Quantum DPM 5500 Manual de usuario

4XDQWXP'30

$

4XDQWXP'30

'30

8VHU¶V*XLGH8VHU¶V*XLGH8VHU¶V*XLGH8VHU¶V*XLGH8VHU¶V*XLGH

Quantum DPM5500 User’s Guide, 81-81527-01 A01, November 2005, Made in USA.

Quantum Corporation provides this publication “as is” without warranty of any kind, either express or

implied, including but not limited to the implied warranties of merchantability or fitness for a particular

purpose. Quantum Corporation may revise this publication from time to time without notice.

Your right to copy this manual is limited by copyright law. Making copies or adaptations without prior

written authorization of Quantum Corporation is prohibited by law and constitutes a punishable violation of

the law.

TRADEMARK STATEMENT

DLT and DLTtape are trademarks of Quantum Corporation.

Quantum, the Quantum logo, and the DLTtape logo are all registered trademarks of Quantum Corporation.

Other trademarks may be mentioned herein which belong to other companies.

Quantum DPM5500 User’s Guide iii

Contents

Chapter 1 DPM5500 System Description 1

Overview..............................................................................................................1

A New Approach to Data Protection .......................................................2

Optimized Performance for Windows Environments...........................2

Superior Service and Support....................................................................3

Features and Benefits .........................................................................................3

DPM5500 System ................................................................................................4

DPM5500 System.........................................................................................4

Hard Drive Storage ............................................................................................6

RAID Sets......................................................................................................7

Supported RAID Configurations .....................................................................7

RAID 5 Configuration.................................................................................7

Turning on the System.......................................................................................8

DPM5500 Operations .......................................................................................10

Chassis LEDs and Buttons .......................................................................10

Hard Drive Sled LEDs ..............................................................................11

Ethernet Port LEDs....................................................................................12

Power Supply LED....................................................................................13

Migrating Data Off the DPM5500 ..................................................................14

Backing Up the Microsoft DPM Database Files....................................15

Relocating the DPM5500 System....................................................................15

Contacts..............................................................................................................15

Contents

Quantum DPM5500 User’s Guide iv

Chapter 2 DPM5500 Remote User Interface 17

DPM5500 Web Pages .......................................................................................17

DPM5500 Web Page Menu Items ...........................................................18

Accessing DPM5500 Web Pages .............................................................18

System Status ....................................................................................................20

Accessing System Status ..........................................................................20

System Configuration ......................................................................................24

Accessing System Configuration ............................................................24

Identification..............................................................................................24

RAID ...........................................................................................................26

Network Configuration...................................................................................27

Accessing Network Configuration .........................................................27

Identification..............................................................................................28

Global Settings...........................................................................................30

Network Interfaces....................................................................................31

Administrator ............................................................................................32

Administration Web Site..........................................................................33

Users...................................................................................................................34

Accessing Users.........................................................................................34

Local Users .................................................................................................35

Local Groups..............................................................................................36

Maintenance ......................................................................................................37

Accessing Maintenance ............................................................................37

Date and Time............................................................................................38

Shutdown ...................................................................................................39

Logs .............................................................................................................40

Adaptec® Storage Manager.......................................................................41

DPM Administrator Console...................................................................42

Backup ........................................................................................................42

Remote Desktop ........................................................................................42

Alert E-Mail................................................................................................43

UPS ..............................................................................................................44

Appendix A DPM5500 System Specifications 46

Physical Characteristics...................................................................................47

Performance Characteristics ...........................................................................48

Environmental Specifications .........................................................................48

Contents

Quantum DPM5500 User’s Guide v

Quantum DPM5500 User’s Guide 1

Chapter 1

1DPM5500 System Description

This chapter describes the DPM5500 system and its components. The

chapter consists of:

•Overview

•Features and Benefits

•DPM5500 System

•Hard Drive Storage

•Supported RAID Configurations

•Turning on the System

•DPM5500 Operations

•Relocating the DPM5500 System

•Migrating Data Off the DPM5500

•Contacts

Overview 1

Quantum is a leader in disk-based backup and is committed to the

ongoing development of tiered storage solutions for data protection. This

tiered approach consists of disk- and tape based systems that optimize

Chapter 1 DPM5500 System Description

Overview

Quantum DPM5500 User’s Guide 2

the performance, reliability, availability, and return-on-investment of the

backup, recovery and archive process, based upon the business value of

customers’ data over time. As the next major progression in delivering on

its tiered data protection strategy, Quantum’s DPM5500 is an integrated

disk solution based upon Microsoft® System Center Data Protection

Manager 2006 (DPM). This new solution will provide Quantum’s

Windows Server™ customers a more granular choice in data protection

options.

A New Approach to Data

Protection 1Quantum’s DPM5500 combines carefully selected components to deliver

a fully integrated, high performance appliance ideal for disk-based

backup in Windows environments. This appliance gives the system

administrator an easy and efficient way to ensure that data in his

environment is protected against any number of potential threats. Most

importantly, the administrator can choose to apply this technology at

multiple points throughout the day. Contrast this with normal client/

server backup methodology. Rather than a nightly backup, backup data

is captured as many as 68 times in a single day. This gives the

administrator tremendous flexibility in providing outstanding service to

internal customers. Rather than having to lose all work completed on a

file between the time of data loss and the last nightly backup, the

restoration of data can be performed from the last DPM backup captured

which may never be more than fifty-nine minutes before the data loss

occurred.

