PTZOptics ZCAM G2 Manual de usuario

Please check PTZOPTICS.com for the most up to date version of this document Rev 1.2 8/20

PTZOptics EPTZ ZCAM G2

User Manual

Model No: PTEPTZ-ZCAM-G2

V1.2

(English)

Page i of 39

Rev 1.2 7/18

Preface

Thank you for purchasing a PTZOptics Camera. This manual introduces the function, installation and operation of the camera.

Prior to installation and usage, please read the manual thoroughly.

Precautions

This product can only be used in the specified conditions in order to avoid any damage to the camera:

•Don’t subject the camera to rain or moisture.

•Don’t remove the cover. Removal of the cover may result in an electric shock, in addition to voiding the

warranty. In case of abnormal operation, contact the manufacturer.

•Never operate outside of the specified operating temperature range, humidity, or with any other power supply

than the one originally provided with the camera.

•Please use a soft dry cloth to clean the camera. If the camera is very dirty, clean it with diluted neutral

detergent; do not use any type of solvents, which may damage the surface.

Note

This is an FCC Class A Digital device. As such, unintentional electromagnetic radiation may affect the image quality of TV in

a home environment.

Warranty

PTZOptics includes a limited parts & labor warranty for all PTZOptics manufactured cameras.

Warranty lengths are shown below. The warranty is valid only if PTZOptics receives proper

notice of such defects during the warranty period. PTZOptics, at its option, will repair or

replace products that prove to be defective. PTZOptics manufactures its hardware products

from parts and components that are new or equivalent to new in accordance with industry

standard practices.

Serial Number

Warranty

I1E1231999 and before

3 year warranty

I1F0101001 and after

5 year warranty

Page ii of 39

Rev 1.2 8/20

Table of Contents

Supplied Accessories…………………………………………………………………………………………………….

Notes……………………………………………………………………………………………………………………...

Features…………………………………………………………………………………………………………………..

Back of the Camera………………………………………………………………………………………………………

Serial Communication Control…………………………………………………………………………………………...

VISCA Command List……………………………………………………………………………………………………

Menu Settings…………………………………………………………………………………………………………….

Exposure…………………………………………………………………………………………………………….

Color………………………………………………………………………………………………………………...

Image………………………………………………………………………………………………………………..

Noise Reduction…………………………………………………………………………………………………….

Setting……………………………………………………………………………………………………………….

Information………………………………………………………………………………………………………….

Restore Default……………………………………………………………………………………………………...

Network Connection……………………………………………………………………………………………………...

Setting up a Network Video Stream………………………………………………………………………………………

Additional Network Info…………………………………………………………………………………………….

Camera Web Interface…………………………………………………………………………………………………….

Live………………………………………………………………………………………………………………….

Directional Arrows………………………………………………………………………………………………….

Video………………………………………………………………………………………………………………..

Image………………………………………………………………………………………………………………..

Audio………………………………………………………………………………………………………………..

System………………………………………………………………………………………………………………

Network……………………………………………………………………………………………………………..

Information………………………………………………………………………………………………………….

Language……………………………………………………………………………………………………………

Network Camera Control Protocol……………………………………………………………………………………….

Photobooth Functionality………………………………………………………………………………………………...

Maintenance and Troubleshooting………………………………………………………………………………………..

Page 1 of 39

Rev 1.2 7/18

Supplied Accessories

When you unpack your camera, check that all the supplied accessories are included:

⚫Camera ................................. 1

⚫AC Power Adaptor ............... 1

⚫Quick Start Guide................. 1

Notes

⚫Electrical Safety

Installation and operation must be in accordance with national and local electric safety standards. Do not use any power

supply other than the one originally supplied with this camera.

⚫Polarity of power supply

The power supply output for this product is 12VDC with a maximum current supply of 1A.

Polarity of the power supply plug is critical and is as follows.

⚫Handling

◼Avoid any stress, vibration, or moisture during transportation, storage, installation and operation.

◼Do not expose the camera to any corrosive solid, liquid, or gas to avoid damage to the casing or components.

◼Never power camera on before installation is complete.

⚫Do not dismantle the camera

◼The manufacturer is not responsible for any unauthorized modification or dismantling.

