PreVent BR11 Manual de usuario

BR11 Instruction Manual

Manual BR11 Version 1.2 19.11.2019

Contents: Page

Introduction 2

1. Functional principle 3

2. Installation 3

3. Operating conditions 3

4. Operability, maintenance and repair 4

- standard construction

4.1. Gland packing 4

4.2. Valve seat and block 5

5. Operability, maintenance and repair 6

- models with extended or bellows construction

5.1. Gland packing 6

5.2. Valve seat and block 6

5.3. Changing the bellows 7

6. Model with pneumatic P/R drive 8

6.1. Changing the operating mode of the drive 9

6.2. Replacing a membrane 10

7. Other drives 10

8. Diagrams / Spare parts lists 11

9. Contacting us 20

To ensure trouble-free and safe operation of the valve, it is essential to be familiar with the contents of this BR11 Instruction

Manual, and also with the general instructions for installation and operation, before installing and operating the valve.

Failure to observe or comply with these operating instructions will invalidate the manufacturer’s guarantee and liability. The

manufacturer’s general conditions of sales and terms of delivery shall apply unless otherwise stated.

Manual BR11 Version 1.2 19.11.2019

1. FUNCTIONAL PRINCIPLE

The valve regulates mass-flow by a linear movement of the valve spindle, which may be operated pneumatically, electrically

or manually. As the stroke of the valve alters, the circular gap between the valve seat and the valve block is increased or

reduced. This directly influences the amount of fluid flowing through the valve.

2. INSTALLATION

The valve may be mounted in any position; however, for valves of DN 80 size and above, vertical installation with the drive

mounted above is preferred. For valves with extended construction, bellows, or drives weighing more than 50 kg, a suitable

support or suspension mounting should be provided for the drive, otherwise its own weight might cause wear and leakage at

the seals.

3. OPERATING CONDITIONS

Regulator valves should be operated under conditions that take into account the size and nature of the construction and the

type of material. To ensure trouble-free operation over the whole operational lifetime, the regulator valve and its accessories

should be regularly inspected and maintained.

Normal operating conditions:

a) With pneumatic positioning drive

Ambient temperature from - 25 to + 80°C, with silicone diaphragm of -40 °C to +80 °C

Relative humidity up to 98 %,

The control and feed air supplies must contain no mechanical impurities, oil or corrosive substances, copper or

aluminium alloys, and must be dehumidified such that the dew-point corresponds to a temperature that is at least

10 °C lower than the operating temperature of the position controller and the positioning drive.

b) With electrical positioning drive

In accordance with the manufacturer’s instructions.

c) With hand-operated drives of type NN

Ambient temperature from - 25 to + 80°C

Relative humidity up to 98 %.

Manual BR11 Version 1.2 19.11.2019

4. OPERABILITY, MAINTENANCE AND REPAIR - STANDARD CONSTRUCTION

The operability of the regulator valve during use is based on maintaining an appropriate flow characteristic and not

exceeding the permitted leakage level for the valve.

To ensure long-term correct and safe operation of the valve, it is essential to carry out regular recorded inspections. Valves

that operate continuously should be checked at least every 6 months. Valves that operate discontinuously should be

checked at least every 12 months.

If it is necessary to carry out maintenance or repair work on the regulator valve, it should be carried out as follows:

4.1. Gland packing

A key criterion for operability is external seal-tightness, which is provided by the gland packing.

The gland packing to be used is normally pre-specified based on the operating conditions.

With normal gland packing, the tightness of the seal is achieved by tightening the sealing nut.

WARNING:

When the valve is supplied, the sealing nut is only hand-tightened. Before putting the valve into service, it is

essential to tighten the sealing sufficiently to achieve an adequate contact pressure, thus ensuring a secure

external seal, but without blocking the valve spindle.

If self-adjusting sealing glands are used, the constant contact pressure is provided by a stainless steel spring. For this

reason, the sealing nut should be screwed in up to the stop.

To change the gland packing, proceed as follows:

Before changing the gland packing, ensure that the valve is not under pressure and is not contaminated.

1. Loosen the upper part of the valve by opening the casing nuts (21) between the casing and the top of the valve.

2. Lift the upper part of the valve out of the casing, along with the valve spindle and the valve block. Loosen the coupling

nut and counter-nut (35,37) and the lock-nut (36), and unscrew them from the valve spindle.

