Prestigio RoadRunner PCDVRR515 Manual de usuario

Guía de inicio rápido

Prestigio RoadRunner PCDVRR515

1. This package includes

• Prestigio car DVR • Strap mount • Car charger cable

• Car charger • Warranty card • Strap

• Tripod mount (x2) • Car mount • Quick start guide

2. Your device at a glance

1Lens 7Micro HDMI port

2Microphone 8Power/menu/emergency button

3Micro SD card slot 9Status indicator

4Tripod mount 10 Record button

5LCD display 11 Speaker

6Micro USB port

Getting started

3. Insert a micro SD card

Micro SD

card

Before starting to record a video, please, insert a micro-SD

card (not included) into the micro-SD card slot of the device.

(1) Insert a micro-SD card with the goldcoloured contacts

facing downwards..

(2) Push the micro-SD card into the slot until it locks in place.

Note:

After inserting the micro-SD card, the device will automatically

recognize it as the default storage, and all the data will be

saved on this card.

4. Charging

• Using the USB cable: Connect the device to the USB port of a PC/notebook.

• Using the car charger: Connect the device to the car charger. The device will start charging

Guía de inicio rápido

Prestigio RoadRunner PCDVRR515

after you start your car engine. The device will automatically turn on and begin recording.

When the engine stops, the device will automatically save the latest file and turn off.

Note:

Before using the device for the first time, please use the included USB cable to connect it to a PC

or notebook to fully charge the battery. It takes 2-3 hours for the charging to complete.

5. Power on/power off

• Mount the device in the vehicle by using the car mount, and then press the power button to

turn it on. To power off the device, press and hold the power button for 2 seconds.

• You can also connect the device to the car charger. It will automatically turn on and start

recording when the car engine starts.

6. Recording

• Connect the device to the car charger, when the car engine starts, the device will start and

loop recording after 5 seconds. When the car engine stops, the device will save the latest file

and turn off after 15 seconds.

Note:

(1) Press [ ] on loop recording, the current file will be saved and the device enters standby

mode.

(2) When the micro SD card is full, the device will delete the first unlocked video file

automatically.

Settings

7. Camcorder operation

In preview mode, press [ ] to enter settings. Use [ ]/[ ] to navigate the menu.

8. Settings menu

The car DVR has eight settings. Advanced settings can be set up via the Prestigio mobile control

app.

Icon Settings Description

Playback Play recorded images

Portable Mode Select Portable mode to record normal videos.

Car Mode Select Car mode to start loop recording or

emergency recording.

WiFi Enable/Disable WiFi connection.

Cloud Enable/Disable the internet cloud connection.

Voice Record Enable/Disable voice recording (car mode only).

Guía de inicio rápido

Prestigio RoadRunner PCDVRR515

Auto Record Enable/Disable auto recording when car

engine starts (car mode only).

Screen Auto Off Screen turns off after 60 seconds of idling (car mode

only).

Factory Settings Reset to default settings.

9. Record modes overview

Mode Portable Mode Car Mode

Record type Normal Loop Emergency

Record trigger Press [ ] in preview

• Car impact

• Press during loop

recording

Record duration Unlimited 3-min. sections

1-min. section

(30 seconds before

and after the event)

Display info. 00:06:36

SD card remaining time

2014/01/01 21:06:36

Current date & time

Notes:

• During loop recording, oldest files will be over-written if the micro-SD card is full.

Playback and media connection

10. Playback on your TV

(1) Connect the car DVR to a TV with a micro-HDMI cable (not included).

(2) Turn on the car DVR. Follow instructions on the TV screen or refer to your TV user manual.

11. Connect to your PC

(1) Connect the car DVR to a PC with the included micro-USB cable.

(2) Find video files under "My computer\Removable Disk\".

(3) Copy, move, delete, or playback your videos on your PC.

Wireless & APP

Before using wireless connections, download and instal the Unieye Drive app from Google Play

Store or Apple Store.

12. Local function

Before using mobile app's location-related functions, ensure the car DVR Wi-Fi is on and Cloud

setting is off. Once Wi-Fi is ready, preview shows the car DVR name (R2-xxxxxxxx) for a few

seconds.

