Pulsar VD84 Manual de usuario
CAL. VD84, VD87
ANALOGUE QUARTZ
ENGLISH
lTime display:
Hour and minute hands with small second hand
24 hour hand (VD84 only)
lCalendar display:
Date hand
Retrograde day of the week hand
English
2
DISPLAY AND CROWN/BUTTONS
c: Second click
b: First click
a: Normal position
CROWN
Hour hand
Minute hand
Small second hand
Day hand
(Retrograde)
Date hand
a b c
24 hour hand
VD84
c: Second click
b: First click
a: Normal position
CROWN
Hour hand Minute hand
Small second hand
Day hand
(Retrograde)
Date hand
a b c
VD87
English
3
English
4
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2Turn Crown clockwise while pressing it
lightly until tight.
Unlocking the crown
English
5
TIME/CALENDAR SETTING
DAY AND TIME SETTING
CROWN
1Pull out to second click
when Small second hand is
at the 12 o’clock position.
2Turn clockwise to advance
Hour and Minute hands
until Day hand is set to the
desired day of the week.
3Turn to set the time.
4Push back completely in
accordance with a time
signal.
1
4
2
3
Small second hand
Day hand
(Retrograde) 24 hour hand
(VD84 only)
English
6
DATE SETTING
CROWN
1 Pullouttorstclick.
2Turn counterclockwise
to set Date hand to the
desired date.
3Push in.
1
3
2
Date hand
English
7
NOTES ON OPERATING THE WATCH
DAY AND TIME SETTING
lThe retrograde day of the week can be set more quickly by following procedures:
(1) Pull out the crown to second click position for day adjustment.
(2) Turn the crown clockwise until the day advance by one increment.
(3) Turn the crown counterclockwise until the center hands come at or before
12:00 position.
(4) Turn the crown clockwise again until the day advance by one increment.
(5) By repeatedly perform the steps (3) & (4), the day hand can be adjusted to the
desired position more quickly.
lWhen adjusting the day hand, turn the crown slowly.
lWhen setting the time, check that AM/PM is set correctly.
lWhen setting the minute hand, advance it 4 to 5 minute ahead of the desired time
and then turn it back to the exact minute.
lThe 24 hour hand (or 24 hour rotating wheel) turns full circle in one day (VD84 only).
English
8
BATTERY CHANGE
Battery life : Approx. 3 years
Battery : SEIKO SR626SW
l
As the battery is inserted at the factory to check the function and performance of
the watch, its actual life once in your possession may be less than the specified
period.
lWhen the battery expires, be sure to replace it as soon as possible to prevent any
malfunction.
lWe recommend that you contact an AUTHORIZED PULSAR DEALER for battery
replacement.
lDo not set the date between 10:00 p.m. and 2:00 a.m. Otherwise, it may not turn
properly.
lWhile setting the date hand, check that it moves properly in one-day increments.
lIt is necessary to adjust the date on the first day after a 30-day month and February.
DATE SETTING
English
9
WARNING
lDo not remove the battery from the watch.
lIf it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
lNever short-circuit, tamper with or heat the battery, and never ex-
pose it to re. The battery may burst, become very hot or catch re.
CAUTION
l The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.
English
10
TO PRESERVE THE QUALITY OF YOUR WATCH
WATER RESISTANCE
lNon-water resistant
lWater resistance (5 bar)*
If “WATER RESISTANT 5
BAR” is inscribed on the
case back, your watch is
designed and manufactured
to withstand up to 5 bar and is suitable
for swimming, yachting and taking a
shower.
If “WATER RESISTANT 10
BAR”, “WATER RESISTANT 15
BAR” or “WATER RESISTANT
20 BAR” is inscribed on the
lWater resistance (10 bar/15 bar/20 bar)*
case back, your watch is designed and
manufactured to withstand up to 10 bar/15
bar/20 bar and is suitable for taking a bath,
shallow diving, but not for scuba diving.
We recommend that you wear a PULSAR
Diver’s watch for scuba diving.
If “WATER RESISTANT” is
not inscribed on the case
back, your watch is not water
resistant, and care should be
If “WATER RESISTANT” is
inscribed on the case back,
your watch is designed and
manufactured to withstand
lWater resistance (3 bar)
up to 3 bar, such as accidental contact
with splashes of water or rain, but it is not
designed for swimming or diving.
taken not to get it wet as water may damage
the movement. If the watch becomes wet,
we suggest that you have it checked by an
AUTHORIZED PULSAR DEALER or SERVICE
CENTER.
