Protech PA-3320 Manual de usuario

USER’S

MANUAL

PA-3320

POS Terminal Powered by

Intel

Atom

Platform

PA-3320 Series POS System

With LCD/Touch screen

All trademarks and registered trademarks mentioned herein are the property of their

respective owners.

This manual is copyrighted Oct. 2012. You may not reproduce or transmit in any

form or by any means, electronic, or mechanical, including photocopying and

recording.

DISCLAIMER

This user’s manual is meant to assist users in installing and setting up the system. The

information contained in this document is subject to change without any notice.

CE NOTICE

This is a class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference

in which case the user will be required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not expressly

approve by the party responsible for compliance could void your authority to operate

such equipment.

CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instructions.

WARNING! Some internal parts of the system may have high electrical voltage. And

therefore we strongly recommend that qualified engineers can open and disassemble the

system.The LCD and Touchscreen are easily breakable, please handle them with extra

care.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual…........................................................

1-2

1-2 POS System Illustration….................................................

1-3

1-3 System Specification…......................................................

1-4

1-4 Safety Precautions….........................................................

1-6

CHAPTER 2 SYSTEM CONFIGURATION

2-1 Jumper & Connector Quick Reference Table…................

2-2

2-2 Component Locations…....................................................

2-3

2-3 How to Set the Jumpers….................................................

2-5

2-4 COM Port & VGA Connector…………………………...

2-7

2-5 COM Port RI and Voltage Selection…………………….

2-9

2-6 Mini-DIM & USB Connector……………………………

2-10

2-7 LAN & USB Connector………………………………….

2-11

2-8 Cash Drawer Connector………………………………….

2-12

2-9 Cash Drawer Power Selection……………………….......

2-13

2-10 Backlight Type Selection………………………..….........

2-13

2-11 Power LED Connector……………..................................

2-14

2-12 Fan Connector……………………………………………

2-15

2-13 Power Connector…………………………………………

2-15

2-14 Reset Switch Connector……………….............................

2-16

2-15 Power for Thermal Printer Connector…………………...

2-16

2-16 External Speaker Connector……………………………..

2-16

2-17 Inverter Connector……………………….........................

2-17

2-18 MSR/Card Reader Connector……………………………

2-18

2-19 LVDS Connector…………………..…..……...................

2-18

2-20 LVDS Voltage Selection…………..…………………….

2-20

2-21 SATA Connector………………………………………...

2-20

2-22 SATA Power Connector…………....................................

2-21

2-23 Touch Panel Connector……..……………………………

2-22

2-24 Clear CMOS Data Selection………………………..........

2-22

2-25 Compact Flash Connector………………………………..

2-23

2-26 Printer Connector…………………………………….......

2-24

2-27 Watch Dog Function Selection…………………………..

2-25

2-28 I-Button Connector………………………………………

2-25

2-29 I-Button Function Selection………………………….......

2-26

Contents

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction.......................................................................

3-2

3-2 Intel

Chipset Software Installation Utility.......................

3-3

3-3 VGA Driver Utility…………………………….…….......

3-4

3-4 LAN Driver Utility............................................................

3-5

3-5 Sound Driver Utility..........................................................

3-6

3-6 Touch Screen Driver Utility……………..……………….

3-7

3-7 Wireless Driver Utility (Optional)……………………….

3-8

CHAPTER 4 AMI BIOS SETUP

4-1 Introduction.......................................................................

4-2

4-2 Entering Setup...................................................................

4-3

4-3 Main…..............................................................................

4-5

4-4 Advanced….......................................................................

4-6

4-5 Boot...................................................................................

4-22

4-6 Security…….....................................................................

4-27

4-7 Chipset……………………………...................................

4-28

4-8 Exit....................................................................................

4-34

APPENDIX A SYSTEM ASSEMBLY

Exploded Diagram for PA-3320 Base Cover……………………

A-2

Exploded Diagram for PA-3320 Top Case…...............................

A-4

Exploded Diagram for PA-3320 CPU Cooler…………………...

A-5

Exploded Diagram for PA-3320 Printer Box……………………

A-7

Exploded Diagram for PA-3320 Panel & Base Detachment……

A-8

Exploded Diagram for PA-3320 Main Board…………………...

A-9

Exploded Diagram for PA-3320 Bottom Case…………………..

A-10

Exploded Diagram for PA-3320 LCD Panel…………………….

A-11

Exploded Diagram for PA-3320 LCD Holder…………………..

A-14

Exploded Diagram for PA-3320 VFD Cover……………………

A-17

Exploded Diagram for PA-3320 3” Printer…………..................

A-19

Exploded Diagram for PA-3320 3” Printer Cover………………

A-21

Exploded Diagram for PA-3320 2” Printer……………………...

A-23

Contents

Exploded Diagram for PA-3320 2” Printer Cover………………

A-25

Exploded Diagram for PA-3320 HDD Module…………………

A-27

Exploded Diagram for PA-3320 SSD Module…………………..

A-28

APPENDIX B TECHNICAL SUMMARY

Block Diagram..............................................................................

B-2

Interrupt Map................................................................................

B-3

DMA Channels Map.....................................................................

B-4

I/O Map........................................................................................

B-5

Watchdog Timer Configuration....................................................

B-8

Flash BIOS Update……...............................................................

B-10

Page:1-1

INTRODUCTION

This chapter gives you the information for the PA-3320. It also outlines

the system specifications.

