ActiveScale

6-68926-04, Rev. A

with ActiveScale OS 6.1.0 software

P100E3 Site Requirements Guide

ActiveScale™ P100E3 Site Requirements Guide

Quantum ActiveScale™ P100E3 Site Requirements Guide, 6-68837-04, March 2022, Product of USA.

Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the

implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time

without notice.

without prior written authorization of Quantum Corporation is prohibited by law and constitutes a punishable violation of the law. ActiveScale,

DXi, DXi Accent, FlexSync, FlexTier, iLayer, Lattus, Quantum, The Quantum Logo, QXS, Scalar, StorNext, SuperLoader, Vision, and Xcellis

are either registered trademarks or trademarks of Quantum Corporation and its affiliates in the United States and/or other countries. All other

trademarks are the property of their respective owners. Quantum specifications are subject to change.

TRADEMARK STATEMENT

Quantum is/are a registered trademark of Quantum Corporation and ActiveScale is a trademark of Quantum Corporation and its affiliates in the

United States and/or other countries. Amazon S3, Amazon Simple Storage Services, and Amazon AWS S3 are trademarks of Amazon.com, Inc. or

its affiliates in the United States and/or other countries. Other trademarks are the property of their respective owners. References in this

publication to Quantum-branded products, programs, or services do not imply that they will be made available in all countries. Product

specifications provided are sample specifications and do not constitute a warranty. Actual specifications for unique part numbers may vary. Please

visit the Support section of our website https://quantum.com/support for additional information on product specifications.

ActiveScale™ P100E3 Site Requirements Guide

Contents

List of tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

List of figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1 Document summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.2 Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.3 System specification summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2 ActiveScale P100E3 site requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.1 Warnings and cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 Environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2.1 Airflow requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.3 Rack requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.4 Delivery route inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.4.1 Walking path inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.5 Build space requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.6 Servicing space requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.7 PDU requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.7.1 Power sequencing requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.8 Network requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Contacting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

ActiveScale™ P100E3 Site Requirements Guide

ActiveScale™ P100E3 Site Requirements Guide List of tables

List of tables

Table 1-1. System specification summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 2-1. Footprint of packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table 2-3. Space requirement specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 2-2. Footprint of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 2-4. Recommended startup order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

ActiveScale™ P100E3 Site Requirements Guide List of tables

ActiveScale™ P100E3 Site Requirements Guide List of figures

List of figures

Figure 1-1. ActiveScale P100E3 system layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 2-1. Minimum servicing space required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ActiveScale™ P100E3 Site Requirements Guide List of figures

ActiveScale™ P100E3 Site Requirements Guide

1 Document summary

This chapter defines the scope of this document and provides a brief overview of the ActiveScale P100E3

system site requirements.

Topics:

•Scope on page 9

•Product overview on page 9

•System specification summary on page 10

1.1 Scope

This document is designed to address all of the important considerations that a user of the ActiveScale

P100E3 system needs to make before integrating the system at the site where the system will be deployed.

This document should be used by the systems architect, system planner, and site manager and teams which

plan the integration of the ActiveScale P100E3 storage solution in their data center(s).

1.2 Product overview

The ActiveScale P100 is a modular object storage system that allows you to store from either:

• 432 TB (raw) of storage using 12 TB HDD’s.

• 504 TB (raw) of storage using 14 TB HDD’s

The base configuration consists of:

• Three P100E3 Nodes.

• One or Two System Interconnects

Figure 1-1. ActiveScale P100E3 system layout

ActiveScale™ P100E3 Site Requirements Guide

1.3 System specification summary

The following table is a summary of specifications relevant to the ActiveScale P100E3 system.

Table 1-1. System specification summary

Condition (fully configured) Non-operating Operating

Altitude -984 ft to 39,371 ft

(-300 m to 12,000 m)

-984 ft to 10,000 ft

(-300 m to 3,048 m)

Height in rack units (U) • 3 node system 3U

Power requirements (typical/

maximum)

N/A • 3 node —1.85 to 2.03 kW

Relative humidity 20% to 95% non-condensing 20% to 80% non-condensing

Relative humidity gradient 30% per hour maximum 30% per hour maximum

System width and depth • Width—17.6 in (448.2 mm)

•Depth—35 in (881 mm)

Temperature -40°F to 158°F (-40°C to 70°C) 50°F to 95°F (10°C to 35°C)

Temperature de-rating 33.8°F per 984.2 ft above 9842.5 ft

(1°C per 300 m above 3000 m)

33.8°F per 984.2 ft above 3116.8 ft

(1°C per 300 m above 950 m)

Temperature gradient 86°F (30°C)/hour 68°F (20°C)/hour

Thermal output N/A • system—6.31 to 6.92 KBTU/hour

Weight • configuration— 180 lbs (82 kg)
