PROGRESSIVE DESK FLTCON-2-24VDC Manual de usuario

V 1.01

Scan for more information!

User Manual

FLTCON-2-24VDC

Dimensional Drawing 3

Specification 3

Installation 4

Operational Procedure 4

Reset Procedure 5

Setting Upper & Lower Limits 5

P a g e | 2

Table of Contents

Have any queries? Our expert engineers are here to help!

[email protected] progressivedesk.com

1-800-828-9414

Troubleshooting 6

Specifications

P a g e | 3

Dimensional Drawing

Input Voltage

Specification Description

24VDC

15A

10A

Hall Effect Sensor

10% (2 min on, 18 min off)

5°C to 40°C

Black

POM

None

7.75" x 5.25" x 3.00"

0.56lbs

18 Months

Output Voltage

Current Rating total

Current Rating per channel

Number of Channels

Feedback Input

Duty Cycle

Operational Temperature

Housing Color

Housing Material

Certifications

Dimensions (LxWxH)

Unit Weight

Warranty

Operational Procedure

P a g e | 4

To raise the desk, press and hold the UP button. To lower the desk, press and hold the DOWN button. The UP and DOWN

buttons are momentary controlled. When either directional buttons are released, the desk will stop immediately.

To save a position, move the desk to the desired height. Press the “M” button followed by a number. The LED display will

flash an 'S', followed by an 'S - Number'. This will indicate that the position has been saved. To use a preset, press any of

the numbered buttons and the desk will begin to move to the preset position. It is important to ensure that no obstacles

impede the motion of travel. To stop motion while in travel, press any button. If the desk does not function as intended or

the LED display flashes "RST", please follow the Reset Procedure outlined below.

Installation

https://f.hubspotusercontent40.net/hubfs/7717445/PDF%20Manuals/Desk%20Accessories/PD%20Accessories/PA-BT1-24-2200%20User%20Manual%20v1.0.pdf

To use the FLTCON-2-24VDC with your desk, make sure to also acquire the PA-BT1-24-2200 and connect them together

using the diagram below. More information about the PA-BT1-24-2200 can be found at the link here.

1. Insert the battery into the dock. Determine the desired placement of the dock on the underside of the tabletop.

2. Remove the battery from the dock and attach the battery dock to the underside of the tabletop using the included

hardware.

3. Connect the dock wiring to the control box. For a mobile desk, the new FLTCON-2-24VDC control box will replace the

existing one on the purchased unit.

NOTE: Battery must be fully charged prior to the first use.

NOTE: To make your standing desk fully mobile, we recommend installing caster wheels.

Setting Upper & Lower Limits

P a g e | 5

Upper Limit

1. To set the upper limit, use the UP/DOWN buttons to move the table desk to your desired maximum height position.

2. Once it is at the desired position, press and release the "M" button so it shows "S-".

3. While "S-" is shown in the display, press and release the up arrow once.

4. Hold the "M" button until the display shows "999" then release.

The display will then automatically revert back to the height display. The upper limit is now set.

Lower Limit

1. To set the upper limit, use the UP/DOWN buttons to move the table desk to your desired minimum height position.

2. Once it is at the desired position, press and release the "M" button so it shows "S-".

3. While "S-" is shown in the display, press and release the down arrow once.

4. Hold the "M" button until the display shows "000" then release.

The display will then automatically revert back to the height display. The upper limit is now set.

Removing Limits

1. Press and release the "M" button so it shows "S-".

2. While "S-" is shown on the display, press and hold "M" again until the display shows "555"

The display will then automatically revert back to the height display. Any previously set limits are now removed.

*After the upper and lower limits are set, the previous memory positions (1,2,3,4) may be outside the new range of move-

ment. If this happens, simply reset the memory positions.

*A Reset procedure requires the desk base to fully retract beyond any lower limit. Please ensure you have proper clear-

ance below the desk base.

*If you attempt to revise a previously set upper or lower limit and it is outside of the existing range, you will need to remove

the original upper/lower limits first.

Reset Procedure

To enter the Reset Procedure, press and hold the DOWN button on the Hand Remote until the LED shows "RST" (If you

are not using an LED hand remote, hold the DOWN button for about 10 seconds). Release the DOWN button. Press and

hold the DOWN button once more until the desk(s) lower completely then slightly rise before coming to a stop. This signals

the end of the reset procedure. Release the DOWN button and your system is now ready to use.

If any error message persist after completing the reset procedure, contact us at 1-800-828-9414 or by email at

[email protected] to receive assistance from our available technicians.

*If the height difference between the legs exceeds 1.5 inches, stop the reset procedure & contact us.

*lf the handset displays ‘HOT’, let the unit cool down for 20 minutes before starting the reset procedure again.

P a g e | 6

Troubleshooting

Have any queries? Our expert engineers are here to help!

[email protected] progressivedesk.com

1-800-828-9414

Code

E01

E02

E03

E04

E07

E08

E09

E10

H01

M1 overcurrent protection

M2 overcurrent protection

M3 overcurrent protection

M4 overcurrent protection

M1 hall error

M2 hall error

M3 hall error

M4 hall error

Over heat / Duty

Cycle protection

All columns stop moving and remote displays E01-E04. Ensure that the total

weight capacity of the lifting columns has not been exceeded and that no

obstacles obstruct the movement. Press any key and remote will display RST,

initiate the Reset Procedure. If the issue persists, disconnect and reconnect all

of the lifting columns, including the main power. Repeat the Reset Procedure.

All columns stop moving, remote displays H01 (if LED screen available). Allow

the system to rest for 16 minutes, use normally. Follow the Duty Cycle rating to

ensure no issues arise from overheating.

All columns stop moving and remote displays E07-E10. Ensure that all columns

are still properly connected to the control box. Check to see if any cables have

been damaged. Press any key and remote will display RST, initiate the Reset

Procedure. If the issue persists, disconnect and reconnect all of the lifting

columns, including the main power. Repeat the Reset Procedure.

Description Solution

Error Codes (remotes with LED display)

Problem

Remote LED

is off.

Lifting columns do

not move when

motion control

buttons are

pressed.

Lifting columns

travel at a

significantly slower

speed than rated

specification.

Unusual noise

during travel.

Lifting columns

stop abruptly

during travel.

Lifting columns

are not level.

Low power mode

activated Press any button on the remote and LED will activate.

Disconnect and reconnect the RJ-45 remote connector.

Ensure connection is secure and cable is not damaged.

Follow "Setting Limit Switches" instructions to remove the programmed

limit (FLTCON-02 only). If maximum or minimum height limit has been

reached, please move the system in the opposite direction.

Disconnect and reconnect the Lifting Columns,

Control Box, AC Power, and Remote.

Ensure weight capacity has not exceeded the maximum load rating.

Ensure there are no obstacles in the path of the lifting columns. If

the movement continues to fail, initiate the Reset Procedure.

Disconnect and reconnect all cables (Lifting Column, Control Box,

AC Power, and Remote), then initiate the Reset Procedure.

Connection issue

Weight issue

Obstacle

Out of sync

Limit switch reached

Connection issue

Description Solution

Troubleshooting Guide
