© 2019 Pinnacle Climate Technologies, Inc. Kerosene Radiant Heater User’s Manual
NEVER LEAVE HEATER UNATTENDED WHILE
BURNING OR WHILE CONNECTED TO A POWER
SOURCE
®
ALWAYS use only the electrical power (voltage and
frequency) specified on the model plate of the
heater.
ALWAYS use only three-prong, grounded outlet and
extension cord.
ALWAYS use only 14 AWG or better extension cord.
ALWAYS unplug the heater when not in use.
ALWAYS install the heater so that it is not directly
exposed to water spray, rain, dripping water, or wind.
NEVER use fuels such as gasoline, benzine, paint
thinners or other oil compounds in this heater.
NEVER refill the heater’s fuel tank while the heater is
operating or still hot. This heater is EXTREMELY HOT
while in operation.
NEVER block air outlet (front).
NEVER use duct work in front of heater.
NEVER move or handle heater while still hot. NEVER
transport heater with fuel in tank.
NEVER use with an external fuel tank.
Keep all combustible materials away from this
heater. Minimum Clearance From Combustibles
80-OFR 125-OFR-A
Top 4 ft. (122 cm) 6 ft. (183 cm)
Sides 4 ft. (122 cm) 6 ft. (183 cm)
Front 8 ft. (244 cm) 8 ft. (244 cm)
ALWAYS locate heater on a stable and level surface.
If your heater is equipped with a thermostat, once it
is plugged in, it can start at anytime in accordance
with the thermostat setting.
RISK OF ELECTRIC
WARNING
SHOCK!
RISK OF BURNS, FIRE
WARNING
AND EXPLOSION!
CAUTION! HOT
WHILE IN
OPERATION. DO
NOT TOUCH. KEEP
CHILDREN, ANIMALS, CLOTHING AND
COMBUS-TIBLES AWAY FROM HEATER.
WARNING
The products described in this manual are kerosene
direct-fired, forced air heaters. Kerosene forced air
heaters are primarily intended for use for temporary
heating of buildings under construction, alteration or
repair. Direct-fired means that all of the combustion
products of the heater enter the heated space. This
appliance is rated at 98% combustion efficiency, but
does produce small amounts of carbon monoxide.
Carbon monoxide is toxic. Humans can tolerate only
small amounts of carbon monoxide and so
precautions should be taken to provide proper
ventilation. Failure to provide proper ventilation in
accordance with the instructions in this manual can
result in death.
People with breathing problems should consult a
physician before using this heater. Early signs of carbon
monoxide poisoning resemble the flu. Symptoms of
improper ventilation/carbon monoxide poisoning are:
Headache • Dizziness • Nausea • Dry Mouth
Sore Throat • Burning of Nose and Eyes
If you experience any of these symptoms:
GET FRESH AIR AT ONCE! Have your heater serviced
and check for proper ventilation. Some people are
more affected by carbon monoxide than others. These
include: pregnant women, those with heart or lung
problems, anemia or those under the influence of
alcohol or at high altitudes.
FOR OUTDOOR USE. INDOOR USE PERMITTED
ONLY FOR: The temporary heating of adequately
ventilated buildings or structures under
construction, alteration or repair! Provide at least a
three square foot (2,800 sq cm) opening of outside
air for every 100,000 Btu/Hr
(29 kW) heater rating. Refer to “Ventilation” on
page 7 for further instructions.
RISK OF INDOOR AIR
WARNING
POLLUTION!
CARBON MONOXIDE
POISONING MAY
LEAD TO DEATH!
DANGER
SAFETY INFORMATION (CONT.)
