Qstarz EXtreme BT-Q818X Manual de usuario



TableofContents



1.OVERVIEW...................................................................................1

2.PACKAGECONTENT .....................................................................1

3.PRODUCTSPECIFICATION ............................................................2

4.MAINFEATURES ..........................................................................3

5.INTRODUCTION ...........................................................................3

5‐1.APPEARANCE.................................................................................................3

5‐2.BATTERYINSTALLATION ..................................................................................4

5‐3.LEDINDICATORS ...........................................................................................6

5‐4.FUNCTIONOFAUTOON‐OFF(POWERSAVINGMODE)........................................7

6.STARTTOUSE..............................................................................7

6‐1.FULLYCHARGETHEBATTERYWHENUSINGATTHEFIRSTTIME...............................7

6‐2.ACTIVATETHEBLUETOOTHFUNCTIONINYOURPDA/SMARTPHONEORPC...........7

6‐3.CREATEBLUETOOTHSETTING(WINDOWSMOBILE5/6FORPOCKETPC) ..............8

6‐4.CONFIGURETHEGPSINTERMEDIATEDRIVERWITHTHEGPSSETTINGSICON .......12

6‐5.ACTIVATEG‐MOUSEFUNCTIONANDCONFIGURATIONVIAUSBCONNECTION ......14

6‐6.SWITCHTOEXTREME5HZSPORTMODEANDACTIVATEA‐GPSBYQSTARZGPSVIEW

SOFTWAREAPPLICATION ......................................................................................14

6‐7.STARTYOURNAVIGATIONSOFTWARE .............................................................17

6‐8.USEFULREFERENCE5HZAPPLICATION‐RACECHRONO .....................................18

7.TROUBLESHOOTING..................................................................19

8.SAFETYNOTICES ........................................................................20

BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..……………………………………………………………………………………………………………………......................

1www.Qstarz.com

1.Overview

ThankyouforchoosingQstarzBT‐Q818XeXtreme66‐Channel

PerformanceBluetooth®GPSReceiver,built‐insecondgeneration

GPSchipsetMTKwith66channelstracking,provideshyper

performancetomeetthemarket’sexpectationbyfastestpositionfix

withitshighspeedcalculatingtechnology.Itcombineswireless

BluetoothandwiredG‐Mousefunctionsforyourconvenienceplus

1~5Hzadjustablecompatibilitygivingyouevenhigherpositioning

andaccuracypurposeduringeXtremesports.



2.PackageContent

(1) GPSUnitBT‐Q818X

(2) CigaretteAdapter

(3) MiniUSBCable(Optional)

(4) QuickGuide

(5) WarrantyCard



1.



2.



3.



Beyond Navigation BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..…………………………………………………………………………...……………………………………………................

www.Qstarz.com 2

3.ProductSpecification

General

GPSChipMTKIIGPSModule

FrequencyL1,1575.42MHz

C/ACode1.023MHzchiprate

Channels66‐CHPerformanceTracking

Antenna(Internal)Built‐inpatchantennawithLNA

SensitivityTracking‐165dBm

DatumWGS84

PerformanceCharacteristic

PositionWithoutaid:3.0m2D‐RMS

Accuracy<3mCEP(50%)withoutSA(horizontal)

DGPS(WAAS,ENGOS,MSAS):2.5m

VelocityWithoutaid:0.1m/s,DGPS(WAAS,ENGOS,MSAS):

0.05m/s

Time50nsRMS

Cold/Warm/HotStart 35/33/1sec,average

DynamicCondition

Altitude<18,000m

Velocity<515m/sec

Acceleration<4g

Protocol

GPSOutputDataProtocol:NMEA0183(V3.01)‐GGA,GSA,GSV,RMC

BaudRate115,200bps

Power

Built‐inrechargeableLi‐ionbattery,Upto42hrsafterfullycharged

Bluetooth

StandardFullycompliantwithBluetoothV1.2

BluetoothProfileSerialPortProfiles(SPP),Upto10meters

Others

Size/Weight72.2(L)X46.5(W)X20(H)mm/64.7g(battery

included)

Operating

Temperature‐10℃to+60℃

StorageTemperature‐20℃to+60℃

Charging0℃to+45℃

BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..……………………………………………………………………………………………………………………......................

