Prestige PE1M2LEDZ Manual de usuario
1PE2LEDZ - PE1M2LEDZ / FLRS Owners rev A.
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
Owner’s Guide
For Models:
PE2LEDZ
PE1M2LEDZ
Flashlogic FLRS
RF Upgrade Kit
22018 Voxx Electronics Corporation. All rights reserved.
Table of Contents
Using Your Remote Control .......................................................3
Remote Start Valet Mode............................................................4
2WayRemoteControlNotications.........................................5
Remote Control Programming...................................................5
ReplacingRemoteControlBatteries ........................................6
3PE2LEDZ - PE1M2LEDZ / FLRS Owners rev A.
Using Your Remote Control
Two Stage Door Unlock (Optional)
If this feature is enabled on your system, pressing the button one time will unlock
only the driver’s door. Press again within three seconds to unlock the remaining
doors.
Activating the Trunk Release Feature (Optional)
If this feature is enabled on your system, pressing and holding the button for 3
seconds will open the vehicle’s trunk or hatch.
Door Lock
To lock the vehicle doors press and release the button.
Door Unlock
To unlock the vehicle doors press and release the button.
Remote Starting Your Vehicle
To activate the remote vehicle start function, press and release the button 2
times within 2 seconds. The vehicle will start and run the predetermined time set up
during installation (5 to 60 minutes selectable).
Remote Start Shutdown
Press and release the button 2 times within 2 seconds to turn the vehicle o.
Pressing the vehicle’s brake will also shutdown the remote start.
Using the Personal Protection Alarm (Panic) (Optional)
If this feature is enabled on your system, press and hold the button for 3 seconds
to activate the personal protection alarm. To stop the alarm, press and hold the
button on the transmitter again for 3 seconds.
42018 Voxx Electronics Corporation. All rights reserved.
Remote Start Valet Mode
Enter / Exit Valet mode for systems using an Flashlogic FLRS kit.
1. Cycle ignition ON ve times [5x OFF/ON] rapidly. (complete this step
within 7 seconds)
2. Wait, LED 1 (on the FLRS kit) will turn solid RED for 2 seconds.
3. Turn ignition to OFF position.
4. Valet Mode Programming Procedure completed.
NOTE: In Valet Mode, the Remote starter is not functional. On units with Keyless
Entry, Lock and Unlock will remain functional. To exit valet mode: repeat steps 1 to 4.
Entering the Vehicle while it is Running via Remote Vehicle Start
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote vehicle starter will disengage and
the vehicle will operate normally.
NOTE: This feature may not be available on all vehicle makes/models. In some
vehicle applications the the remote start will shut down upon entering the vehicle and
the engine will stop running. For these applications it will be necessary to restart the
vehicle normally. Refer to installing dealer for details.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
5PE2LEDZ - PE1M2LEDZ / FLRS Owners rev A.
2WayRemoteControlNotications
FUNCTION BEEPS/LEDFLASHES
Lock 1 Beep / Flash
Unlock 2 Beeps / Flashes
Trunk Release 2 Beeps / Flashes
Remote Start Activation RS Activation Melody
Conrm Remote Start 4 Beeps / Flashes
Remote Start Running 1 Flash per 5 seconds for duration run time
Remote Start Shutdown RS Shutdown Melody
Car Find / Panic 2 Beeps / All LEDs Flash per 3 seconds -
Repeats 9 times
Remote Control Programming
1. Cycle ignition ON ve times [5x OFF/ON] rapidly. (complete this step
within 7 seconds).
2. Press 1 button of each transmitter you wish to program, the LED’s will
ash to conrm each transmitter.
3. Turn the ignition OFF.
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.
62018 Voxx Electronics Corporation. All rights reserved.
ReplacingRemoteControlBatteries
5 Button Remote Control - Model 185SP (PE2LEDZ Only)
The CR2032 battery inside each remote control should last approximately 1 year under
normal use. When the battery becomes weak you will notice the remote control range
(the distance from the vehicle the remote control will work) deteriorate and the small LED
on the remote control will dim. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
2 Way LED Remote Control - Model 185TWSP (PE2LEDZ Only)
The CR2450 battery inside the 2-way LED remote control should last approximately 6
months under normal use. When the battery becomes weak you will notice the remote
control range (the distance from the vehicle the remote control will work) deteriorate and
give an additional ash upon button presses. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
7PE2LEDZ - PE1M2LEDZ / FLRS Owners rev A.
2 Way LED Remote Control - Model 18TWLOR (PE1M2LEDZ Only)
The CR2450 battery inside the 2-way LED remote control should last approximately 6
months under normal use. When the battery becomes weak you will notice the remote
control range (the distance from the vehicle the remote control will work) deteriorate and
give an additional ash upon button presses. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
82018 Voxx Electronics Corporation. All rights reserved.
Voxx Electronics Corporation.
Customer Service 1-800-225-6074
www.PrestigeCarSecurity.com
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
PATENTED: www.voxxintl.com/company/patents
