Safety Rules

Unpacking Your Fan

Installing Your Fan

Setting the Codes on Remote Control and Receiver

Making the Electrical Connections

Finishing the Fan Installation

Operating Your Fan

Care of Your Fan

Troubleshooting

Specications

Table of Contents

1. To reduce the risk of electric shock, insure electricity

has been turned off at the circuit breaker or fuse box

before beginning.

2. All wiring must be in accordance with the National

Electrical Code ANSI/NFPA 70-1999 and local electrical codes.

Electrical installation should be performed by a

qualied licensed electrician.

3. CAUTION: To reduce the risk of personal injury, use only

the screws provided with the electrical box.

4. The outlet box and support structure must be securely

mounted and capable of reliably supporting 50 lbs. (22.68

kg). Use only UL Listed outlet boxes marked “Acceptable

for Fan Support of 50 lbs. ((22.68 kg) or less.”

5. CAUTION: The fan must be mounted with a minimum of

7 feet clearance from the trailing edge of the blades to the

oor.

6. Do not wait for the fan to stop before pressing the reverse

button. The fan will not reverse direction if the fan is not

moving.

7. Avoid placing objects in path of the blades.

8. To avoid personal injury or damage to the fan and other

items, be cautious when working around or

cleaning the fan.

9. Do not use water or detergents when cleaning the fan or fan

blades. A dry dust cloth or lightly dampened cloth will be

suitable for most cleaning.

10. After making electrical connections, spliced conductors

should be turned upward and pushed carefully up into

electrical box. The wires should be spread apart with the

grounded conductor and the equipment-grounding

conductor on one side of the electrical box and ungrounded

conductor on the other side of the electrical box.

11. Electrical diagrams are for reference only. Light kits that

are not packed with the fan must be UL Listed and marked

suitable for use with the model fan you are installing.

Switches must be UL General Use Switches. Refer to the

instructions packaged with the light kits and switches for

proper assembly.

12. All set screws must be checked and retightened where

necessary before installation.

13. WARNING: To reduce the risk of re or electric shock,

do not use this fan with any solid-state speed control device.

1. Safety Rules

READ AND SAVE THESE INSTRUCTIONS

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL

INJURY, MOUNT TO OUTLET BOX MARKED “ACCEPTABLE FOR FAN

SUPPORT OF 50 LBS. (22.68 KG) OR LESS”, AND USE SCREWS PRO-

VIDED WITH THE OUTLET BOX.

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE

BLADE BRACKETS (ALSO REFERRED TO AS (“FLANGES”) DURING

ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN

THE PATH OF THE BLADES.

TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED

WITH AN ISOLATION CONTROL/SWITCH.

by Rhine Electronic Co., Ltd only.

Use with speed controller UC7067RYE, manufactrued

14.

a. Blade attachment hardware

(16 Screws)

b. Electrical hardware and Balancing kit

(3 plastic wire connectors, blade balancing

kit)

c. Blade attachment hardware

(5 strength plates)

5. Fan Motor Assembly

6. Switch Cup Adaptor

7. Switch Cup

8. Blade (5)

9. Transmitter and Receiver

1. Mounting Bracket (inside canopy)

2. 8” Ball/Downrod Assembly (hanger pin

and locking pin pre-attached)

3. Canopy with Canopy Ring (attached)

4. Decorative Motor Collar Cover

2. Unpacking Your Fan

Unpack your fan and check the contents. You should have the following items:

THIS SIDE UP

d. Extra mounting screws #10-32 for outlet box

(1 Screws)

3. Installing Your Fan

Tools Required

Phillips screw driver or straight slotted screw

driver, adjustable wrench, step ladder, and

wire cutters.

Mounting Options

If there isn’t an existing electrical box, then

read the following instructions. Disconnect

the power by removing fuses or turning off

circuit breakers.

Secure the electrical box directly to the building

structure. Use appropriate fasteners and

building materials. The electrical box and

its support must be able to fully support the

moving weight of the fan (at least 50 lbs.).

Do not use plastic electrical boxes.

Figures 1, 2, and 3 are examples of different

ways to mount the electrical box.

Note: You may need a longer downrod to

maintain proper blade clearance when

installing on a steep, sloped ceiling. The

maximum angle allowable is 20˚. If the

canopy touches downrod, remove the

decorative canopy bottom cover and turn

the canopy 180˚ before attaching the canopy

to the mounting plate.

To hang your fan where there is an existing

xture but no ceiling joist, you may need an

installation hanger bar as shown in Figure 4.

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PERSONAL INJURY, MOUNT TO

OUTLET BOX MARKED “ACCEPTABLE FOR

FAN SUPPORT OF 50 LBS. (22.68 KG) OR

LESS”, AND USE SCREWS PROVIDED WITH

THE OUTLET BOX. ELECTRICAL BOXES

COMMONLY USED FOR THE SUPPORT OF

LIGHTING FIXTURES MAY NOT BE ACCEPT-

ABLE FOR FAN SUPPORT AND MAY NEED TO

BE REPLACED. CONSULT A QUALIFIED ELEC-

TRICIAN IF IN DOUBT.

