Pyle Pure Clean SLPRWAS58 Manual de usuario
SLPRWAS58
YLQ27SC-130B
www.PyleUSA.com
SAVE THESE INSTRUCTIONS
Please read and comply with these original instructions prior to the initial operation of your
appliance and store them for later use or subsequent owners.
Apart from the notes contained herein the general safety provisions and rules for the prevention of
accidents of the legislator must be observed.
Warnings and notes that are attached on the appliance provide important notes for the safe operation.
Hazard levels
DANGER
Pointer to immediate danger, if not avoided, which leads to severe injuries or death.
WARNING
Pointer to a possibly dangerous situation, if not avoided, which can lead to severe injuries or death.
CAUTION
Pointer to a possibly dangerous situation, if not avoided, which can lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation, which can lead to property damage.
Electric Components
DANGER
Risk of electric shock.
Never touch the main plug and the socket with wet hands.
Check the power cord with main Plug for damage prior to every use. Do not use the machine if the
supply cord or important parts of the machine are damaged, e.g. safety devices, high pressure hoses,
trigger gun.
All current-conducting parts in the working area must be protected against jet water.
The main plug and the coupling of an extension cable must be watertight and must never lie in water.
Moreover, the coupling may never lie on the ground. The use of cable reels that ensure that the sock-
ets are at least 60 mm above the ground is commended.
Make sure that the power cord or extension cable is not damaged by running over, pinching, dragging
or the like. Protect the power cords from heat, oil, and sharp edges.
Always switch off the main switch when leaving the appliance unattended.
WARNING
The appliance may only be connected to an electric supply that has been installed by an electrician in
accordance with IEC 60364.
The appliance may only be connected to alternate current. The voltage must correspond with the type
plate of the appliance.
For safety reasons, we recommend that you operate the appliance only via a residual current device
(max. 30mA).
An unsuitable electrical extension cable can be hazardous. Only use an electrical extension cable
which has been approved and labeled for this purpose and has an adequate cable cross-section
outdoors: 1 - 10 m: 1.5 mm 2;10 - 30 m: 2.5 mm2
Always fully unreel the extension cable from the cable drum.
Substandard electrical extension cable can be hazardous.
www.PyleUSA.com
www.PyleUSA.com
Safe Handling
DANGER
The user must use the appliance as intended. The person must consider the local conditions and must
pay attention to other people in the vicinity when working with the appliance.
Check important components, such as high pressure hose, hand spray gun and safety installations,
for damage prior to every operation. Immediately replace damaged components. Do not operate
appliance with damaged components.
The appliance has been designed for use with the cleaning agent supplied or recommended by the
manufacturer. The use of the other cleaning agents or chemicals may adversely affect the safety of the
appliance.
High-pressure jets can be dangerous if subject to misuse. The jet must not be directed at people, live
electrical equipment or the machine itself.
Do not direct the jet against yourself or others in order to clean clothes or foot-wear.
Do not use the appliance within range of people unless they wear protective clothing.
Wear appropriate Personnel Protection Equipment (PPE) while operating the appliance.
WARNING
The appliance must not be operated by children or untrained personnel.
This appliance is not intended for use by people (including children) with reduced physical, sensory or
mental capacities, or lacking experience and knowledge.
Children must not play with this appliance.
Supervise children to prevent them from playing with the appliance.
Create stability for the appliance prior to any work on or with the appliance to prevent accidents or
damage.
The water jet that is emitted from the high pressure nozzle results in a repulsion power acting on the
hand spray gun. Make sure that you have a firm footing and are also holding the hand spray gun and
spray lance firmly.
Never leave the appliance unattended as long as it is in operation.
ATTENTION
In case of extended breaks, turn the main switch off or pull the main plug.
Do not operate the appliance at temperatures below 0ºC
www.PyleUSA.com
Other Risks
Even if you are operating this product in accordance with all the safety requirements, potential risks of
injury and damage remain. The following dangers can arise in connection with the structure and
design of this product:
•Health defects resulting from vibration emission if the product is being used over long periods of
time or not adequately managed and properly maintained.
•Danger of injury and property damage caused by flying objects.
•Injuries and damage to property due to broken accessories or the sudden impact of hidden
objects during use.
Safety Devices
CAUTION
Safety installations serve the protection of the user and may not be modified or by past.
GROUND FAULT CIRCUIT INTERRUPTER
The appliance is provided with a ground-fault circuit-interrupter (GFCI) built into the plug of the pow-
er-supply cord. This device provides additional protection from the risk of electric shock. Should
replacement of the plug or cord become necessary, use only identical replacement parts that include
GFCI protection.
Power switch
The appliance switch prevents unintentional operation of the appliance.
Lock trigger gun
This locks the lever of the trigger gun and prevents the inadvertent start of the appliance. Overflow
valve with water that has flowed through backflow preventers is considered to be non-potable.
Pressure switch
If the lever on the trigger gun is released the pressure switch turns off the pump, the high pressure jet
is stopped. If the lever is pulled the pump is turned on again.
