PSW160
16 Ports 10/100M Ethernet Switch
User's Manual
Revision 1.0
16-Port 10/100Mbps Fast Ethernet Switch
With External power supply
OVE VIEW
Thanks for choosing 16/port 10/100Mbps Auto-sensing Switch with External power supply. It is
the smallest switch with External power supply around the world. The switch is designed to be
suitable for integrating both 10BASE-TX networking circumstance with cabling UTP(Unshielded
Twisted-Pair) connection in Small/Medium Business(SMB) and Small Office/Home
Office(SOHO) environment.Simple plug in the networking cable and the switches sill
automatically detect the maximum speed of networking connection to offer smooth network
migrations and easy upgrades to network capacity. In addition, easy upgrade to network capacity.
In addition, External power supplies increase users’ convenience. For easy recognition or network
status and trouble-shooting, it provides a set of diagnostic LEDs, including 10/100Mbps, Link-
Activity.
Features
■Outstanding performance with guaranteed quality. 16-port With ealtek TL8316+ TL8208
world-class chipset solution.
■Single chip with highest level of silicon integration for the 16-port 10/100 Fast Ethernet
switch device, embedded on chip memory used for packet buffer and MAC address.
■Support auto-crossover (autoMDI/MDL-X) on every 10/100M J-45 port.
■Designed with External power supply. Palm-size with External power design, convenient for
the placement and power cord arrangement.
■Each port with non-blocking wire speed forwarding performance.
■Each port supports flow control and back-pressure.
■Small size and Plug-and-Play solution for SOHO application.
■FCC Part 15 Class B, CE EN55022 Class B, VCC1 Class B.
User Guide
●HARDWARE DESCRIPTION
A. The Front View
The LED indicators will help you monitor the status of each port and connected segment. The
functions of the LEDs indicators are described as follows.
LED
Indicators
Color Description
Power Red Lit: power On
Unlit: power off
0/ 00M speed Gree
n
Lit: Link at 00Mbps
Unlit: link at 0Mbps or no link
Link/activity Gree
n
Lit: Good link on The port
Blinking: the Port is
Receiving/Transmitting Date
Unlit: No link is Occurring on The
port
B. The Rear View
The rear panel contains 16-port 10/100Mbps J45 and a power core socket.
●HARDWARE INSTALLATION
A. Basic Installation
1. Place 16-port 10/100Mbps switch on a smooth surface.
2. Connect the power cord to the Switch.
3. Connect server, workstation or PC to the Switch using standard J-45
Ethernet cable.
4. Connect another workstation or PC to the Switch by following the same
process as described in Step3.
5. If necessary, another hub/switch also can be connected to any port of
your Switch using standard J-45 Ethernet cable for more flexible
application.
6. Ensure that each device is connected properly. Plug power cord into the
power outlet.
B. NWAY Process
“Auto-Negotiation” (NWAY) mode automatically sets the best possible
bandwidth when connection is established with another network device.
A. 100Base-TX Full Duplex(200Mbps)
B. 100Base-TX Half Duplex(100Mbps)
C. 10Base-T Full Duplex(20Mbps)
D. 10Base-T Half Duplex(10Mbps)
Each port with NWAY capability, support alf/Full Duplex function.
＊Attention:
1. The cable distance between the 6-port 0/ 00Mbps Switch and
hub/server should not exceed 00meters.
2. Make sure the wiring is correct In 0Mbps opration,Category 3/4/5
cable can be used for connection.To reliably operate your network at
00Mbps,you must use Category 5cable,or better Data Grade cabling.
Sample Application (According to 16-port Switch)
The optimal application for the 16-port 10/100Mbps Switch is as a
“bridge”joining 100Mbps and 10Mbps network segments, the following figure
illustrates the application.
NOTE:
16-port 10/100Mbps Switch supports auto-crossover(auto MDI/MDI-X)
function.Every port can be connected directly to another hub/switch for more flexible
Application. The user doesn’t need to use special crossover cable for uplink.
Technical Specifications
Standard IEEE802.3(Ethernet)
IEEE802.3u(Fast Ethenet)
IEEE802.3x(flow control)
Max Bandwidth
Full Duplex
Half Duplex
200Mbps(for 100BASE-TX),20Mbps(for 10Base-T)
100Mbps (for 100Base-TX),10Mbps (10 Base-t)
Media Interface 5/8/16 10/100Mbps J45 ports
Cabling 10BASE-T 2-Pair UTPP/STP Cat.3 or higher. Up to 100m(328 ft)
100BASE-TX 2-Pair UTP/STP Cat.5 or higher. UP to 100m(328 fi)
Cable Types UTP 100 ,STP 150 ;ETA/TLA 568-A,ISO/IEC11801
Packet Forwarding ate 10Mbps @14880bps;100Mbps@148800bps
MAC Address 5/8-port 10/100M Switch 1024 entries
16-port 10/100M Switch 4096 entries
Packet Forwarding ate 5/8-port 10/100M Switch Built-in 2M bit
16-port 10/100M Switch Built-in 4M bit
Modes Half and Full Duplex, auto-negotiation
Forwarding Mode Store and Forward
Non-blocking Yes
Flow Control
(IEEE802.3x)
Half: back pressure
Full: pause frame
Auto crossover Yes for each port
Diagnostic LED s Speed, Link/Activity
Operating Temperature 0 to 45 (32 to 113 )℃ ℃ ℉ ℉
Operating Humidity 10% H to 90% H
Certification FCC Part 15 Class B,CE EN 55022 Class B,VCC1 Class B.
