PROAIM P-WV-2SD Manual de usuario
Instruction Manual
7' Wave-2 Jib Crane, Dolly Stand for
Camera / Gimbals / Pan Tilt Heads
(P-WV-2SD)
2
Subject Page
Foreword 3
Introducon 4
Assembling 5-10
Warranty 11
At Proaim, our goal is to ensure 100% Customer Sasfacon in all that we do.
We back our sales with a 1 year warranty from the date of purchase and work hard
to resolve any problems in the unlikely event one should arise.
With our commitment to connuous improvement and your Feedback, building on
our reputaon of providing aordable, quality products is
PRIORITY #1.
Table of Contents
3
Dear Client,
On behalf of all the people that work so hard to provide you with the most
up-to-date, exible and cost-ecient producon gear, we would like to welcome
you into the Proaim family.
By purchasing your Proaim 7' Wave-2 Video Jib Crane With CST-100 Stand &
Portable Dolly you have just joined a host of designers, engineers, machinists,
assembly, customer service and oce sta that take great pride in all that they do.
Our mantra of connuous improvement has been the guiding principle of how we
conduct our business since day one.
Once you have the opportunity to experience your new Proaim 7' Wave-2 Video Jib
Crane, we hope you will agree that we cra quality products at a compeve price.
Products designed to meet and exceed the standards of today’s real producon
world.
Standards set by our valued clients and standards we strive to maintain.
With Best Wishes,
Proaim Team
Welcome To Proaim!
4
Introducon
PROAIM welcomes you to the new and modernized era with its Proaim 7' Wave-2
Video Jib Crane With CST-100 Stand & Portable Dolly , a portable lming
soluon to increase your producon value. The Robust jib crane is specically
designed travel crane for indoor & outdoor video producons. Its telescopic
arm feature adds exibility to frame perfect shots in indoor and outdoor spaces.
This video producon package includes a rugged camera dolly for smooth,
dynamic moving shots and rock solid aluminum tripod stand for immense support
Please inspect the contents of your shipped package to ensure you have received
everything that is listed below.
What’s In The Box
75mm Conversion
Ring
Cst-100mm Bowl Tripod Stand
Weight Rod with weight Closer
Proaim Portable Dolly (P-PRT-D)
Flate Base Plate
Bag packing
Wave-2 Jib Crane
Aluminum Spreader
100mm Bowl
5
Posion the height of the tripod by loosening all three adjustment knobs, sliding the tripod
up to the desired height and re-ghten the knobs securely.
In case of spreader, Take out the Spreader and spread it on oor and open the legs (as per
your requirement) of spreader with the help of provided knob.
You can use the Wave jib in 2 ways
Assembling
Now mount the Tripod Stand on Spreader, lock it in place with the rubber grips
Spreader Dolly
6
In case of Dolly, Take out the bolt from the center of dolly and spread it on oor. Then put
the bolt back through the center of dolly again.
Now mount the Tripod Stand on Dolly, lock it in place with the rubber grips.
NOTE: To keep the dolly in stac
posion, lock the wheels by pushing down
the lever.
7
Loosen the bolts of the hub secon and move the hub secon from their posion for proper
aaching, then again ghten the bolts to secure it.
Loosen the knob for the free lt movement of the camera plate, then aach the lower
secon of the jib as shown in the image.
Aaching the Lower telescopic jib secon.
Tighten the aaching 1st knob, the 2nd knob ghten properly for double security.
1st knob
2nd knob
8
Unscrew the locking lever from the Central Post of the jib. Place the Central Post in the bowl
of Tripod Stand and re-ghten the locking mechanism for a secure t.
NOTE: It is important to make sure that the Central Fork is seated in the bowl properly. That
means perpendicular to the tripod bowl. O axis installaon may hamper movement of the jib.
Also you may need the assistance of a grip stand to hold the camera end of the arm during
installaon prevenng it from falling as it will be front heavy at this point. You may also need
the grip stand or assistance at the rear of the jib when mounng the camera.
Provided are the jib panning control
knobs (as shown in the picture). Loosen
the knobs for the smooth pan
movement of the jib and ghten these
knobs to lock the pan movement of the
jib.
Unscrew the allen bolts to extend jib arm at back and reghten the allen bolts. Secure all the
connecons.
9
Insert the weight rod into the jib arm.
Now slide in weight to it as per your requirement and screw in weight closer
properly. (Counter weight Not Included)
NOTE: Make sure the opposite end of the jib arm is secured so that the addion of the weights
does not cause the arm to rise violently.
Mount your fluid head (Not included) onto the bowl plate in order to attach the camera (Not
included) . And then nally, secure your camera properly on the uid Head.
10
Loosen the bolts and remove the 100 bowl.
Attach the flate base plate and secure by tightening the bolts and then attach the Pan Tilt Head
(Not Included) and secure by tightening the bolts.
For an over slung setup, attach the flat base plate on the top and mount the camera setup and
secure the camera properly.
