Prestigio Nobile 1560

Notebook Computer

User’s guide

Notebook Computer User’s guide

Original Issue: January 2005

Changes may be made periodically to the information in this publication without obligation to notify any person of such revision

or changes. Such changes will be incorporated in new editions of this manual or supplementary documents and publications. This

company makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically

disclaims the implied warranties of merchantability or fitness for a particular purpose.

Record the model number,serial number,purchase date, and place of purchase information in the space provided below.The serial

number and model number are recorded on the label affixed to your computer.All correspondence concerning your unit should

include the serial number, model number,and purchase information.

NotebookComputer

ModelNumber :

SerialNumber:

PurchaseDate:

Placeof Purchase:

All trademarks and registered trademarks are the properties of their respective companies.

2PRESTIGIO NOBILE 1560

ENG

Preface

Thisnotebook computer incorporates the latestmobile technologiesin a slim and portablepackage. Thismanual should

answermost ofthe questions youhaveabout the day-to-dayoperation ofyour notebook computer.Youshould also take

advantageof the onlinehelp files thatare availablewith almost allof the programsshipped with yourcomputer.

We hope you enjoy your notebook computer.With proper care,your computer will provide you with years of productive

service.

Connecting the computer

Connectingthe computeris as easy as 1-2-3.

1. Insert the battery at anangle (1); press gently onthe battery (2) until it clicksinto place. Then slide thebattery lock to

thelock position(3).

Note: When using a battery pack for the first time, fully recharge the battery,then disconnect the

adapter to use up the battery before recharging again. Perform this action twice to condition the

battery pack.

2.Connect one end of theAC adapterto the DC-inport

onthecomputer’srearpanel(1);connect thepowercord

to the AC adapter (2) and the other end to a properly

groundedpower outlet(3).

3.Press thedisplay cover releaselatch (1)and openthe

display (2) to a comfortable viewing angle. Press the

powerswitch(3)toturn onthepower.ThePOST(power-

onself-test)routineexecutes and Windowsbeginsload-

ing.

Note: To turn off the power, use the Windows Turn

Off command to shut down the computer. If you are

unable to shut down your computer normally, press

and hold the power switch for more than four

seconds to turn off the computer. If you turn off the

computer and want to turn it on again, wait at least

two seconds before powering up.

PRESTIGIO NOBILE 1560

ENG

Care and maintenance

Taking care of your computer

Your computer will serve you well if you take care of it.

• Do not expose the computer to direct sunlight.Do not place it near sources of heat,such as a radiator.

•Do not exposethe computer totemperatures below 0.C(32.F) or above50.C (122.F).

•Do not subjectthe computerto magnetic fields.

•Do not expose the computer to rainor moisture.

•Donot spill wateror any liquid on thecomputer.

•Do not subject the computerto heavyshock and vibration.

•Do not exposethe computer todust anddirt.

•Never placeobjectson topof thecomputer toavoiddamaging thecomputer.

•Never placethe computer onuneven surfaces.

Taking care of your AC adapter

Here are some ways to take care of your AC adapter:

•Do not connectthe adapter to any otherdevice.

•Do notstepon thepower cordor place heavyobjects ontop ofit.Carefully routethe powercordand anycables away

from all potential traffic.

•When unpluggingthe powercord, donot pullon thecord itself butpull onthe plug.

•The total ampere ratings of the equipmentplugged in shouldnot exceed theampere rating ofthe cord ifyou are

usingan extension cord.Also, the totalcurrent ratingof all equipmentplugged into asingle wall outlet should not

exceedthe fuserating.

Taking care of your battery pack

Here are some ways to take care of your battery pack:

• Use only batteries of the same kind as replacements.Turn the power off before removing or replacing batteries.

•Do not tamperwith batteries. Keepthem awayfrom children.

•Dispose ofused batteries accordingto localregulations. Recycleif at all possible.

Cleaning and servicing

Whencleaning thecomputer,follow these steps:

1.Power off thecomputer and removethe batterypack.

2.Disconnect theACadapter.

