Qlogic QLA12160 Manual

Hardware Installation Guide for the

QLA12160 Board

64-Bit PCI Dual SCSI Host Adapter Board

for the PCI Bus

DC8151101-00 C

September 14, 2001

Get other manuals https://www.bkmanuals.com

QLogic Corporation

Page ii DC8151101-00 C

Information furnished in this manual is believed to be accurate and reliable.

However, QLogic Corporation assumes no responsibility for its use, nor for any

infringementsofpatentsorotherrightsofthirdpartieswhichmayresultfromitsuse.

QLogicCorporationreserves theright to change product specifications at any time

without notice. Applications described in this document for any of these products

are for illustrative purposes only. QLogic Corporation makes no representation nor

warranty that such applications are suitable for the specified use without further

testingormodification.QLogicCorporationassumesnoresponsibilityforanyerrors

that may appear in this document.

No part of this document may be copied nor reproduced by any means, nor

translated nor transmitted to any magnetic medium without the express written

consent of QLogic Corporation.

QLogic is a trademark of QLogic Corporation.

Seagate is a trademark of Seagate Technology, Inc.

Microsoft is a trademark of Microsoft Corporation.

All other brand and product names are trademarks or registered trademarks of

their respective owners.Document Revision History

Rev. A initial release, 6/22/99

Rev. B, update, 5/24/00 (QL12160L board added)

Rev. C, update, 9/14/01 (QLA12160L board deleted)

Boards Affected

QLA12160 (DC8110402)

Changes Sections Affected

Deleted QLA12160L All

Added 4 GB Addressingand Fast CommandPosting

to host adapter settings A.2.1

Moved SCSI ID, SCSI bus reset, SCSI bus reset

delay, and SCSI termination from host adapter

settings to SCSI bus settings

A.2.1, A.2.3

Deleted Host Adapter and Concurrent Command/

Data from host adapter settings A.2.1

First Printed: June 1999

Printed in U.S.A.

QLogic Corporation, 26600 Laguna Hills Drive, Aliso Viejo, CA 92656

(800) 867-7274 or (949) 389-6000

Get other manuals https://www.bkmanuals.com

DC8151101-00 C Page iii

Table of Contents

Section 1 Introduction

1.1 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.2.1 Mixed Peripheral Support . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Section 2 Hardware Installation

2.1 Preinstallation Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

2.2 What You Need for Installation . . . . . . . . . . . . . . . . . . . . . . . 2-1

2.3 Setting the SCSI Termination . . . . . . . . . . . . . . . . . . . . . . . . 2-2

2.4 SCSI Termination Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

2.5 Installing the Device Activity Light. . . . . . . . . . . . . . . . . . . . . 2-2

2.6 Installation in the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

2.7 Installation Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Section 3 Troubleshooting

3.1 Problems After Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3.2 Hardware Problem Checklist. . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3.3 System Configuration Problem Checklist . . . . . . . . . . . . . . . 3-1

3.4 SCSI Problem Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Appendix A Fast!UTIL

A.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

A.2 Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

A.2.1 Host Adapter Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

A.2.2 SCSI Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

A.2.3 SCSI Bus Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5

A.2.4 Autoconfigure SCSI Devices . . . . . . . . . . . . . . . . . . . . . . A-7

A.2.5 Selectable Boot Settings . . . . . . . . . . . . . . . . . . . . . . . . . A-7

A.2.6 Restore Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . A-8

A.2.7 Raw NVRAM Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8

A.3 Scan SCSI Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8

A.4 SCSI Disk Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8

A.5 Using SCSI-1 Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8

Get other manuals https://www.bkmanuals.com

Table of Contents QLA12160 Hardware Installation Guide

Page iv DC8151101-00 C

Appendix B SCSI Termination

B.1 Setting the SCSI Termination . . . . . . . . . . . . . . . . . . . . . . . B-1

B.2 Termination (Jumpers) for the QLA12160 . . . . . . . . . . . . . . B-1

Appendix C Specifications

FIGURES

Figure Page

2-1 QLA12160 Board Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

B-1 QLA12160 Jumper Termination . . . . . . . . . . . . . . . . . . . . . . . . . B-2

TABLES

Table Page

1-1 SCSI Data Transfer Rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

3-1 Maximum Cable Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

A-1 Host Adapter Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

A-2 SCSI Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

A-3 SCSI Bus Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5

A-4 QLA12160 Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6

C-1 QLA12160 Board Operating Environment . . . . . . . . . . . . . . . . . C-1

C-2 QLA12160 Board Specifications. . . . . . . . . . . . . . . . . . . . . . . . . C-1

Get other manuals https://www.bkmanuals.com

DC8151101-00 C 1-1

Section 1

Introduction

NOTE: This installation guide applies to thefollowing QLogic host adapter boards,

collectively referred to as the QLA12160 board unless otherwise noted:

■QLA12160/33 (DC8110402-06)

■QLA12160/66 (DC8110402-07)

The QLA12160 board (wide, low voltage differential [LVD]), dual port,

Ultra3, 64-bit PCI) contains the ISP12160A/33 or ISP12160A/66 chip.