Figure 1

Figure 2

Figure 4

Figure 3

Hanging the Fan

REMEMBER to turn off the power. Follow

the steps below to hang your fan properly.

NOTE: This fan is recommended for

standard ceiling mount using the downrod

provided with this fan. When using standard

ceiling installation with the 8 inch downrod

provided, the distance from the ceiling

to the bottom of the fan blades will be

approximately 15 inches.

Standard Ceiling Mounting

1. Remove the canopy ring from the canopy

by turning the ring counter-clockwise

until it unlocks. (Figure 5)

2. Remove the mounting bracket from the

canopy by loosening the four screws on

the top of the canopy. Remove the two

non-slotted screws and loosen the slotted

screws. This will enable you to remove

the mounting bracket. (Figure 6)

3. Remove the hanger pin and locking pin

from downrod assembly.

4. Route the wires exiting the top of the fan

motor through the decorative motor collar

cover then the canopy ring. Make sure the

slot openings are on top. Route the wires

through the canopy and then through the

ball/downrod assembly. (Figure 7)

Remove

Loosen but Do Not Remove

Turn Canopy Ring to Remove

Figure 5

Figure 6

5. Loosen, but do not remove, the set screws

on the collar on the top of the motor

housing.

6. Align the holes at the bottom of the

downrod with the holes in the collar on top

of the motor housing. (Figure 7)

Carefully insert the hanger pin through the

holes in the collar and downrod. Be careful

not to jam the hanger pin against the wiring

inside the downrod. Insert the locking pin

through the hole near the end of the bolt

until it snaps into its locked position, as

noted in the circle inset of Figure 7.

7. Re-tighten the set screws on the collar on

top of the motor housing.

8. Make sure the grommet is properly installed

in the collar cover, then slide the collar cover

on the downrod until it rests on the motor

housing. Be sure that the canopy and the

collar cover are both oriented correctly.

9. Proceed to “Installing the Fan” section.

FAILURE TO PROPERLY INSTALL SET SCREWS

AS NOTED IN STEP 7 COULD RESULT IN FAN

LOOSENING AND POSSIBLY FALLING.

Figure 7

Standard mounting

Installing Fan to

the Electrical Box

WHEN MOUNTING THE FAN ON A SLOPED

CEILING, THE STANDARD BALL/DOWNROD

MOUNTING METHOD MUST BE USED. THE

MOUNTING PLATE MUST BE MOUNTED SO

THAT THE SLOT OPENINGS ARE ON THE

LOWER SIDE BY SLIDING THE MOUNTING

PLATE FROM THE TOP DOWN.

1. Pass the 120-volt supply wires through the

center hole in the ceiling mounting bracket

as shown in Figure 8.

2. Install the ceiling mounting bracket on the

outlet box by sliding the mounting bracket

over the two screws provided with the outlet

box. If necessary, use leveling washers (not

included) between the mounting bracket

and the outlet box. Note that the at side of

the mounting bracket is toward the outlet

box. (Figure 8)

3. Securely tighten the two mounting screws.

4. Carefully lift the fan assembly up to the

ceiling mounting bracket. Make sure the tab

on the mounting bracket is properly seated

in the groove in the hanger ball. (Figure 9)

Figure 8

Electrical Box)

WHEN USING THE STANDARD BALL/DOWNROD

MOUNTING, THE TAB IN THE RING AT THE

BOTTOM OF THE MOUNTING BRACKET MUST

REST IN THE GROOVE OF THE HANGER BALL.

FAILURE TO PROPERLY SEAT THE TAB IN THE

GROOVE COULD CAUSE DAMAGE TO WIRING.

Figure 9

6. Setting the Codes

Setting the Codes

This unit has 16 different code combinations

to prevent possible interference from other

remote units such as garage door openers, car

alarms or security systems.

To set the codes, perform the following steps:

1. Setting the code on the transmitter:

A. Remove the battery cover from the

battery compartment in the back side of

the transmitter.

B. Slide code switches to your choice of

up or down position (factory setting is

up).

C. Replace the battery cover on the battery

compartment of the transmitter.

2. Setting the code on the receiver:

A. Slide code switches to the same

position as set on your transmitter.

Model:UC7085T

FCC ID:CHQ7085T

IC:2968A-7085T

Complies with Canada

RSS-210

MADE IN CHINA

AirproR

1 2 3 4

NECE

12V

1 2 3 4

ON DIP

1 2 3 4

ON DIP

1 2 3 4

NECE

Dip Switches

Transmitter

Receiver

The reverse button

Figure 10

EACH WIRE NUT (WIRE CONNECTOR) SUPPLIED

WITH THIS FAN IS DESIGNED TO ACCEPT UP TO

ONE 12 GAUGE HOUSE WIRE AND TWO WIRES

FROM THIS FAN. IF YOU HAVE LARGER THAN

12 GAUGE HOUSE WIRING OR MORE THAN

ONE HOUSE WIRE TO CONNECT TO THE FAN

WIRING, CONSULT AN ELECTRICIAN FOR THE

PROPER SIZE WIRE NUTS TO USE.