• Connects the car DVR to your smartphone

(1) For Android: Turn on Wi-Fi.

Guía de inicio rápido

Prestigio RoadRunner PCDVRR515

Fore iOS: Go to Settings > Wi-Fi. Turn on Wi-Fi.

(2) Run Unieye Drive.

(3) Tap Local and select the car DVR to enter Local view page.

Notes:

• The smartphone cannot connect to the car DVR while it is recording.

• For the first time, no password is required. You can set the password in Setup.

Icon Description Icon Description

View

• Enable quad-view for

multiple live recordings on your

smartphone.

• In quad-view, select a window

for single view.

Album Capture photos.

Setup Record videos.

Voice control: talk to the car DVR

from your smartphone

Record videos and save the files on

the micro-SD card inserted in the

car DVR.

Flip an image upside-down.

13. Internet functions

Before using app's Internet functions, ensure the Internet setup has been completed.

•Internet setup

(1) After connecting the car DVR to your smartphone. Enter Setup.

(2) Go to Setup > Internet Settings > Edit Email and AP.

(3) Tap Save to complete Email & AP settings.

Notes: AP (Access Point) can be a wireless router, 3G/4G mobile

Internet connection, or a 3G/4G mobile Hotspot.

Guía de inicio rápido

Prestigio RoadRunner PCDVRR515

• Connects to cloude server

Enable Cloud [ ] in the car DVR to sync video recording to a cloud server. Connecting

status will show on the screen.

Status Description

The connection is successful. The preview shows [ ] and the

car DVR ID.

• Invalid AP name or password.

• Weak Wi-Fi signal or not in Wi-Fi coverage.

Connection fail:

• No Internet or cloud server accessible.

• Blocked by a firewall.

• Remote Internet live view

(1) Connect your smartphone to the Internet (via Wi-Fi, 3G/4G).

(2) Run Unieye Drive and tap Internet.

(3) For adding the car DVR or using another smartphone to view, tap [ ]

to enter the car DVR ID and password.

(4) Tap the car DVR ID/name to view Internet live videos.

Safety precautions

Please read all safety precautions before using Prestigio Roadrunner 525w. Please follow all

procedures outlined in this Quick Start Guide to correctly operate the device.

• Do not attempt to disassemble or alter any part of the device that is not described in this

guide.

• Do not place the device in humid areas or allow it to contact water or any other liquids. The

device is NOT designed to be liquid-proof.

• In the event of liquid entering into the device, immediately disconnect the device from the

computer. Continuing use of the device may result in fire or electrical shock. Please consult

your product distributor for the nearest support center.

• To avoid risk of electrical shock, do not connect or disconnect the device with wet hands.

• Do not place the device near a heat source or directly expose it to flame or heat.

• Never place the device in vicinity of equipments generating strong electromagnetic fields.

Exposure to strong magnetic fields may cause malfunction or data corruption and loss.

Guía de inicio rápido

Prestigio RoadRunner PCDVRR515

Technical Specifications

Image sensor 3.0MP

Video quality 1920*1080 (30fps)/1280*720 (30fps)

Video format MP4 (H.264)

Backend chipset Ambarella A7LA55

Lens 2.45mm/F2.4 fixed focus

Lens view angle 160°

G-Sensor 3-axis G-Force sensor

LCD 2.0”, 480*234

Battery Li-ion 700mAh

Battery life 60min (record mode)

Internal memory 128MB

External memory Micro SD/SDHC/SDXC, up to 64GB

Wi-Fi IEEE 802.11 b/g

Video Storage Capacity

Storage card(G) 32 GB 16 GB 8 GB 4 GB

1920*1080 FHD 185 min 64 min 56 min 29 min

Cláusula de exención de responsabilidad

Debido a la mejora y actualización constantes de los productos Prestigio, es posible

que el software y el hardware del dispositivo tengan aspecto ligeramente diferente

u otras funciones distintas a las expuestas en esta Guía de inicio rápido.

Por la presente, Prestigio declara que este RoadRunner cumple los requisitos básicos y demás

prescripciones pertinentes de la Directiva Europea 1999/5/CE. La versión completa de la

declaración de conformidad está disponible en

http://www.prestigio.com/compliance.
