PowerVision PowerDolphin Manual de usuario
PowerDolphin
V1.0
快速入门指南
CN
Quick Start Guide
EN
クイックスタートガイド
JP
目录 /CONTENTS
快速入门指南
Quick Start Guide
クイックスタートガイド
1
EN
PowerDolphin
PowerDolphin is a water-surface vehicle that can sail autonomously. Equipped with a robotic camera
arm the PowerDolphin can shoot 4k video and take12 MP photos above and below the water surface.
In addition, you can attach the PowerSeeker sonar to the bottom of the PowerDolphin, to locate sh,
check water temps, and render terrains. You can also attach our bait container or attach a shing line
to the payload feature on the back of the PowerDolphin for precise bait drops. The remote controller
and the Vision+ 2 App provide real-time image transmission and many other features.
On/Off button
Radio antenna
Propeller
Payload system
Hook
Fitting pin
Camera electric joint
Camera manual joint
Battery cover
Rubber plug
microSD card slot
Reset button
Micro USB port
Intelligent battery
Fish nder port
2
EN
You can use the remote controller to operate your PowerDolphin wirelessly with a range of up to 2400
ft, and display real-time zero latency high resolution image’s back to your mobile device through the
Vision+ 2 App. In addition, the collapsible mobile device stand folds right into the remote and can
hold any size iOS and android mobile phone.
Remote
3
EN
Mobile device stand
Antenna
Control stick
Mode buttons
Cruise mode (C)
Normal mode (N)
Underwater mode (U)
Lock/Unlock button
Smart return button
Custom button
(Unhook/Bait button by default;
can be customized in the App)
Power button
Charging port (Micro USB)
Photo button
Video button
Image transmission port (USB)
16 Camera joint control thumbwheel
• Underwater mode (U): suitable for low-speed, underwater scenarios like snorkeling.
The maximum speed is restricted; the camera electric joint can be adjusted for many different views.
• Normal mode (N): This mode is for general high-speed fun and water-surface FPV
scenarios.
The maximum speed is 10mph; the camera electric joint in N mode is set to its initial position and
cannot be adjusted into the water.
• Cruise mode (C): Cruise control function. Take off, release the throttle stick and just steer
the PowerDolphin.
The maximum speed is 10mph; the camera electric joint in C mode is set to its initial position and
cannot be adjusted into the water.
[Notes]:To Enter Cruise mode: Hold the throttle stick in a position for 2s then release.
To Exit Cruise mode: Just move the throttle stick again to regain speed control.
16
4
EN
Fish nder
Fishing line connector Charging port Fish luring lamp
Introduction
Installation
[Notes]:When the PowerSeeker is connected to another mobile device, it cannot connect to
PowerDolphin. Make sure the connection to the PowerSeeker of others phones before using with
PowerDolphin.
5
EN
Charging and battery level
Charging
Download the App to watch the video tutorial of PowerDolphin
Please scan the QR code or go to your App store to download Vision+ 2,
and watch the video tutorial in the App.
Fish nder charging portFish nder charging portRemote charging port
6
EN
2. Fish nder
Battery level
1. Remote (LED indicators)
>60% <20%20%-60%
7
EN
3. Intelligent battery
Level
Low High
Prepare PowerDolphin
1. Install the battery and secure it into place.
1. Ensure that the rubber plug is secured into place to guarantee water prong.
2. Make sure that the battery-sealing ring is intact before installing the battery. Damage to the
rubber seal will result to a unusable battery. The rubber seal can be found under the lip of the
battery top.
