Pro-Team ProGen 1073300 Manual de usuario

Upright

Service Manual

ProGen Models

1073300 & 1073290

Table of Contents

Base Cover.............................................................................................. 1

Clutch, LED Front Light, Belts, and Control Boards.............................. 2-3

Filter Bag Housing .................................................................................. 4

Foot Pedal .............................................................................................. 5

Motor.................................................................................................. 5-7

Power Head Hose ................................................................................... 8

Front Wheel............................................................................................ 8

Rear Wheel ............................................................................................. 9

www.pro-team.com 866.888.2168

ATTENTION

Before servicing any part or

proceeding with any repair

procedure on any ProTeam vacuum,

ALWAYS disconnect the vacuum

from power source.

View Upright Vacuum

Wiring Schematic

at www.pro-team.com

www.pro-team.com 866.888.2168 1

Base Cover

Remove brush

Remove cover - Lift up on one side

Remove five (5) (M4 x 16mm length) screws

To Reassemble. Repeat steps in reverse.

Clutch, LED Front Light, Belts, and Control Boards

2 www.pro-team.com 866.888.2168

Lift straight up on sensor control board, do not

lift by wires

Remove rubber bumper - Pull straight up

1. Remove lens - Lift up on corner

Remove LED light - Lift straight up on sensor

control board, do not lift by wires

Remove RPM sensor - Remove screw

(M4 x 16mm length)

6. Remove printed circuit board - Remove two (2)

screws (M4 x 16mm length)

www.pro-team.com 866.888.2168 3

Clutch, LED Front Light, Belts, and Control Boards

Lift up on control board

Remove clutch assembly - Slide belt off pulley

9. Remove clutch assembly

10.

Remove clutch assembly - Remove two (2)

(M3 x 12mm length) screws

To Reassemble. Repeat steps in reverse.

Filter Bag Housing

4 www.pro-team.com 866.888.2168

Lift up on bag housing and slide belt off motor

pulley

Remove power head hose from bag housing

Remove filter bag housing - Tilt filter bag

housing back

1. Remove two (2) (M4 x 16 mm length) screws

and bracket on each side

To Reassemble. Repeat steps in reverse.

www.pro-team.com 866.888.2168 5

Foot Pedal

Remove plastic sleeve bearing each side - pull

straight off

Remove foot petal

1. Tilt/rotate pedal forward (wear gloves to prevent

cuts from possible sharp edges in this assembly) -

Lift up on foot pedal

Remove rear bag housing cover - Remove

nine (9) (M4 x 20mm length) screws

Motor

To Reassemble. Repeat steps in reverse.

Motor

6 www.pro-team.com 866.888.2168

Lift motor assembly upward

Remove gasket

Remove air separator and motor - Remove

two (2) (M4 x 20mm length) screws

Remove steel sleeve bearing on each side - Pull

straight off

3. Remove filter plate - Remove four (4) screws

(M4 x 20mm length)

Remove filter door on each side

Lift wiring harness upward

Motor

Remove air separator - Remove two (2) (M4 x

20mm length) screws

10.

Remove upper motor housing - Remove six (6)

(M4 x 16mm length) screws

11.

To Reassemble. Repeat steps in reverse.

www.pro-team.com 866.888.2168 7

Remove motor brush assembly - Remove two

(2) (M4 x 16mm length) screws

12.

Pinch tab end and pull to release

13.

Power Head Hose

Remove center wheel - Pull wheel upwards -

Slide wheel off shaft

Remove hose by twisting/unthreading

Remove power head hose - Remove four (4)

(M4 x 16 mm length) screws

To Reassemble. Repeat steps in reverse.

Front Wheel

8 www.pro-team.com 866.888.2168

To Reassemble. Repeat steps in reverse.