3. Undo the sealing nut (or screw plug) (12) from the sealing gland, and withdraw the valve spindle and valve block from

the upper part of the valve.

4. Using appropriate tools, remove all parts of the sealing gland (13,14) from the gland packing space, and carefully clean

out the packing space.

5. Fit a new casing gasket (15) and carefully clean the surfaces of the seal in the casing and on the upper part.

6. Insert the valve spindle and the valve block into the upper part of the valve.

7. Carefully locate the upper part of the valve on the valve casing and fasten it in place with the nuts (19).

8. Carefully fit the new sealing gland parts over the valve spindle and into the packing space, taking care to get everything

in the correct order (insert the parts in reverse order to the order in which they were taken out).

9. Screw on and tighten the packing seal nut (12).

10. Screw the counter-nut and coupling nut (35,37) and the lock-nut (36) on to the valve spindle and connect the drive and

the valve solidly back together.

Manual BR11 Version 1.2 19.11.2019

4.2. Replacement of the valve seat and the valve block

If it is necessary to change the valve seat and valve block due to a change in the operating conditions or due to wear and

tear, proceed as follows:

Before making the change, ensure that the valve is not under pressure and is not contaminated.

In order to achieve a better seal when changing the valve seat and valve block, we recommend lapping the seat and the

block with a fine abrasive paste.

Replacing the valve block

1. Loosen the upper part of the valve by opening the casing nuts (21) between the casing and the top of the valve.

2. Lift the upper part of the valve out of the casing, along with the valve spindle and the valve block. Loosen the

coupling nut and counter-nut (35,37) and the lock-nut (36), and unscrew them from the valve spindle.

3. Undo the sealing nut (or screw plug) (12) from the sealing gland, and withdraw the valve spindle and valve block

from the upper part of the valve.

a) For Kvs = 0.01...1, the whole valve spindle is replaced, because the valve spindle and valve block are a single part.

b) For Kvs = 1.6...16; Kvs = 63...630 (for DN 150...250) and Kvs = 0.01...1, and for models with extended construction

or bellows.

Knock out the dowel pin (6) using a punch, and unscrew the valve block; screw in a new block, drill it and knock in a

dowel to secure it in place again.

c) For Kvs = 25...160 (for DN 40...100):

Unscrew the spindle from the block (4) and take out the insert (5). Place the insert on the spindle and screw it into a

new valve block.

5. For a pressure-balanced valve block, the same procedure is used as for a normal block; however, when re-

introducing the valve spindle into the upper part of the valve, take care not to damage the auxiliary edge-seal on the

valve block.

6. Push the spindle with its new valve block into the upper part of the valve.

7. Carefully place the upper part of the valve into the valve casing and fasten it down with the nuts (19).

8. Tighten the gland seal nut.

9. Screw the counter-nut and coupling nut (35,37) and the lock-nut (36) on to the spindle and couple the drive and the

valve solidly together again.

Replacing the seat

1. Loosen the upper part of the valve by opening the casing nuts (21) between the casing and the top of the valve.

2. Unscrew the valve seat (3) in counter-clockwise direction, using a suitable seat wrench.

3. Take a new or repaired valve seat, thoroughly clean the threads, lightly smear the seal cone with lubricant, and

screw it in place.

4. Re-assemble the valve as when changing the valve block (items 7-9 above).

Manual BR11 Version 1.2 19.11.2019

5. OPERABILITY, MAINTENANCE AND REPAIR – MODELS WITH EXTENDED OR BELLOWS CONSTRUCTION

The regulator valve’s operability during use is based on maintaining an appropriate flow characteristic and not exceeding the

permitted leakage level for the valve.

To ensure long-term correct and safe operation of the valve, it is essential to carry out regular recorded inspections. Valves

that operate continuously should be checked at least every 6 months. Valves that operate discontinuously should be

checked at least every 12 months.

If it is necessary to carry out maintenance or repair work on the regulator valve, it should be carried out as follows:

5.1. Gland packing

A key criterion for operability is external seal-tightness, which is provided by the gland packing.

The gland packing to be used is normally pre-specified based on the operating conditions.

With normal gland packing, the tightness of the seal is achieved by tightening the sealing nut.