USE THE PLASTIC WIRE CONNECTORS

SUPPLIED WITH YOUR FAN. SECURE THE

CONNECTORS WITH ELECTRICAL TAPE AND

ENSURE THERE ARE NO LOOSE STRANDS OR

CONNECTIONS.

BLUE

BLACK

WHITE

GREEN

BLUE

BLACK WHITE

WHITE

SUPPLY CIRCUIT

BLACK

WHITE

Grounding

Conductor

Green

Grounding

Lead

Remote

Receiver

Figure 11

REMEMBER to disconnect the power. If

you feel you do not have enough electrical

wiring knowledge or experience, have your fan

installed by a licensed electrician. Do not use

solid state fans, electrical wires must meet all

local and national electrical code requirements.

Electrical source and fans must be 115/120

Volt, 60Hz.

Remote control model: UC7067RYE

Making the Electrical Connections

IF OTHER FAN OR SUPPLY WIRES ARE

DIFFERENT, PLEASE HAVE THIS UNIT

INSTALLED BY A LICENSED ELECTRICIAN.

Follow the steps below to connect the fan to

your household wiring. (Figure 11)

1. Connect the GROUND conductor of the

120v supply (this may be a bare wire or

a wire with green colored insulation) to

the GREEN ground lead(s) of the fan.

(Figure 11)

2. Connect the fan motor WHITE wire to

the receiver WHITE wire using a wire

nut. (Figure 11)

3. Connect the fan motor BLACK wire to

the receiver BLACK wire using a wire

nut. (Figure 11)

4. Connect the fan motor BLUE wire to the

receiver BLUE wire using a wire nut.

(Figure 11)

5. Connect the receiver BLACK wire to the

supply BLACK (hot) wire using a wire

nut. (Figure 11)

6. Connect the receiver WHITE wire to the

supply WHITE (neutral) wire using a

wire nut. (Figure 11)

7. After connecting the wires, spread them

apart so that the green and white wires

are one side of the electrical box and the

black wire is on the other side.

8. Turn the wire connecting nuts upward

and carefully push the wiring into the

electrical box.

Otros manuales para AirPro P2560

Tabla de contenidos

Otros manuales de Admirador de Progress Lighting

Progress Lighting

Progress Lighting 52-RDT Manual de usuario

Progress Lighting

Progress Lighting AirPro COPAN Manual de usuario

Progress Lighting

Progress Lighting AirPro P250060 Manual de usuario

Progress Lighting

Progress Lighting AirPro Huff P250030-031 Manual de usuario

Progress Lighting

Progress Lighting EF200D Manual de usuario

Progress Lighting

Progress Lighting AirPro P250072 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250093 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250061 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250066 Manual de usuario

Progress Lighting

Progress Lighting AirPro Royer P250010 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250075 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250040 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250074 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250082 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250094 Manual de usuario

Progress Lighting

Progress Lighting AirPro P2553 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250021 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250099 Manual de usuario

Progress Lighting

Progress Lighting AirPro Trevina II P2555 Manual de usuario

Progress Lighting

Progress Lighting AirPro Midvale P250011 Manual de usuario

Progress Lighting

Progress Lighting AirPro P2552 Manual de usuario

Progress Lighting

Progress Lighting AirPro P2568 Manual de usuario

Progress Lighting

Progress Lighting AirPro P250000 Manual de usuario

Progress Lighting

Progress Lighting Springer P260004 Manual de usuario

Manuales populares de Admirador de otras marcas

ELTA FANS

ELTA FANS H03VV-F Manual de usuario

Hunter

Hunter 20714 Manual de instrucciones

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manual de usuario

Hunter

Hunter Caraway Manual de instrucciones

Panasonic

Panasonic FV-15NLFS1 Manual de usuario

Kompernass

Kompernass KH 1150 Manual de usuario

VES

VES FALA100/12V/TR Manual de usuario

Vertiv

Vertiv Liebert DCD Manual de usuario

Westinghouse

Westinghouse GFP Series Manual de usuario

Venmar

Venmar KUBIX HRV PLUS Series Manual de usuario

Maico

Maico ECR 31 Manual de usuario

Sonnenkonig

Sonnenkonig Dinky Manual de usuario

S&P

S&P ECOWATT HXBR Manual de usuario

Wider

Wider IMP03369BH Manual de usuario

Panasonic

Panasonic F-60DHN Manual de usuario

Hinkley

Hinkley HIGHLAND Manual de usuario

Broan

Broan 766BN Manual de usuario

Premium

Premium PFS16022 Instrucciones de montaje