3.Use a softcloth moistenedwith water.Donot useliquid or aerosolcleaners.

Contactyour dealer orsee your servicetechnician ifany of thefollowing occurs:

•The computerhas beendropped orthe bodyhas beendamaged.

•Liquid hasbeen spilledinto theproduct.

•Thecomputerdoes notoperatenormally.

4PRESTIGIO NOBILE 1560

ENG

Getting familiar with your computer

Thiscomputercombines high-performance,versatility,powermanagementfeaturesandmultimedia capabilities witha

uniquestyleand ergonomicdesign.

Workwith unmatchedproductivity andreliability withyour new powercomputingpartner.

Thischapter givesan in-depth“tour”of thecomputer’s manyfeatures.

A tour of your computer

Letusshow youaround yournewnotebookcomputer.

Note: Computer housing design might differ from the illustrations.

Front view

# Item Description

1 Display cover latch Press to unlatch the display cover.

2 Optical drive Accepts a CD or DVD

3 LED indicator Lights up when the optical is active

4 Eject button Press to eject the drive tray

5 Emergency eject hole Insert a pin to eject the drive tray when power is off

Note: Optical drive may be DVD-ROM, DVD/CD-RW, DVD-Dual, or DVD Super Multi drive.

Top view

PRESTIGIO NOBILE 1560

ENG

# Item Icon Description

1 Display screen Also called LCD (liquid-crystal display),displays computer output.

2 Status indicators LEDs (light-emitting diodes) that turn on and offto show the status

of the computer and its functions and components

3 Power button Turns on the computer power

4 Launch keys Buttons for launching frequently-used programs

5 Touchpad Touch-sensitive pointing device which functions like

a computer mouse

6 Microphone Inputs sounds and voices into your computer

7 Click buttons The left and right buttons function like the left and right mouse

(left and right) buttons

8 Palm rest Comfortable support area for your hands when you use the computer

9 Keyboard Inputs data into your computer

10 Speakers Outputs sound.

11 Audio DJ control panel Control buttons for playing audio.

Left view

# Item Icon Description

1 Volume control Adjusts the volume.

2 4-in1 card slot Accepts a Secure Digital (SD), Memory Stick (MS), xD-Picture Card (xD)

or MultiMediaCard (MMC) memory card.

3 ExpressCard slot Accepts one ExpressCard/34 or one Express/54 module.

4 PC Card slot Accepts one Type II 16-bit PC Card or 32-bit CardBus PC Card.

5 PC Card eject button Ejects the PC Card from its slot.

Right view

# Item Icon Description

1 Security keylock Connects to a Kensington-compatible computer security lock.

6PRESTIGIO NOBILE 1560

ENG

Rear view

# Item Icon Description

1 DC-in jack Connects to an AC adapter.

2 S-video out port Connects to a television or display device with S-video input

3 External monitor port Connects to a display monitor (up to 2048x1536 resolution).

4 Modem jack Connects a phone line (only for models with an internal fax/data

modem).

5 Network jack Connects to an Ethernet-based network.

6 IEEE 1394 port Connects to a IEEE 1394-compatible (4-pin) device

(e.g., digital video camera).

7 USB ports Connect to USB devices (e.g., USB digital camera

8 Line-in jack Accepts audio line-in devices (e.g., audio CD player, stereo walkman).

9 S/PDIF line-out jack Connects to audio line-out devices (e.g., speakers, headphones);

supports S/PDIF connections.

Bottom view

PRESTIGIO NOBILE 1560

ENG

# Item Icon Description

1 MXM Graphic Module™ slot Accepts a Mobile PCI Express (MXM) Module daughterboard.

2 Name card slot Accepts a calling card-sized name card.

3 Memory module slots Accepts DDR2 memory modules.

4 Hard disk bay Houses the computer’s hard disk.

5 Battery bay Houses the computer’s battery pack.

6 Battery release latch Unlatches the battery to remove it.

7 Battery lock Locks/unlocks the battery pack.

Features

Thiscomputer was designed withthe user inmind. Here arejust a fewof its many features:

Performance

•Intel® Pentium® MProcessor (up to745/1.8 GHz)

•Formodel 1558:15.0-inchTFT(ThinFilmTransistor)LCDat1024x768XGA(eXtended GraphicsArray)resolutiondisplaying

in32-bit colordepth with Intel® 915GM chipset

•Memory upgradeable to2 GBwith 2 PC2-3200/PC2-4200 (400/533 MHzDDR2) soDIMMslots

• SATA hard disk

•Lithium-Ion battery pack

•Power management system

•Dual view capability

•Simultaneous LCDand CRT display

•External display support up to1024x768 (85Hzor higher) resolution

Multimedia

•Audio DJ panelfor playing music CDs withoutpowering on thesystem

•AC’97 2.2-compliantstereo audio

•S/PDIF line-out jack

•Built-in microphone

• DVD/CD-RW combo drive, DVD-ROM drive, DVD Dual drive (option) or DVD Super Multi drive (option)

•S-video output port

Connectivity

•High-speed fax/data softwaremodem

•Ethernet LAN 10/100Mbps

•802.11b,802.11b+gor802.11a+b+g wirelessLAN(option)

Human-centricdesign and ergonomics

•Sleek, smooth,slim andstylish design

•Full-sized keyboard

•Ergonomically-centered touchpadpointing device(can beenabled ordisabled thruthe hotkeyFn-F6)

•Launch keys

•Audio DJ panel

Expansion

•Upgradeable memory and hard disk

•CardBus (PCMCIA type-II socket)

8PRESTIGIO NOBILE 1560

ENG

•ExpressCard (ExpressCard/34 or ExpressCard/54 module)

• USB 2.0

•IEEE 1394 (6-pin)

• 4-in-1 card slot (Secure Digital (SD), Memory Stick (MS), xD-Picture Card (xD) or MultiMediaCard (MMC)

Display

Thegraphics displayoffers excellent viewing,display qualityand desktop-performancegraphics. The computersupports a

largeThin-FilmTransistor(TFT)liquidcrystaldisplay(LCD)displaying upto16.7 millioncolors at1024x768XGAresolution.

Simultaneous display

Thecomputer’s crispdisplay andmultimedia capabilities aregreatforviewing moviesorgiving presentations.If youprefer,

youcanalso connectanexternalmonitor whengivingpresentations. This computersupportssimultaneous LCDandexternal

display output via the external display port or the S-video output port. Simultaneous display allows you to control the

presentationfromyourcomputerand atthesame timefaceyouraudience.Youcan alsoconnect otheroutputdisplaydevices

suchas LCDprojection panelsfor large-audience presentations.

Power management

Thepowermanagementsystemincorporatesan“automaticLCDdim”featurethatautomaticallydimstheLCDwhenthecomputeris

poweredbyabatterypacktoconservebatterypower.See“Powermanagement”formoreinformationonpowermanagementfeatures.

Opening and closing the display

To open the display,press the display cover latch and lift up the cover,then tilt it to a comfortable viewing position.See

“Connectingthecomputer” onpage vii. Thecomputer employsamicroswitch thatturnsoff thedisplay(e.g., entersstandby

mode)to conserve powerwhen youclose thedisplay cover,and turns it back onwhen youopen thedisplay cover.

To closethe displaycover,fold it downgently untilthe displaycoverlatchclicksinto place.

Caution:To avoid damaging the display, do not slam it when you close it.Also,do not place any

object on top of the computer when the display is closed.

Indicators

Thecomputer has seven easy-to-read statusindicators (LEDs)under the displayscreen.

PRESTIGIO NOBILE 1560

ENG

ThePowerand Standbyindicatorsare visibleevenwhenyou closethedisplay coversoyou can seethestatus ofthecomputer

whilethe cover is closed.

# Item Icon Description

1 Wireless communication Lights when the wireless LAN (optional) capabilities are enabled.

2 Power Lights when the computer is on. Blinks when a battery-low condition

occurs.