Motor protection switch
The motor protection switches off the device if the power consumption is high.
www.PyleUSA.com
Even if you are operating this product in accordance with all the safety requirements, potential risks of
injury and damage remain. The following dangers can arise in connection with the structure and
design of this product:
•Health defects resulting from vibration emission if the product is being used over long periods of
time or not adequately managed and properly maintained.
•Danger of injury and property damage caused by flying objects.
•Injuries and damage to property due to broken accessories or the sudden impact of hidden
objects during use.
Safety Devices
CAUTION
Safety installations serve the protection of the user and may not be modified or by past.
GROUND FAULT CIRCUIT INTERRUPTER
The appliance is provided with a ground-fault circuit-interrupter (GFCI) built into the plug of the pow-
er-supply cord. This device provides additional protection from the risk of electric shock. Should
replacement of the plug or cord become necessary, use only identical replacement parts that include
GFCI protection.
Power switch
The appliance switch prevents unintentional operation of the appliance.
Lock trigger gun
This locks the lever of the trigger gun and prevents the inadvertent start of the appliance. Overflow
valve with water that has flowed through backflow preventers is considered to be non-potable.
Pressure switch
If the lever on the trigger gun is released the pressure switch turns off the pump, the high pressure jet
is stopped. If the lever is pulled the pump is turned on again.
Motor protection switch
The motor protection switches off the device if the power consumption is high.
CAUTION
Mind the weight of the appliance when selecting the storage location and during transport to prevent
accidents or injuries.
Several hours of continuous use of the appliance can lead to numbness in the hands in rare cases.
→Wear gloves.
→Keep hands warm.
→Take breaks at regular intervals. Working with detergent.
WARNING
The improper use of detergents can cause severe injuries or oxidation.
Store cleaning agent away out of children’s reach.
Discharge residual pressure before disconnecting the hose from the product.
Check before each use, and at regular intervals, that all metal fasteners are tight and the product’s
components are in good condition; inspect for broken or worn parts.
Be aware of kick-back: Hold with Both Hands.
SERVICING OF A DOUBLE-INSULATED APPLIANCE
In a double-insulated product, two systems of insulation are provided instead of grounding.
Grounding means are not provided for a double - insulated product, nor should grounding means be
added to the product. Servicing a double-insulated product requires extreme care and knowledge of
the system, and should only be done by qualified service personnel. Replacement parts for a dou-
ble-insulated product must be identical to the original parts. A double-insulated product is marked with
the words “Double Insulation” or “Double Insulated”.
www.PyleUSA.com
CAUTION
Wear protective clothing and safety goggles to protect against splash back containing water or dirt.
During the use of high-pressure cleaners aerosols can develop. Inhaling aerosols can cause health
damage.
—Depending on the application, completely shielded nozzles (e.g. surface cleaner) that significantly
reduce the emission of aqueous aerosols can be used for high-pressure cleaning.
—The use of such shielding is not possible with all applications.
Symbols on the machine
The high pressure jet must not be directed at persons, animals, live electrical equipment
or at the appliance itself.
The appliance must not be directly connected to the public drinking water network.
For protection against injury, wear ear defenders and safety goggles.
Wear safety gloves during use to protect hands
Wear non-slip footwear that will protect your feet and improve your footing on slippery
surfaces.
Personal Protective Equipment
www.PyleUSA.com
Proper Use
Use this pressure washer for private households only:
If connection is made to a potable water system, the system shall be protected against backflow.
This high pressure cleaner is designated with a rated input current. The intended use of this product
covers the cleaning of vehicles, buildings, terraces, facades and garden equipment using clean water
and biodegradable chemical detergents. Likewise the product can be used to clean paving slabs or
rain gutters.
This product may not be used to clean clothing, shoes and other textiles. The water jet should not be
directed against persons, animals, any electrical equipment or on the product itself. Do not flush any
objects which contain health hazardous materials. The product must not be run with inflammable,
explosive and toxic liquids.
For safety reasons it is essential to read the entire instruction manual before first operation and to
observe all the instructions there in.
Description of the Appliance
1. Handle
2. Adjust switch OFF/ON
3. Power cord hook
4. Front case
5. Power cord
6. Water inlet
7. High-pressure hose hook
8. Trigger gun
9. High-pressure hose
10. Spray wand
11. Trigger gun holder
12. Detergent bottle
13. Rear case
14. Water outlet
15. Wheel
www.PyleUSA.com
Technical Specifications
Voltage
Frequency
Input Current
Protection Class
Degree of protection
Rated pressure
Max. permissible pressure
Max. rate flow
Max. inlet pressure:
Weight
120V 〜
60Hz
14A
Double insulation
IPX5
1400PSI
1900PSI
1.76GPM
0.7MPa
18.95 lbs.
Assembly
Mount loose parts delivered with appliance prior to start-up.
1. Install the handle into position with screws.
2. Install the high-pressure hose hook into position with screws.
www.PyleUSA.com
3. Slide the power cord hook into the right position of the unit.
4. Install the spray wand.
• Fit the spray wand into the gun and rotate it until the two parts are completely locked.
5. Connect the high pressure hose to the trigger gun.
• Connect the sliver end of the high-pressure hose to the trigger gun and twist the nut as indicated to
secure the connection.