WARNING:

When the valve is supplied, the sealing nut is only hand-tightened. Before putting the valve into service, it is

essential to tighten the sealing sufficiently to achieve an adequate contact pressure, thus ensuring a secure

external seal, but without blocking the valve spindle.

If self-adjusting sealing glands are used, the constant contact pressure is provided by a stainless steel spring. For this

reason, the sealing nut should be screwed in up to the stop.

For models with extended and bellows construction, the gland packing is changed as described in item 4 above.

5.2. Replacement of the valve seat and the valve block

If it is necessary to change the valve seat and valve block due to a change in the operating conditions or due to wear and

tear, proceed as follows:

Before making the change, ensure that the valve is not under pressure and is not contaminated.

In order to achieve a better seal when changing the valve seat and valve block, we recommend lapping the seat and the

block with a fine abrasive paste.

Replacing the valve block

The procedure is identical to that described for models of normal construction; however, please note:

1. a) For Kvs = 0.01 ...16; Kvs = 63...630 (for DN 150...250) Knock out the dowel pin (6) using a punch, and unscrew

the valve block; screw in a new block, drill it and knock in a dowel to secure it in place again.

b) For Kvs = 25...160 (for DN 40...100):

Unscrew the spindle from the block (4) and take out the insert (5). Place the insert on the spindle and screw it into

a new valve block.

2. To avoid damage in the models with metal bellows (the version with insulating section does not have a bellows),

take care that no torque is applied to the bellows when unscrewing the valve block and screwing it back in. We

recommend applying an opposing torque to the valve spindle.

Replacing the seat

Exactly as described in item 4.2 above.

Manual BR11 Version 1.2 19.11.2019

5.3. Replacing the bellows

1. Loosen the upper part of the valve by opening the casing nuts (21) between the casing and the top of the valve.

2. Lift the upper part of the valve out of the casing, along with the valve spindle and the valve block. Loosen the

coupling nut and counter-nut (35,37) and the lock-nut (36), and unscrew them from the valve spindle.

3. Loosen the gland nut on the cover. Loosen the coupling nuts (99) on the bellows and take off the cover flange and

the drive.

4. Loosen the cover (sleeve) (91), to expose the bellows.

5. Remove the valve block (4) from the bellows as described in item 5.2.

6. Withdraw the bellows spindle extension with the metal bellows welded on to it, drawing it upwards out of the

bellows cover (89).

7. Clean the surfaces of the seal on the connecting piece.

8. Fit a new bellows seal (87) and insert the bellows. Fit a new cover seal (93) and replace the cover, then screw the

cover flange back in place with the connecting nuts (99).

9. Tighten the gland nut.

10. Screw the valve block back into the bellows, as described above.

11. CAUTION

Take great care that no torque is applied to the bellows when unscrewing the valve block and screwing it

back in.

12. Screw the counter-nut and coupling nut (35,37) and the lock-nut (36) on to the valve spindle, and connect the drive

and the valve solidly back together.

Manual BR11 Version 1.2 19.11.2019

6. PNEUMATIC P/R DRIVE

When the pressure rises in the drive pressure chamber, a force is applied to the membrane in the drive unit. If this force

exceeds the spring force of the springs in the second chamber, the springs are compressed and the drive spindle starts to

travel out or in, according to the function. If the pressure continues to increase, once the maximum spring force is reached

the springs will be pressed against the end-stop and the drive will halt. Thus, a simple pneumatic drive can reach a defined

position in proportion to the air pressure.

The size of the drive is based on the cm

surface of the membrane.

Drive

size

Stroke

[mm]

Spring range (kPa)

1 2 3 4 5 6 7

20 - 100 40 - 200 40 - 120 0 - 240 60 - 140 120 - 2 0 1 0 - 3 0

No. of

springs

Total

tenstion

[mm]

No. of

springs

Total

tenstion

[mm]

No. of

springs

Total

tenstion

[mm]

No. of

springs

Total

tenstion

[mm]

No. of

springs

Total tenstion

[mm]

No. of

springs

Total tenstion

[mm]

No. of

springs

Total

tenstion

[mm]

250 20 3 - 6 - 3 - 6 - 3 6 6 6 - -

400 20 3 - 6 - 3 - 6 - 3 6 6 6 - -

630 3 3 - 6 - 3 10 6 10 3 10 + 10 6 10 + 10 12 10 + 10

1000

3 3 - 6 - 3 9,5 6 9,5 3 9,5 + 9,5 6 9,5 + 9,5 12 9,5 + 9,5

50 3 - 6 - 3 12,5 6 12,5 3 12,5 + 12,5 6 12,5 + 12,5 12 12,5 +

12,5

63 3 - 6 - 3 16 6 16 3 16 + 16 6 16 + 16 12 16 + 16

Spring range and drive sizes for pneumatic drives of type P/R

P type drive: Single membrane drive.

