Pyle Pro PCA4 Manual de usuario
www.pyleaudio.com
PCA4
2x120W Max Stereo Power Amplifier
with AUX CD/MP3 Input
1 - Pyle Pro PCA4 Manual
FEATURES AND CONTROLS
Pyle Pro PCA4 Manual - 2
gives you the power and versatility you need in a professional sound system.
Its wide frequency response make it suitable for amplifying music or vocal
program material.
The front located 3.5mm jack allows you to connect the input of various of
MP3 devices conveniently.
Your new Pyle Pro PCA4 Stereo Power Amplifier
3 - Pyle Pro PCA4 Manual
FEATURES AND CONTROLS
(1) Blue LED Output Level Display
(2) Power On/Off and LED Indicator
Main power switch, the indicator lights when the amplifier is turned on.
(3) CD/MP3 3.5mm AUX Input Jack (FRONT)
Lets you easily connect the computerized MP3 Device (player) sources, such as
PC (CD ROM), Laptop, Walkman, iPod, and Cell Phone.
(4) MASTER Volume Control
Lets you control the overall volume level.
(5) BASS and TREBLE Controls
Allows you to boost or attenuate bass and treble for the desired sound.
(6) LINE RCA Input
Lets you connect most high level audio sources such as CD player, tape deck,
tuner, camcorder, or VCR. It is compatible with the computerized devices (MP3)
via 3.5mm to RCA Converter.
(7) Push Type Speaker Terminal
Lets you easily connect speaker wires directly to the amplifier. The speaker
impedance can be ranged from 4 to 8 Ohms for the general stereo output.
The total speaker impedance must be at least 4-Ohm per channel at stereo mode.
(8) 110/220 Voltage Selector
This amplifier has selectable input voltage from 110V/60Hz (the standard
in USA and CANADA) to 220V/50Hz (for EUROPEAN operation). Please make
sure the switch is in the proper position before operating, otherwise,
the severe damage will be incurred and not covered by the warranty.
(9) Replaceable Power Fuse
The amplifier uses a fuse for protection against surges and short circuit.
If the amplifier suddenly turns off and will not turn on, check the fuse
and if necessary replace it with a 1.5-amp, 250-volt, fast-acting, 5x20mm
fuse (not supplied).
CONNECTION DIAGRAM
Pyle Pro PCA4 Manual - 4
Specifications are typical; individual units might vary.
Specifications are subject to change and improvement without notice.
Specifications
5 - Pyle Pro PCA4 Manual
Output Power, 2 channels driven
4-Ohm, 1 kHz, 1% THD .............................................................................. 20Wx2
4-Ohm, 1 kHz, 10% THD ............................................................................. 32Wx2
Max Power ................................................................................................. 120Wx2
Total Harmonic Distortion, 1 kHz Rated Power ................................................ 0.3%
Input Sensitivity, 1 kHz, 4-Ohm Rated Power
LINE ..................................................
..........................................................
220mV
CD ............................................................................................................... 220mV
Frequency Response ............................................................
...............
20Hz-20kHz
Signal to Noise Ratio, 1 kHz, 4-Ohm Rated Power
LINE ..................................................................
.............................................
75dB
CD .................................................................................................................. 75dB
Tone Controls
BASS ............................................................................................. +/-10dB, 100Hz
TREBLE ......................................................................................... +/-10dB, 10kHz
Power Requirement ................................................. 120V AC 60Hz/230V AC 50Hz
Power Fuse ......................................................... 1.5 A, 250V fast-acting, 5x20mm
Dimensions, inches (mm) WxHxD ..................... 8.27 x 2.72 x 5.39 (210 x 69 x 137)
Weight, lbs (kg) ........................................................................................ 5.32(2.42)
Pyle Pro PCA4 Manual - 6
PYLE PRO AMPLIFIER
Your Pyle Pro Amplifier is an example of superior design and craftsmanship.
The following suggestions will help you care for your amplifier so you can
enjoy years of use:
Keep the amplifier dry. If it gets wet, wipe immediately.
Use the amplifier only in well-ventilated installations.
Handle the amplifier gently and carefully - do nto drop!
Keep the amplifier away from dust adn dirt.
Wipe occasionally with a damp cloth to keep it looking new.
Do not use harsh chemicals, solvents or detergents!
7 - Pyle Pro PCA4 Manual