Page 2 of 39

Rev 1.2 8/20

Features

•Image Sensor

oPanasonic 1/2.5” inch HD CMOS Sensor

oFull 1920x1080p HD Resolutions up to 30 frames per second

o2D & 3D noise reduction with our latest “low noise CMOS sensor”

o0.5 Lux @ F1.8 AGC ON

o104° Field of View

•Video Outputs

oSimultaneous IP & Dual 3G-SDI output capabilities

oTwo (2) 3G-SDI High Definition Video Output up to 30 frames per second

oH.264, H.265 & MJPEG IP streaming output (dual stream) up to 30 frames per second

•Control of EPTZ and Settings

oPTZOptics VISCA over IP

oRS485 remote camera control interface

oWeb-based IP remote camera control

oButton controls on back of camera

▪Hold left on Menu Navigation button for 5+ seconds to toggle Dynamic or Static IP addressing.

▪Hold up on Menu Navigation button for 5+ seconds to Zoom In.

▪Hold down on Menu navigation button for 5+ seconds to Zoom Out.

•Installation

oStandard 1/4-20 female thread for camera mounting (2 on top, 2 on bottom)

oPower over Ethernet – Supports PoE 802.3af

o12VDC 1A Power Supply Provided for non-PoE infrastructure

•Warranty

o3-year warranty

Page 3 of 39

Rev 1.2 8/20

Product Specifications

Model

PTEPTZ-ZCAM-G2

Type

PTZOptics 3G-SDI HD 1080p Camera

Features

Video System

1080p-30/25, 720p-30/25

Sensor

Panasonic 1/2.5", CMOS, Effective Pixels: 8.51M

Scanning Mode

Progressive

Lens

F=2.5mm, F1.8 – F2.8

Minimal Illumination

0.5 Lux (@F1.8, AGC ON)

Shutter

1/30s - 1/10000s

White Balance

Auto, Indoor, Outdoor, One-Push, Manual, VAR

Backlight Compensation

Support

Digital Noise Reduction

2D & 3D Digital Noise Reduction

Video S/N

≥55dB

Horizontal Angle of View

42° ~ 104°

Vertical Angle of View

25° ~ 72°

Image Flip

Yes

Image Mirroring

Yes

Number of Presets

255

Preset Accuracy

0.1°

Video coding standards

H.264, H.265, MJPEG

Video Freeze

Yes

Face Detection

Via Future Firmware Update

Input/Output

HD Output

2x SDI (3G-SDI), BNC female

1x RJ45 IP 10/100 Ethernet Port

Network Interface and Output

1x RJ45: 10M/100M Adaptive Ethernet port

Audio Input

1x 3 pin phoenix port audio interface, LINE IN (embedded on IP Stream only) (Unbalanced stereo)

Control Input / Output

1x RS-485: 2pin phoenix port, Max Distance: 1200m, Protocols: VISCA/Pelco-D/Pelco-P

IP Video Features

Video Compression

H.265 / H.264 / M-JPEG

Video Stream

Three (3) IP Video Output Streams Available

First Stream Resolution

1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360

Second Stream Resolution

3840x2160@15, 1920x1080, 1280x720, 1024x576, 720x576 (50Hz), 720x480 (60Hz), 720x408,

640x360, 480x270, 320x240, 320x180

Third Stream Resolution

1024x576, 960x540, 720x576 (50Hz), 720x480 (60Hz), 720x408, 640x360, 480x270, 320x240,

Page 4 of 39

Rev 1.2 8/20

320x180

Video Bit Rate

32Kbps ~ 102400Kbps

Bit Rate Type

Variable Rate, Fixed Rate

Frame Rate

50Hz: 1fps ~ 25fps, 60Hz: 1fps ~ 30fps

Audio Compression

AAC

Audio Bit Rate

48Kbps, 64Kbps, 96Kbps, 128Kbps

Support Protocols

TCP/IP, HTTP, RTSP, RTMP, DHCP, Multicast, etc.

General Specifications

Power Connector

JEITA type (DC IN 12V) or RJ45 via PoE 802.3af

Input Voltage

12VDC (10.8 - 13.0V DC)

Current Consumption

0.3A (Max)

Operating Temperature

14°F - 104°F [-10°C ~ 40°C]

Storage Temperature

-40°F - 140°F [-40°C ~ 60°C]

Power Consumption

6W (Max)

MTBF

>30000h

Dimensions (w x h x d) in.

2.8” x 2.4” x 5.6” (6.3” including SDI)

Dimensions (w x h x d) mm.