Safe position NO (open on loss of pressure)

When pressure rises in the upper chamber, the drive spindle travels out.

R type drive: Single membrane drive.

Safe position NC (closed on loss of pressure)

When pressure rises in the lower chamber, the drive spindle travels in.

Manual BR11 Version 1.2 19.11.2019

6.1. Changing the operating mode of the drive

No additional components are required in order to alter the direction of operation of type P/R pneumatic drives.

Changing P to R and vice versa

1. Disconnect the valve from the drive.

2. Ensure that no air pressure is applied to the drive.

3. Remove the top cover of the position drive, taking care that the tensioning nuts (long nuts) (82) are unscrewed to

the ends – in accordance with the notes on the warning label.

The further steps in the procedure depend on the current operating mode of the drive before it is changed.

To change the drive function from P to R, proceed as follows:

4. Undo the special nuts (34) from the bolts on the positioning drive.

5. Remove the membrane with its membrane plate, spacer ring, washer and spacer cover (or spacer covers for drive

sizes 630 and 1000).

6. Remove the springs (31) from the lower casing.

7. Turn the membrane together with all the parts as listed above through 180 degrees, and fit the membrane back

over the drive bolts.

8. Screw the special nuts (34) on to the drive bolts, thus compressing the whole of the above group of components.

9. Place the springs on the membrane plate so that they fit in the guide cut-outs and their ends are aligned with the

axis of the bolts.

10. Place the top cover over the springs and initially tighten the tensioning nuts (82).

11. Compress the springs evenly until the upper part of the drive end-stop is pressed against the lower part, then insert

the rest of the bolts and screw on the nuts.

To change the drive function from R to P, proceed as follows:

4. Remove the springs (31) from the membrane plate (28).

5. Undo the special nuts (34) from the bolts on the positioning drive.

6. Remove the membrane with its membrane plate, spacer ring, washer and spacer cover (or spacer covers for drive

sizes 630 and 1000).

7. Place the springs in the designated locations in the lower cover.

8. Turn the membrane together with all the parts as listed above through 180 degrees, and fit the membrane back

over the drive bolts, so that the 6 mm diameter opening on the base and the nut on the edge of the drive membrane

plate are axially aligned with one of the openings on the edge of the membrane.

9. Screw the special nuts (34) on to the drive bolts, thus compressing the whole of the above group of components.

10. Place the springs on the membrane plate (28) so that they fit in the guide cut-outs. To check that the springs are in

the correct position, rotate the membrane (to the position of the notch on the nut at the edge of the membrane

plate) until the 6 mm opening on the base is visible. By sighting through the opening, check that there is a spring in

place on the underside.

11. Place the top cover over the springs and initially tighten the tensioning nuts (82).

12. Compress the springs evenly until the upper part of the drive end-stop is pressed against the lower part, then insert

the rest of the bolts and screw on the nuts.

Manual BR11 Version 1.2 19.11.2019

6.2. Changing the membrane

Should it be necessary to change a membrane, the drive should be dismantled as described in item 6.1. Instead of putting

the drive back together in reverse order, it should simply be re-assembled in its original order after changing the membrane.

7. OTHER DRIVES

It is possible to equip model BR11 valves with electrical drives. Sizing the drive to the regulator valve is normally a part of

the bidding process.

It is also possible to supply model BR11 valves with a purely manual operation (type NN), or to fit the pneumatic drive with

an additional hand-wheel (type P/R-N).

(See the following diagrams)

Tabla de contenidos

Otros manuales de Unidad de control de preVent

preVent

preVent ZSN1 Manual de usuario

preVent

preVent BR13 Manual de usuario

preVent

preVent BR51 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario

preVent BR11 Manual de usuario

Manuales populares de Unidad de control de otras marcas
