Pyle PBMSPG148 Manual de usuario

PBMSPG148

Wireless BT Portable Speaker Radio System

1 2 3 4 5 6

7 8 9 10 11

www.PyleUSA.com

2

Please take the time to read this manual carefully before you begin using

your new device. Any content revision of the manual won't declare again,

and we are not responsible for consequence caused by fault or oversight of

this manual.

FEATURES:

• Compact Boom Box Stereo Style

• Portable Travel-Friendly Speaker Design

• Digital Streaming FM Radio

• Built-in Rechargeable Battery

• MP3 Digital Audio File Playback

• Ported Enclosure for Extended Bass

• Full Range Stereo Sound Reproduction

• Rugged & Durable 'Super Tube' Speaker Housing

INSTRUNCTION:

1. MODE (Wireless BT switch,

USB disk, FM and AUX-IN state)

2. PREVIOUS/VOLUME DOWN

3. PLAY/PAUSE

4. DIGITAL DISPLAY

5. NEXT/VOLUME UP

6. EQ

7. MIC JACK

8. USB PORT

9. AUX IN JACK

10. DC 5V Charging Port

11. OFF/ON

www.PyleUSA.com

3

EQ Introduction:

This unit oers 2 dierent kinds of sound eect, EQ in turn to be BASS, SITE.

Playing music from USB disk

1. Turn the power button to“ON”.

2. Plug the USB disk into the USB socket. The audio les on the USB disk will start

to play automatically.

3. Short press PREVIOUS or NEXT button on the device to select songs you like.

4. Press and hold PREVIOUS or NEXT button to adjust volume down and up.

5. Short press PLAY/PAUSE button to play or pause the music.

6. Short press“EQ” to choose dierent style you like such as BASS or SITE.

7. Please turn the Power button to “OFF” if not in use.

Wireless BT Streaming:

1. Turn the power button to“ON”.

2. Activate Wireless BT of mobile phone and search for device name“PyleUSA”

then connect it.

3. Play the music from your mobile phone and enjoy.

4. Short press PREVIOUS or NEXT button on the device or on Mobile phones to

select songs you like. Press and hold PREVIOUS or NEXT button to adjust

volume down and up or adjust the mobile phones’ volume.

5. Press PLAY/PAUSE button on the device or on Mobile phones to play/stop the

music.

6. Short press“EQ” to choose dierent style you like such as BASS or SITE.

7. Please turn the Power button to “OFF”while without use.

Songs will play automatically after starting up.

FM Radio:

1. Turn the power button to“ON”, press the “MODE” button to FM radio state.

2. The audio cable provided can be used as antenna, please insert the audio cable

to get the best FM signal before using.

3. Short press“PLAY/PAUSE” button to auto search FM Channel from low level

www.PyleUSA.com

4

frequency to the high level search and store it automatically; During searching,

the RGB light won’t light on, will light on once searching stops, and there is no

sound during searching.

4. Short press PREVIOUS or NEXT button to switch the stored FM channel.

5. Short press“EQ” to choose dierent style you like such as BASS or SITE.

AUX-IN:

• Use the supplied audio cable to connect “LINE OUT”of the music players like

Phones/MP3/MP4 to the “AUX IN” of this speaker;

• Press the “MODE” button to switch to AUX IN state;

• Short press“PLAY/PAUSE” button to mute, short press again to relieve;

• Short press“EQ” to choose dierent style you like such as BASS or SITE;

Microphone Input:

This product has one Microphone input. Just plug the 6.5MM microphone jack

then you can use.

TWS Function:

1. Turn ON two identical speakers you want to pair, please note that they must

have the same BT paring name, both under BT mode.

2. Only need to set up one of the two units before paring with your device.

3. Then press and hold“PLAY/PAUSE” button for around 5 seconds till show “BU”

on the digital display of the speaker you set up.

4. Then connect the BT paring name of the two machines (only one BT name will

appear in your device), then your two speakers can play music.

Remark:

1. Press the MODE button to switch for dierent modes, the order is Wireless BT,

USB disk, FM radio and AUX-IN.

2. Turn the power button to“OFF”to cut o the power supply while without use.

www.PyleUSA.com

5

How to charge:

1. Power o the unit, put the provided charging cable into the Micro charging slot

of the unit, connect the other end to your PC or other charger with DC 5V

output, the red charging indicator will keep blinking and will be o once fully

charged. Charge time should be 7-8 hours.

2. When the unit is on, the light is always red, it works as an external input power

indicator, and the battery icon on digital display will work as charging indicator

in progressive beat, till fully charged, the icon will stop beating.

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]

This product can expose you to a chemical or group of checmicals, which

may include ”Cadmium (Cd)” which is known in the state of California to

cause cancer, birth defects, or other reproductive harm. For more info, go

to https://www.p65warnings.ca.gov/.