Sections included:

About This Manual

POS System Illustration

System Specifications

Safety precautions

Experienced users can jump to chapter 2 on page 2-1

for a quick start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 PA-3320 USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our PA-3320 Series System. The PA-3320 is an updated

system designed to be comparable with the highest performance of IBM AT personal

computers. The PA-3320 provides faster processing speed, greater expandability and

can handle more tasks than before. This manual is designed to assist you how to install

and set up the whole system. It contains four chapters and two appendixes. Users can

configure the system according to their own needs.

Chapter 1 Introduction

This chapter introduces you to the background of this manual. It also includes

illustrations and specifications for the whole system. The final section of this chapter

indicates some safety reminders on how to take care of your system.

Chapter 2 System Configuration

This chapter outlines the location of motherboard components and their function. You

will learn how to set the jumpers and configure the system to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the Intel Utility,

VGA Utility, LAN Utility, Sound Utility, and Touch Screen Utility.

Chapter 4 AMI BIOS Setup

This chapter indicates you how to change the BIOS configuration.

Appendix A System Assembly

This appendix gives you the exploded diagrams and part numbers of the PA-3320.

Appendix B Technical Summary

This appendix gives you the information about the allocation maps for the system

resources, Watchdog Timer Configuration, and Flash BIOS Update.

Chapter 1 Introduction

PA-3320 USER

′

S MANUAL Page: 1-3

1-2. POS SYSTEM ILLUSTRATION

Front View Rear View

Top View Side View

I/O View

LAN

USB

COM2

COM1

COM3

COM4

(Optional)

DWR1 DC OUT DC IN

LPT

(Optional)

VGA

Chapter 1 Introduction

Page: 1-4 PA-3320 USER

′

S MANUAL

1-3. SYSTEM SPECIFICATIONS

System

CPU Intel

Atom

D525

Chipset Intel

ICH8M

Operation System Windows 7/XP Pro

WES 7/2009

POSReady 7/2009

Memory 1 x 204-pin DDRIII SO-DIMM socket on board, up to 2GB

BIOS AMI SPI, 8Mbits with VGA

Power Supply 120W DC

Printer 2” or 3” easy loading thermal printer with auto cutter

(*Diameter of paper roll cannot exceed 8 cm.)

i-Button (Optional) Read only, output through PS/2 KB interface

MSR (Optional) JIS-I or II, ISO Tracker 1+2+3 (PS/2 KB

Interface)

Wireless LAN (Optional) Mini-PCIe wireless LAN module (802.11b/g)

Fingerprint (Optional) Embedded fingerprint module (USB Interface)

RFID (Optional) Read/Write, ISO 14443A 13.56MHz (USB

Interface)

Dimension (WxHxD)

369 mm x 287 mm x 355 mm

System Weight 9 Kg

Certificate FCC/CE

I/O Ports

Serial Port 3 x DB-9 (COM 2/3/4)

1 x RJ45 (COM1)

+5/12V Selectable (COM1~4)

USB 5 x USB 2.0 (one on front panel)

Keyboard/Mouse PS/2 with mini-DIN connector on rear panel

LAN 1 x 10/100/1000 Mbps

VGA 1 x DB-15 interface

Audio 1 x 2W speaker

Tabla de contenidos

Otros manuales de Terminal táctil de protech

protech

protech POS-6511 Series Manual de usuario

protech

protech prox PA-R120 Manual de usuario

protech

protech PA-A901 Manual de usuario

protech

protech PA-J580 Series Manual de usuario

protech

protech POS-3152 Series Manual de usuario

protech

protech PS8852 Manual de usuario

protech

protech prox KS-M333 Manual de usuario

protech

protech PA-5685 Manual de usuario

protech

protech PA-6610 Manual de usuario

protech

protech prox PA-J500 Manual de usuario

protech

protech prox PA-J670 Manual de usuario

protech

protech PS6508 Series Manual de usuario

protech

protech prox PA-J600 Manual de usuario

protech

protech POS-3520 Manual de usuario

protech

protech prox PA-6980 Manual de usuario

protech

protech PA-3110 Manual de usuario

protech

protech prox PA-J581 Manual de usuario

protech

protech MH-5752 Manual de usuario

protech

protech prox PA-A900 Manual de usuario

protech

protech prox PA-J511 Manual de usuario

protech

protech PA-3055 Manual de usuario

protech

protech prox PA-J511 Manual de usuario

protech

protech POS-6510 Series Manual de usuario

protech

protech PA-2019 Series Manual de usuario

Manuales populares de Terminal táctil de otras marcas

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manual de usuario

Ingenico

Ingenico AXIUM EX4000 Manual de usuario

Heisei Electronics

Heisei Electronics Q-POS 815 Manual de usuario

Amano

Amano MTX-15 Manual de usuario

FLOWBIRD

FLOWBIRD CWT Compact Touch Manual de usuario

Demco

Demco SP7 Manual de usuario

Lathem

Lathem PC600 Series Manual de usuario

Partner

Partner MF-2352 Manual de usuario

NCR

NCR RealPOS 7460-2 Manual

Simrad

Simrad MS50 Instrucciones de montaje

Unitech

Unitech MR350 MKII Guía de inicio rápido

Jungheinrich

Jungheinrich WMT 210 Manual de usuario

Motorola

Motorola MTP850 Manual de usuario

YASKAWA

YASKAWA 62H-MDC0 Manual de usuario

MVG industries

MVG industries NeptuLink Manual de usuario

Price Industries Limited

Price Industries Limited FDC Manual de instrucciones

Honeywell

Honeywell TemaKey Manual de usuario

EBN

EBN BPC65-B-A16G Manual de usuario

protech PA-3320 Manual de usuario

Manuales populares de Terminal táctil de otras marcas