72mm x 60mm x 143mm (162mm including SDI)

Weight

1.1 lbs. [0.50 kg]

Boxed Weight

2.0 lbs [0.90 kg]

Page 5 of 39

Rev 1.2 8/20

Back of the Camera

1. DC12V Power Jack 5. RJ45 Network Connection

2. USB 2.0 connection (Future use) 6. Power LED Indicator

3. Phoenix Connector (RS485 & audio) 7. 3G-SDI Video Output 2 (EPTZ View)

4. Menu Navigation Buttons 8. 3G-SDI Video Output 1 (Full View)

Page 6 of 39

Rev 1.2 8/20

Serial Communication Control

In default working mode, the camera is able to connect to a VISCA controller with an RS485 serial interface.

➢RS485 Communication Control

The camera can be controlled via RS485, Half-duplex mode, with support for VISCA, Pelco-D or Pelco-P protocol.

The parameters of RS485 are as follows:

Baud rate: 2400, 4800 or 9600 bps.

Start bit: 1 bit.

Data bit: 8 bits.

Stop bit: 1 bit.

Parity bit: none.

Page 7 of 39

Rev 1.2 8/20

VISCA Command List

Part 1: Camera-Issued Messages

ACK/Completion Message

Command

Function

Command Packet

Comments

ACK/Completion

Messages

ACK

z0 4y FF

(y: Socket No.)

Returned when the command is accepted.

Completion

z0 5y FF

(y: Socket No.)

Returned when the command has been executed.

Error Messages

Command

Function

Command Packet

Comments

Error Messages

Syntax Error

z0 60 02 FF

Returned when the command format is different

or when a command with illegal command

parameters is accepted.

Command Buffer Full

z0 60 03 FF

Indicates that two sockets are already being used

(executing two commands) and the command

could not be accepted when received.

Command Canceled

z0 6y 04 FF

(y: Socket No.)

Returned when a command which is being

executed in a socket specified by the cancel

command is canceled. The completion message

for the command is not returned.

No Socket

z0 6y 05 FF

(y: Socket No.)

Returned when no command is executed in a

socket specified by the cancel command, or when

an invalid socket number is specified.

Command Not Executable

z0 6y 41 FF

(y: Execution command Socket

No. Inquiry command: 0)

Returned when a command cannot be executed

due to current conditions. For example, when

commands controlling the focus manually are

received during auto focus.

z = Camera Address + 8

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de PTZOptics

PTZOptics

PTZOptics Link PT12X-LINK-4K-GY Manual de usuario

PTZOptics

PTZOptics PT20X-NDI-GY Manual de usuario

PTZOptics

PTZOptics PT12X-NDI-GY Manual de usuario

PTZOptics

PTZOptics PT12X-NDI-GY-G2 Manual de usuario

PTZOptics

PTZOptics PT12X-SDI-WH-G2 Manual de usuario

PTZOptics

PTZOptics PTEPTZ-ZCAM-G2 Manual de usuario

PTZOptics

PTZOptics EPTZ-ZCAM-G2 Manual de usuario

PTZOptics

PTZOptics PT12X-USB-GY-G2 Manual de usuario

PTZOptics

PTZOptics NDI HX ZCAM G2 Manual de usuario

PTZOptics

PTZOptics Move 4K Manual de usuario

PTZOptics

PTZOptics EPTZ NDI HX ZCAM G2 Manual de usuario

PTZOptics

PTZOptics PTVL-NDI-ZCAM Manual de usuario

PTZOptics

PTZOptics PT12X-SE-GY-G3 Manual de usuario

PTZOptics

PTZOptics PTEPTZ-NDI-ZCAM-G2 Manual de usuario

PTZOptics

PTZOptics PT20X-USB-GY-G2 Manual de usuario

PTZOptics

PTZOptics PTZOptics 20x NDI HX ZCAM Manual de usuario

PTZOptics

PTZOptics PT12X-NDI-ZCAM Manual de usuario

PTZOptics

PTZOptics PT30X-SDI-GY-G2 Manual de usuario

PTZOptics

PTZOptics PT-WC-G1 Hoja de especificaciones

PTZOptics

PTZOptics Move PT12X-4K-GY Manual de usuario

PTZOptics

PTZOptics Move 4K Manual de usuario

PTZOptics

PTZOptics PT20X-USB-GY-G2 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
