Quantum Networks QN-I-200 Manual de usuario
Access Point User Guide
Models: QN-I-200, QN-I-220, QN-O-230
Copyright Information
Copyright & trademark specifications are subject to change without prior notice. Copyright ©
2018 Quantum Networks (SG) Pte. Ltd. All Rights Reserved. Quantum NetworksTM& the
logo are trademarks of Quantum Networks (SG) Pte. Ltd. Other brands or products
mentioned may be trademarks or registered trademarks of their respective owners.
Mentioned contents of this document can’t be used, translated or transmitted in any form or
by any means without taking prior written permission from Quantum Networks (SG) Pte.
Ltd..
Contents
Introduction...............................................................................................................................4
Access Point Overview.......................................................................................................4
Package Contents...............................................................................................................4
Unpacking the Access Point..............................................................................................4
Glossary....................................................................................................................................5
Pre-configuring Access Point in standalone Mode............................................................6
Navigation.................................................................................................................................8
Navigating the web Interface.............................................................................................8
AP Configuration.....................................................................................................................9
Dashboard............................................................................................................................9
Configuration......................................................................................................................11
Device.............................................................................................................................11
Internet............................................................................................................................13
Local Subnet..................................................................................................................15
Bridge Profile..................................................................................................................16
Wireless..........................................................................................................................17
Ethernet Ports................................................................................................................21
Hotspot............................................................................................................................22
Management......................................................................................................................24
Diagnostics.........................................................................................................................25
Introduction
Access Point Overview
This document explains how to configure and manage standalone Access Point.
Quantum Networks Wireless APs are the industry's most facile to utilize. It’s a
feature-opulent Wi-Fi APs designed to bring power and simplicity together for sizably
voluminous-scale indoor deployments.
Quantum Networks wireless AP can be deployed in standalone mode and can be
managed through Quantum cloud controller, as part of the Quantum Wireless Smart
WLAN system.
A wireless technology that sanctions wireless signals to navigate around
interference, elongate wireless signal range, and increment speeds and as well as
capacity for wireless networks.
Note: To get more information about Quantum Networks products visit us @
https://qntmnet.com
Package Contents
A consummate AP package contains all of the items listed below.
Access Point Device
Quick set up guide
Unpacking the Access Point
Once you received Quantum Networks Wireless Access Point, unpack the AP and
check the package contents.
Open the AP package, and remove the contents carefully.
Confirm all items listed in Package Contents are included in the package.
Check every item for damage or in case of missing. If so, notify your
authorized Quantum Networks sales representative immediately.
Glossary
Following terms are frequently used in this manual.
Term
Definition
AP
Access Point
DHCP
Dynamic Host Configuration Protocol (DHCP) is a network protocol that
enables a server to automatically assign an IP address to concern devices.
Static
A static address is a fix IP address assigned to the device.
PPPoE
PPPoE stands for Point-to-Point Protocol over Ethernet, a network protocol
for encapsulating Point-to-Point Protocol (PPP) frames inside Ethernet
frames.
WLAN
WLAN i.e. Wireless Local Area Network, a wireless network that can transfer
data at high speeds.
LAN
Local Area Network
WAN
Wide Area Network
SSID
An SSID i.e. Service Set Identifiers a unique ID that consists of 32
characters and is used for naming wireless networks.
WPA2
WPA2 (Encryption Method) - Wi-Fi Protected Access 2 - Pre-Shared Key, is
a method of securing your network using Pre-Shared Key (PSK) for
authentication.
WPA-Mixed
With WPA mixed (Encryption Method) mode network, one can connect with
both WPA (TKIP) and WPA2 (AES) clients.
TKIP
TKIP (Temporal Key Integrity Protocol) is an encryption protocol included as
part of the IEEE 802.11i standard for wireless LANs (WLANs). It was
designed to provide more secure encryption than the notoriously weak
Wired Equivalent Privacy (WEP), the original WLAN security protocol.
AES
AES (Advanced Encryption Standard) is an encryption protocol which is
much more secure as it uses longer encryption keys.
Wireless 2.4
GHz
2.4GHz band provides great distance coverage, however transmits data at
slower speeds.
Wireless 5 GHz
The 5 GHz band provides less coverage, however transmits data at faster
speeds.
Pre-configuring Access Point in standalone Mode
AP default SSID is QN_XX: XX (where XX:XX= last four digits of AP MAC ID).
Connect QN_XX:XX SSID and enter AP default IP 169.254.1.1 in browser.
Click on start configuration.
Figure 1
Do IPv4 setup (WAN) by selecting required option DHCP, Static or PPPoE and
proceed for Next.
Select Management Mode as Standalone and click on Next.
Admin can select AP operation mode as Bridge or Router.
oBridge (In this mode, device connects to a wired or wireless router via an
Ethernet cable)
oRouter (Gateway) (In this mode, device connects to the internet directly and
shares internet access to multiple wired and wireless devices.
oFor Operation Mode - Bridge, select option and follow below procedure.
Configure WLAN (SSID) parameters and click on Next.
Configuration Summary screen will appear. Click on Reconfigure if
any changes required or click on Finish to complete the quick
configuration.
oFor Operation Mode - Router, select option and follow below procedure.
Configure WLAN (SSID) and Local subnet parameters and click on
Next.
Configuration Summary screen will appear. Click on Reconfigure if
any changes required or click on Finish to complete the quick
configuration.
Navigation
Navigating the web Interface
Open Web Browser and enter configured IP address of the Access point.
Below screen will appear.
Figure 4: AP Web Login Page
Enter Username and Password (use the same created while quick setup process),
click on Login and get below screen.
Figure 5: Web Interface Dashboards
AP Configuration
Dashboard
Select Configuration > Dashboard. Dashboard screen appears.
Figure 6: Dashboard
Statistics
Statistics
Description
AP Name
Name of Access Point
Device Location
Access point location
GPS Coordinates
Displays GPS coordinates
Managed By
Displays AP managed by QN cloud or as standalone
Mode
Displays AP selected mode Bridge / Gateway
Device Model
AP Model Detail
Serial no.
Serial number of the device.
MAC
MAC address of the device.
Firmware Version
Displays current AP firmware version
Local Time
Displays local current time as per selected country
Uptime
Displays AP actual up time detail
CPU
Provides CPU utilization detail
Memory
Provides Memory utilization detail
WAN IP Schema
Displays selected IP schema –i.e. DHCP / Static /
PPPoE
Channel
Displays active radio channel detail
Clients on 5 GHz
Displays connected clients on 5 GHz
Clients on 2.4 GHz
Displays connected clients on 2.4 GHz
Connected Clients
Parameter
Description
Radio
Displays radio detail through which clients has been
connected.
SSID
Displays SSID name through which clients has been
connected.
MAC
Displays MAC address of connected client device.
IP
Displays IP address taken by host device
Hostname
Displays Host name
RSSI
Displays wireless signal strength. (Between AP and
Connected client)
