.xx.xx firmware (Madrid) is used in the QD7000

(E5600, Titan RAID controller, only). Refer to the NetApp to

Quantum Naming Decoder section for additional information.

This section provides the following information:

•Audience

•Prerequisites

•NetApp to Quantum Naming Decoder

•Product Safety Statements

•Contacts

•Comments

•Quantum Global Services

Audience This manual is intended for storage customers and technicians.

Preface

iv Changing Host Protocol in Base System

Prerequisites Prerequisites for installing and using this product include knowledge of:

• Servers and computer networks

• Network administration

• Storage system installation and configuration

• Storage area network (SAN) management and direct attach storage

(DAS)

• Fibre Channel (FC) and Ethernet protocols

NetApp to Quantum

Naming Decoder

Use Table 1 to correlate the NetApp product nomenclature to the

equivalent Quantum-storage naming conventions.

Table 1 Product Nomenclature

E-Series NetApp

Product Quantum-Storage Description

Controller-Drive Tray Base System Quantum uses Base System when referring to a drive

tray with the RAID controllers.

Drive Tray Expansion Unit Quantum uses Expansion Unit when referring to a

drive tray with the environmental services modules

(ESMs).

E5600 (Code Name:

Titan)

RAID Controller Four 16Gb/s FC SFP+ host ports

E5500 (Code Name:

Soyuz)

RAID Controller Four 16Gb/s FC SFP+ host ports

E5400 (Code Name:

Pikes Peak)

RAID Controller Four 8Gb/s FC SFP+ host ports

DE6600 (Code Name:

Wembley)

4U 60-drive

enclosure

Sixty 3.5 inch disk drives

Preface

Changing Host Protocol in Base System v

E5660

• DE6600 4U drive

enclosure

• With E5600 RAID

controllers

(Titan)

Quantum StorNext

QD7000

E5560

• DE6600 4U drive

enclosure

• With E5500 RAID

controllers

(Soyuz)

Quantum StorNext

QD7000

E5460

• DE6600 4U drive

enclosure

• With E5400 RAID

controllers (Pikes

Peak)

Quantum StorNext

QD6000

E-Series NetApp

Product Quantum-Storage Description

Preface

vi Changing Host Protocol in Base System

Product Safety

Statements

Quantum will not be held liable for damage arising from unauthorized

use of the product. The user assumes all risk in this aspect.

This unit is engineered and manufactured to meet all safety and

regulatory requirements. Be aware that improper use may result in

bodily injury, damage to the equipment, or interference with other

equipment.

WARNING: Before operating this product, read all instructions and

warnings in this document and in the system, safety, and

regulatory guide.

E5424

• DE5600 24-drive

2U drive

enclosure

• Code Name:

Camden

• With E5400 RAID

controllers (Pikes

Peak)

Quantum StorNext

QS2400

E5412

• DE1600 12-drive

2U drive

enclosure

• Code Name:

Ebbets

• With E5400 RAID

controllers (Pikes

Peak)

Quantum StorNext

QS1200

E-Series NetApp

Product Quantum-Storage Description

Preface

Changing Host Protocol in Base System vii

Preface

viii Changing Host Protocol in Base System

Contacts For information about contacting Quantum, including Quantum office

locations, go to:

http://www.quantum.com/aboutus/contactus/index.aspx

Comments To provide comments or feedback about this document, or about other

Quantum technical publications, send e-mail to:

[email protected]

Quantum Global

Services

Accelerate service issue resolution with these exclusive Quantum

StorageCare services:

•Service and Support Website - Register products, license software,

browse Quantum Learning courses, check backup software and

operating system support, and locate manuals, FAQs, firmware

downloads, product updates and more in one convenient location.

Benefit today at:

http://www.quantum.com/serviceandsupport/get-help/

index.aspx#contact-support

•eSupport - Submit online service requests, update contact

information, add attachments, and receive status updates via email.

Online Service accounts are free from Quantum. That account can

Preface

Changing Host Protocol in Base System ix

also be used to access Quantum’s Knowledge Base, a

comprehensive repository of product support information. Get

started at:

http://www.quantum.com/customercenter/

For further assistance, or if training is desired, contact the Quantum

Customer Support Center:

North America 1-800-284-5101 (toll free)

+1-720-249-5700

EMEA +800-7826-8888 (toll free)

+49-6131-324-185

APAC +800-7826-8887 (toll free)

+603-7953-3010

For worldwide support:

http://www.quantum.com/serviceandsupport/get-help/

index.aspx#contact-support

E-Series and EF-Series

Changing the host protocol in the E5600 or EF560 by replacing

hardware components

This documents applies to E5600 storage arrays, including the E5612, E5624, and E5660, and the EF560 flash arrays.

The following image shows all the protocol changes that are possible:

*If you are converting between Fibre Channel and iSCSI, you must use the host interface card (HIC) feature pack conversion

documents, not the procedures in this document.

**If you are converting from iSCSI to SAS or InfiniBand (IB), you might need to swap only the HICs or the controllers and

HICs as a unit, depending on your Replacement Part Number. You can find the instructions for determining the Replacement

Part Number in this document.

For other changes to the HIC protocol, you might need to perform both a HIC hardware upgrade and a HIC feature pack

conversion, or you might be able to perform a HIC feature pack conversion only. For example, if you want to change the

protocol from Fibre Channel to IB, and you want to use iSCSI RDMA Protocol (SRP) instead of iSCSI Extensions for Remote

Direct Memory Access (iSER), you must follow a two-step process:

1. Perform a HIC hardware upgrade to IB-iSER.

2. Perform a HIC feature pack conversion to convert the IB HICs from iSER to SRP.

Note: This document describes how to perform HIC hardware upgrades only; for instructions for performing HIC feature

pack conversions, see the list of related documents at the end of this topic.

Considerations for this procedure

Before starting the procedure, be aware of the following:

• Because the power is off, you must schedule a downtime maintenance window for this procedure, and you cannot access

data on the storage array or flash array until you have successfully completed the upgrade.

Web: www.netapp.com • Feedback: [email protected]