3www.Qstarz.com

4.Mainfeatures

zAdoptMTKIIchipsetwithsuper66‐CHperformanceand

highsensitivityto‐165dBm

zUpto42hrsoperatingtimeforGPSnavigation

zFastPositionFix,Coldstart35s,Warnstart33s,Hotstart1s

zG‐Mouse+Bluetoothinone:wiredandwirelessGPS

receiver

zAdjustable1~5HzupdaterateforthedemandofeXtreme

sports

zSmartpowercontrol–AutoOn‐Offfunction

zA‐GPSsupportbooststhefixspeedto15secfaster

zDGPS(WAAS+EGNOS+MSAS),QZSSsupport

zCompatiblewithBluetoothSerialPortProfile(SPP)in10m

wirelessly



5.Introduction

5‐1.Appearance



1.Powerjack(miniUSBtype)

2.Modeswitch(OFF/NAV/5Hz)

3.BatterystatusLED(Red/Green)

4.BluetoothstatusLED(Blue)

5.GPSstatusLED(Orange)

6.Internalantenna



Beyond Navigation BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..…………………………………………………………………………...……………………………………………................

www.Qstarz.com 4

5‐2.Batteryinstallation

‐PutBatteryinplace:

1.PressthePUSHbuttononthebottom

sideoftheunit



2.Pulloutthebatterycover.Insert

batteryintheunit



3.Putbatterycoverontothecabinet



4.Thenpushdownandforceitforwardto

fitfirmly







BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..……………………………………………………………………………………………………………………......................

5www.Qstarz.com



‐TakeBatteryout:

1.PressthePUSHbuttononthebottomsideoftheunit



2.Pulloutthebatterycover



3.Thentakeoutthebatteryfromtheunit.



Beyond Navigation BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..…………………………………………………………………………...……………………………………………................

www.Qstarz.com 6



‐Chargingyourbattery

ForthefirsttimeusingtheBT‐Q818X,

pleasechargebatteryuntilitisfully

charged.Takethepowercableand

connectittothepowerjack(mini

USBtype)andrechargethrough

travelchargerorcarcigarette

adaptor.Thiswillbegintochargethe

battery.Chargingtimeis3hours

typically.

‐WhenthePowerLEDisRed,batterypowerislowstatus.Please

recharge.

‐WhenthePowerLEDisGreen,thebatteryisunderchargingmode.

‐WhenthePowerLEDisoff,thebatteryisfullycharged.

NOTE:TheCigaretteAdaptorcanonlybeusedtochargeBT‐Q818.

Pleasedon’tmakeuseofitwithdevicesotherthanBT‐Q818.



5‐3.LEDIndicators



LEDStatus FlashONOFF

Power

(Red/Green)

Recharging

(Green)

LowPower

(Red)

Fully

charged

Bluetooth

(Blue)

Flashper2sec.:

Bluetoothconnected

andtransmittingMode

Flashper5sec.:Power

savingmode

Not

connected

/Pairing

GPSnot

powered

GPS

(Orange)

GPSpositionisfixed,

Navigation

Detecting

Satellite,

GPS

position

notfix

GPSnot

powered

BT‐Q818XBluetoothA‐GPSReceiver

…….………………………………………………………………………………………………………………………………………………………………….



……….…..……………………………………………………………………………………………………………………......................

7www.Qstarz.com

5‐4.FunctionofAutoOn‐Off(Powersavingmode)



BT‐Q818XsupportsAutoOn‐Off(Powersavingmode).Itcan

automaticallyentersleepingmodeaftertheBluetoothconnectivityis

turnedoff,sotheBlueLEDwillturntoflashevery5seconds.Thus

youcanalwayspoweritonwithverylowpowerconsumption.

Underpowersavingmode,whendetectingBluetoothisbeing

connected,BT‐Q818XwillautowakeupitselfandtheblueLEDwill

turntoflashevery2secondsandGPSOrangeLEDwillbealsoOn.



Note:PowersavingmodewouldnotfunctionwhenUSBisplugged

in.



6.Starttouse

6‐1.Fullychargethebatterywhenusingatthefirst

time

Afullychargedbatterycanlastfor42hourscontinuouslyoperation

(underoptimumconditions).



6‐2.ActivatetheBluetoothfunctioninyour

PDA/SmartphoneorPC



BeforeactivatingtheBluetoothfunctioninyourPDA/PC,please

switchonBT‐Q818XReceiverforparingandcheckifyourdeviceis

equippedwithBluetoothfunction.Ifnot,youmayneedtoacquirean

optionalCF/SDBluetoothcardorBluetoothdongle.



NOTE1:

BT‐Q818Xwouldbeidentifiedas”QstarzGPS”underBluetooth

Manager.Infurtheruse,youjustneedtoclickittoconnecttothis

BluetoothGPSReceiver.