3 Standby Blinks when computer enters Hibernation mode

4 Media activity Lights when the hard disk, or CD or DVD drive is active

5 Battery charge Lights when the battery is being charged

6 Caps lock Lights when Caps Lock is activated.

7 Num lock (Fn-F11) Lights when Numeric Lock is activated.

Keyboard

Thekeyboard hasfull-sized keyswith anembedded keypad,separate cursor keys,two Windowskeys andtwelve function

keys.

Special keys

Lock keys

Thekeyboard has three lock keyswhich youcan toggle onand off.

Lock Key Description

Caps Lock When Caps Lock is on, all alphabetic characters typed are in uppercase.

Num Lock When Num Lock is on, the embedded keypad is in numeric mode. The (Fn-F11)

keys function as a calculator (complete with the arithmetic operators +, -, *, and /).

Use this mode when you need to do a lot of numeric data entry. A better

solution would be to connect an external keypad. See “External keyboard”.

Scroll Lock When Scroll Lock is on, the screen moves one line up or down when (Fn-F12) you

press /\ or \/ respectively. Scroll Lock does not work with some applications.

10 PRESTIGIO NOBILE 1560

ENG

Embedded numeric keypad

Theembedded numerickeypad functionslike adesktop numerickeypad. Itis indicatedby smallcharacters locatedon the

upperright cornerof the keycaps.Tosimplify the keyboard legend,cursor-controlkeysymbols arenot printedonthe keys.

Desired Access Num Lock On Num Lock Off

Number keys on embedded keypad Type numbers in a normal manner.

Cursor-control keys Hold Shift while using cursor-control keys. Hold Fn while using cursor-control

on embedded keypad keys.

Main keyboard keys Hold Fn while typing letters on Type the letters in a embedded

keypad.normal manner.

Windows keys

Thekeyboard hastwo keysthat performWindows-specific functions.

Key Description

Windows logo key Start button. Combinations with this key perform special functions.

Below are a few examples:

Windows logo key + Tab (Activates next Taskbar button)

Windows logo key + E (Explores My Computer)

Windows logo key+ F (Finds Document)

Windows logo key + M (Minimizes All)

Windows logo key + Shift + M (Undoes Minimize All)

Windows logo key + R (Displays Run dialog box)

Application key Opens the application’s context menu (same as right-click).

Otros manuales para NOBILE 1560

Tabla de contenidos

Otros manuales de Computadora portátil de Prestigio

Prestigio

Prestigio VISCONTE 120 Manual de funcionamiento

Prestigio

Prestigio NOBILE 156 Manual de funcionamiento

Prestigio

Prestigio Nobile 1530 Manual de usuario

Prestigio

Prestigio PSB116A Manual de usuario

Prestigio

Prestigio PSB141C05 Manual de usuario

Prestigio

Prestigio CAVALIERE 142 Manual de funcionamiento

Prestigio

Prestigio Visconte 1220 Manual de usuario

Prestigio

Prestigio NOBILE 157 Manual de usuario

Prestigio

Prestigio Nobile 1522W Manual de usuario

Prestigio

Prestigio PNT10131DEDB Manual de usuario

Prestigio

Prestigio NOBILE 159W Manual de usuario

Prestigio

Prestigio Signore 152 Manual de funcionamiento

Prestigio

Prestigio Signore 153 Manual de funcionamiento

Prestigio

Prestigio Nobile 158W Manual de funcionamiento

Prestigio

Prestigio Avanti 1592W Manual de usuario

Prestigio

Prestigio Nobile1590W Manual de usuario

Prestigio

Prestigio Nobile 1440W Manual de usuario

Prestigio

Prestigio SMARTBOOK PSB141S01 Manual de usuario

Prestigio

Prestigio Nobile 158W Manual de usuario

Prestigio

Prestigio Visconte1300 Manual de usuario

Prestigio

Prestigio PSB116A Manual de usuario

Prestigio

Prestigio Aero 1214 Manual de usuario

Prestigio

Prestigio NOBILE 156 Manual de usuario

Prestigio

Prestigio Nobile 1522E Manual de usuario

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