Optimized Performance for

Windows Environments 1Choosing system components, especially in networking environments,

can be extremely difficult, time consuming and costly, especially when it

isn’t done right the first time. Quantum has done the hard work for you

by carefully designing the DPM5500 to closely match the capabilities of

Microsoft Data Protection Manager. By choosing the appropriately

configured server, the right disk array can deliver the performance and

quality that backup, recovery and archive environments demand,

Quantum’s DPM5500 stands above the rest in terms of ease of use,

performance, integration of differentiated features and an impressive

reputation for certified service and support.

The DPM5500 is available in both 4.8TB and 9.6TB configurations and

enough performance muscle to backup 8TB’s of Windows application

data every hour.

Chapter 1 DPM5500 System Description

Features and Benefits

Quantum DPM5500 User’s Guide 3

Superior Service and

Support 1The DPM5500 Series comes with a one-year next business day standard

warranty and StorageCare™ Guardian, Quantum’s new proactive remote

monitoring solution. The warranty can be extended for long-term

protection and peace of mind at an affordable price. Additional 5x9x4 and

7x24x4 service contract upgrade response levels are also available.

Professional Installation and Integration services can be purchased

through Quantum to ensure maximum uptime. Please contact Quantum

for availability in your region. Leveraging the intelligence inside the

DPM5500 Series, StorageCare Guardian proactively monitors the health

of the library over the Internet and uses intelligent diagnostics data to

remotely service the equipment when something is wrong. Guardian is

offered at no additional cost for products under warranty or service

contract. Guardian is easy to install and can be downloaded online.

Please visit http://guardianinfo.quantum.com for more information or

contact Quantum Support to download Guardian today.

Features and Benefits 1

• High performance disk-based system

• Microsoft Data Protection Manager 2006

• Microsoft Storage Server 2003

• Performance tuned media server

• StorageCare Guardian remote diagnostic service (future

enhancement)

• Protect 1 to 8 TB of Windows application files

• Enterprise class reliability and availability

• Hot-swappable drives and redundant power and cooling allow

maximum uptime to your operations

• Tape copy software supports disaster recovery best practices

(available 2006)

Chapter 1 DPM5500 System Description

DPM5500 System

Quantum DPM5500 User’s Guide 4

DPM5500 System 1

The system takes advantage of high speed hard drives to greatly reduce

the time required for backup/restore functions and also improve

confidence in completing the backup in the time allowed.

Table 1 DPM5500 Capacity

Specifications

DPM5500 System 1The DPM5500 system houses the following components:

• Drive sleds (twelve, eighteen, or twenty four drive sleds per storage

array) (customer serviceable)

• Four redundant power supplies (customer serviceable)

• Redundant fan modules located at the back of the unit (customer

serviceable)

• Motherboard, CPU, and memory (not customer serviceable)

• RAID controllers (not customer serviceable)

The customer serviceable components are removed and replaced either

through the front/back of the system (see figure 1).

DPM Model (with Drive Size) Raw Capacity

DPM5500 (400 GB drives) 4.8 TB to 9.6 TB

Chapter 1 DPM5500 System Description

DPM5500 System

Quantum DPM5500 User’s Guide 5

Figure 1 DPM5500 System

Components

Power suppliesLeft-hand blower Right-hand blowe

Center

fans

Ethernet

ports

Power and reset buttons

Drive sleds

Otros manuales para DPM 5500

Tabla de contenidos

Otros manuales de Almacenamiento de Quantum

Quantum

Quantum DLTtape DLT 7000 Manual de usuario

Quantum

Quantum DLTtape SDLT 600 Manual de usuario

Quantum

Quantum DLTtape SDLT 220 Hoja de información del producto

Quantum

Quantum Scalar i6000 Manual de usuario

Quantum

Quantum Scalar LTFS Manual de uso y cuidado

Quantum

Quantum DLT-V4 Manual de usuario

Quantum

Quantum Fireball Plus AS Manual de usuario

Quantum

Quantum Scalar i500 Manual de usuario

Quantum

Quantum QX Series Manual de usuario

Quantum

Quantum ValueLoader DLT VS160 Instrucciones de funcionamiento

Quantum

Quantum DAT 72 Manual de usuario

Quantum

Quantum PowerStor L200 Manual de usuario

Quantum

Quantum P4000 Series Manual de usuario

Quantum

Quantum Maxtor Fireball CR Manual de usuario

Quantum

Quantum ValueLoader DLT VS160 Manual de usuario

Quantum

Quantum P3000 Series Manual de usuario

Quantum

Quantum DLT Series Instrucciones de instalación

Quantum

Quantum Scalar i500 Manual de usuario

Quantum

Quantum DLTtape DLT 2000 Manual

Quantum

Quantum DXi3500 Manual de usuario

Quantum

Quantum Scalar 24 Manual de usuario

Quantum

Quantum DXi6900 Guía de inicio rápido

Quantum

Quantum QXS G2 Series Manual de funcionamiento

Quantum

Quantum Scalar 218 Guía de instalación

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