1.1

Product Description

The QLA12160 board is an intelligent, high-performance, DMA bus master SCSI

hostadapterdesignedforhigh-endsystems.Theintelligenceandperformanceare

derived from the ISP chip, making the QLA12160 board a high performance host

adapter. The ISP chip combines a powerful RISC processor, two SCSI executive

processors (SXPs), and a peripheral component interconnect (PCI) local bus

interface in asingle-chip solution.The QLA12160 board supports bootabledevices

(hard disk drivesand CD-ROM drives) and can be used with tape drivesand other

SCSI devices. Installation of the QLA12160 board is quick and easy.

The QLA12160 board is for use only with UL listed computers that have detailed

instructions for user installation of accessory cards.

The QLA12160 board is designed to operate with multiple data transfer speeds

under SCSI specifications (see table 1-1).

NOTE: Only single-ended and LVD devices (Ultra2 and Ultra3) can be connected

to the QLA12160 board.

Table 1-1. SCSI Data Transfer Rates

SCSI Mode Maximum Data Rate

Narrow (8-bit) Maximum Data Rate

Wide (16-bit)

SCSI (or parallel SCSI) 5 MBps (asynchronous) —

Fast SCSI 10 MBps 20 MBps

Ultra SCSI 20 MBps 40 MBps

Ultra2, LVD SCSI 40 MBps 80 MBps

Ultra3, LVD SCSI 80 MBps 160 MBps

Get other manuals https://www.bkmanuals.com

Features 1 –Introduction

1-2 DC8151101-00 C

TheQLA12160boardsupportsUltra,Ultra2,and Ultra3transferspeeds.Theboard

can connect computers to other computers or to peripheral devices such as

CD-ROM drives, tape drives, and hard disk drives. SCSI allows connecting the

following numbers and types of devices to a single port by daisy chaining:

■15 fast, wide SCSI devices

■15 Ultra2 or Ultra3, LVD SCSI devices

■6 Ultra SCSI devices (QLA12160 board in single-ended mode)

A daisy chain is a series of connections where the first device is connected to the

host adapter board, the second device is connected to the first device, and so on.

A daisy chain can be created either by using a daisy chain cable (one cable with

multiple connectors) or by using multiple cables. Each SCSI device must have a

unique SCSI ID.

Because SCSI allows the computer to use a standard set of commands to

communicate with peripherals, adding a variety of peripherals to your computer

using one host adapter board is easy.

1.2

Features

■Compliance with Intel PCI version 2.2 specification

■Compliance with ANSI X3.131-1994 SCSI-2 standard

■Compliance with ANSI X3T10/1071D SCSI-3Fast-20 standard(Ultra SCSI)

■Compliance with ANSI X3T10/1142D Fast-40 draft (Ultra2 SCSI)

■CompliancewithANSIT10project855D,InformationTechnology—SCSI-3

Parallel Interface (SPI)

■Compliance with ANSI T10 project 1142D, Information Technology—SCSI

Parallel Interface-2 (SPI-2)

■Compliance with ANSI T10 project 1302D, Information Technology—SCSI

Parallel Interface-3 (SPI-3)

■Compliance with U.S. and international safety and emissions standards

■Support for asynchronous and synchronous transfer modes

■Support for synchronous SCSI data transfer rates:

❑Ultra3, LVD SCSI (160 MBps)

❑Ultra2, LVD SCSI (80 MBps)

❑Ultra SCSI wide (40 MBps)

❑Ultra SCSI narrow (20 MBps)

❑Fast SCSI wide (20 MBps)

❑Fast SCSI narrow (10 MBps)

❑SCSI narrow (5 MBps)

■Support for single-ended mode

Get other manuals https://www.bkmanuals.com

1 –Introduction Features

DC8151101-00 C 1-3

■Support for LVD mode

■Support for up to 30 LVD SCSI devices (15 per channel)

