Projecta BM320 Manual de usuario
***PLEASE READ INSTALLATION SECTION OF THIS
MANUAL BEFORE INSTALLING THE PRODUCT***
WARNINGS
•Risk of explosive gas. Working in the vicinity of a lead-acid battery can be dangerous.
•Batteries might release explosive gases during normal operation and charging.
•Before using the product, read and follow the instructions carefully. Follow all
manufacturer’s instructions
•Do not smoke, use matches, use a cigarette lighter, or allow a spark or flame near
the battery.
•Remove rings, bracelets, necklaces and watches when working with a lead-acid
battery.
•Before accessing the battery leads (Red for positive and Black for negative),
disconnect the all devices or power sources from sockets and dc terminals provided
by the product.
•Do not submerge the product in water or expose to rain.
•Not recommended to use the product for critical power backup application.
•Designed to work with 12V lead acid battery only.
•This appliance is not intended for use by young children or infirm persons without
supervision. Young children should be supervised to ensure that they do not play
with the appliance
•Ensure that all cable connections have the correct polarity and are protected against
accidental short circuit
•Do not allow water or other liquids to enter the installation area
•Must Fit Fuse. Failure to do so may cause fire
•Max discharge current - 320A
Overview
Projecta BM320 - A sophisticated, full colour LCD monitor that accurately displays a battery’s total
capacity, overall health and voltage. It is Ideal for camper trailer and caravan interiors as it is housed
in a modern and simple to install enclosure. The BM320 comes with all the necessary components to
connect to your battery system.
It has the following features:
•2.4” full colour LCD display
•Configurable Low battery capacity and battery health alarm
•Suitable for popular deep cycle AGM, WET, GEL & Calcium batteries
•Using patented technology to monitor battery characteristics like battery state of
charge and state of health
Specification
Part No.
BM320
Battery Fuel Gauge
Input consumption current
(backlight off )
12V/1.5 mAdc
Input Voltage Range
6.0--17.0 Vdc
Max discharge current
320A
Display Resolution
Current
0.1 A
Voltage
0.1V
Battery Capacity
0.1Ah
Type of Battery Supported
Wet/AGM/Gel/Calcium
Display Physical Characteristics
Weight
0.12 kg
External Dimension
118mm (L) x 96mm (W) x 18mm(H)
Operating Temperature
0 to 50℃
Compliance
EMC
Certified to meet AS/NZS 61000.6.3
DISPLAY SCREEN INSTALLATION
Choose a flat location which is easily accessible and easy to view the display screen.
The location should be indoors away from weather.
Screw the mounting clip using supplied self-tapping screws ensuring that the arrow is pointing “UP”
Drill a 15mm Diameter hole 20mm from the screw hole as pictured to allow the connector to pass
through.
Plug in the supplied four pin connector to the recipicale at the back of the battery monitor
Feed the cable through the pre drilled hole and slide the left hand side of the battery monitor into
the bracket tab.
Close the battery monitor onto the clip until you hear the “click” sound.
Make sure that the cable assembly has been fed into the hole correctly.
SHUNT AND WIRING INSTALLATION
IMPORTANT: to maintain accurate record of the battery capacity, all current must be passed through
the shunt.
Disconnect the battery and turn off all devices before beginning the installation.
Mount the shunt in a secure location with adequate protection from damage.
The BM320 is designed for 12V applications only.
Once the shunt has been wired up to the battery and the monitor. Apply the provided shunt cover to
protect the shunt.
Spread the shunt cover apart and place over the shunt.
Ensure that the shunt cover is now covering the shunt so that when the shunt is screwed down the
shunt cover is held in place.
Battery cable selection chart
Nearest
Nominal
AMP
Nominal
B & S
Area
Rating
O.D.
(mm²)
(mm)
(40°C)
8
7.71
66
5.5
6
13.5
92
7.2
4
20.26
120
8.3
3
26.45
150
10.2
2
32.07
167
11.3
1
39.55
187
12.1
0
49
219
12.7
00
64.15
260
14.5
000
83.19
298
16.4
Alternative connection method:
NOTE: USE ONLY ONE CONNECTION METHOD.
To connect using your own wiring harness use the supplied terminal block.
The terminal block is labelled, ensure you follow the wiring diagram and follow the colour
coded connection sequence.
Quick Start
BM320 has four keys for user interface
•MENU Key: for navigating to various available Modes.
•UP/DOWN Key: for navigating between various options within the Modes.
•ENTER Key: For confirming a selection.
2. Select the type of battery (AGM,WET,GEL,CAL)
3. Enter the battery capacity and press ENTER button to confirm
4. Set the time and date of the clock (12Hr) – use the up and down arrows to adjust and press
ENTER to move to the next setting
5. Enter value for the low battery capacity alarm and press ENTER button to confirm
6. Enter the value for battery health warning alarm and press ENTER button to confirm
7. *The battery settings and alarm settings will now be locked and unable to change unless the
power is removed and the start-up sequence is completed again. Press enter to continue or
menu to adjust the values.*
8. For most accurate results - Charge the battery to full with any multi-stage battery charger
9. Disconnect the battery charger when the battery is full
10. Unit is ready to use