■Support for logical unit numbers (LUNs) 0–15

■Support for bus master DMA

■Fast!UTIL BIOS utility to customize the configuration parameters on the

QLA12160 board and attached drives

■Active termination

■Active negation

1.2.1

Mixed Peripheral Support

■Support for hard disk, removable disk, optical disk, scanner, tape drive,

CD-ROM, and other SCSI devices

■Simultaneous mixed-peripheral configurations support

■Bootable device support for disk and CD-ROM

■DOSadvancedSCSI programminginterface(ASPI)managerfordisk,tape,

and other devices

Get other manuals https://www.bkmanuals.com

Features 1 –Introduction

1-4 DC8151101-00 C

Get other manuals https://www.bkmanuals.com

BC8151101-00 C 2-1

Section 2

Hardware Installation

2.1

Preinstallation Procedures

Before installing your QLA12160 board, take the time to read this instruction guide.

CAUTION!

■Your computer, the QLA12160 board, and each SCSI device must

be configured properly for optimum performance. Refer to the

appropriate documentation to configure your computer and SCSI

devices.

■PayparticularattentiontotheSCSIIDassignment.TheQLA12160

board is set at the factory for SCSI ID 7. The QLA12160 board

and each SCSI device attached to the board must have

different SCSI IDs.

■The QLA12160 board contains parts that can be damaged by

electrostatic discharge (ESD). Before handling the QLA12160

board, use standard methods to discharge static electricity. Keep

the QLA12160 board in the antistatic bag until you are ready to

installit.Placetheboardonthebagwhenyouexamineorconfigure

it. Retain the bag for future use.

2.2

What You Need for Installation

Before you install the QLA12160 board in your computer, you need the following:

■A screwdriver (usually a Phillips #1)

■One or more of the following cables:

❑Internal narrow (68-pin to 50-pin)

❑Internal wide (68-pin to 68-pin)

❑External narrow (68-pin very high density cable [VHDC] to 50-pin)

❑External wide (68-pin VHDC)

Get other manuals https://www.bkmanuals.com

Setting the SCSI Termination 2 –Hardware Installation

2-2 BC8151101-00 C

Figure 2-1 identifies the QLA12160 board components referenced throughout this

section.

Figure 2-1. QLA12160 Board Layout

2.3

Setting the SCSI Termination

Termination for the QLA12160 board is set automatically in most cases. You can

change the termination using the Fast!UTIL software (see section A.2.3).

Termination for the QLA12160 board also can be set using jumpers (see

section B.2).

2.4

SCSI Termination Power

The QLA12160 board suppliestermination power to itself and to theSCSI bus.The

circuit is protected by a self-restoring fuse.

2.5

Installing the Device Activity Light

If the SCSI disk is assigned as drive C (boot drive), you can connect the device

activity light on thefront panelof the PC to indicate boot drive activity. Connect the

J6J7J8

SCSI LED

ISP CHIP

3333

DC8110402

Get other manuals https://www.bkmanuals.com

Otros manuales para QLA12160

Tabla de contenidos

Otros manuales de Adaptador de Qlogic

Qlogic

Qlogic InfiniPath Manual de usuario

Qlogic

Qlogic SANblade QLA2342 Manual de usuario

Qlogic

Qlogic QL45212 Manual de usuario

Qlogic

Qlogic FastLinQ 3400 Series Manual de usuario

Qlogic

Qlogic 3400 Series Manual de usuario

Qlogic

Qlogic QConvergeConsole CLI 2400 Series Manual de usuario

Qlogic

Qlogic BR-1020 Manual de usuario

Qlogic

Qlogic 8400 Series Manual de usuario

Qlogic

Qlogic QLogic Fibre Channel Switch Manual de usuario

Qlogic

Qlogic 3000 Series Manual de usuario

Qlogic

Qlogic QLA200 HBA Manual de usuario

Qlogic

Qlogic QLE7280 Manual de usuario

Qlogic

Qlogic InfiniPath QLE7140 Manual de usuario

Qlogic

Qlogic QLE2740L-DEL Manual de usuario

Qlogic

Qlogic QLE2360 Manual de usuario

Qlogic

Qlogic QLA234 Series Manual de usuario

Qlogic

Qlogic SANblade QEM2462 Manual de usuario

Qlogic

Qlogic 8200 Series Manual de usuario

Qlogic

Qlogic BR-815 Manual de usuario

Qlogic

Qlogic InfiniPath QHT7140 Manual de usuario

Qlogic

Qlogic QLE7240 Manual de usuario

Qlogic

Qlogic QLE2460 Manual de usuario

Qlogic

Qlogic QLE3142-SR-CK Manual de usuario

Qlogic

Qlogic SANblade QEM2462 Manual

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
