MI TOWER+
ASSEMBLY GUIDE
FOR MI TOWER+
+44 (0)1244 833 933info@popupproducts.co.uk popupproducts.co.uk
MI TOWER+ ASSEMBLY GUIDE (Rev.02 20-02-2020)
CONTENTS
CONTENTS
INTRODUCTION
KNOW YOUR MITOWER+
KNOW YOUR MITOWER+’S COMPONENTS
KNOW YOUR KIT LIST AND SPECIFICATIONS
KNOW YOUR STORAGE AND TRANSPORT PACK
SAFETY DOS AND DON’TS - ALWAYS
SAFETY DOS AND DON’TS - NEVER
BEFORE YOU START
1
2
3
4-5
6
7
8
9
10
GETTING STARTED
MITOWER+ 2M - ASSEMBLY
MITOWER+ 3M - ASSEMBLY
MITOWER+ 4M - ASSEMBLY
MITOWER+ 5M - ASSEMBLY
MITOWER+ 6M - ASSEMBLY
10 POINT PRE-USE SAFETY CHECKLIST
REGISTRATIONS
11
12-13
14-15
16-17
18-19
20-21
22
23
ASSEMBLY GUIDE
FOR MI TOWER+
INTRODUCTION
M TOWER+ is a safe, versatile and high quality tower. It can be built by ONE PERSON and provides a work
platform for up to TWO PEOPLE. It is designed in accordance with the latest testing and quality standards.
Our priority is to help ensure the safe operation of our products, so please pay particular attention to the safety
tips on pages and .
We want you to enjoy the safe and responsible use of M TOWER+ with the minimum of fuss and this guide is
designed to get you up and running as quickly and as safely as possible.
We recommend that you read this guide prior to assembling and using your M TOWER+.
Scan this QR code to view the video of M TOWER+ in operation.
Visit PASMA and HSE for further reference.
www.popupproducts.co.uk/videos/mitower+
Page 2
KNOW YOURMI TOWER+
Page 3
1
2
3
4 RUNG FRAME
TOE BOARD
TELESCOPIC STABILISER
PARTS LISTING
4
5
6
ADJUSTABLELEG AND CASTOR
GUARDRAIL BRACE PANEL
HATCH PLATFORM
1
2
3
4
5
6
KNOW YOUR MI TOWER+ COMPONENTS
Page 4
1 GUARDRAIL BRACE PANEL
jaw which is released by simply moving the jaw’s trigger. The claw must only be
attached to the frame with the opening facing outward. Attachment with the
jaw’s opening facing inward will not fully protect the user if lent upon and may
cause serious injury or death. Always ensure that each claw is positively locked in
position before using your tower.
2 FRAME CLIPS
The frame clip’s pin locates into a retaining hole in the frames to lock tower
sections together when placed one on top of the other. The pin is locked in place
by a red tab to ensure that it remains in place. From the disengaged position,
pivot the pin / tab to bring the pin horizontal. Insert the pin fully through the
3 STABILISER COUPLER CLAMP
tube and set the buckle on to the hook, then close the clamp arm to lock the
The coupler clamps are used to secure the stabilisers to the tower’s vertical
4 WIND-LOCK CATCH
Disengaged Engaged
Component
Hanger
Retract
Extend
The wind lock catches comprise of a set of auto-engaging hooks at one end
of the platform and a single gravity type catch at the other. The purpose of
these devices is to prevent up-lift of the platforms in windy conditions. To
engage the auto wind lock (AWL) simply tilt the platform at the angle shown
before placing the hooks onto the rung of the end frame. Lower the
opposite end of the platform onto the opposite end frame rung and the
gravity type lock will automatically engage. Simply lift and hold the gravity
lock before tilting the platform to dis-engage the opposite AWL hooks when
removing the platform on tower disassembly.
5 PLATFORM WITH BUILT IN COMPONENT HANGERS
Component
Hanger
Retract
Extend
Friction
Clip
To enable one man to erect E products each hatch s fitted th
four component hangers which are stowed (two either side) within the
platform’s frame. The hangers can be extended when needed and retracted
when not.
To extend a hanger simply pull up the friction clip and pull the component
hanger until it stops. To retract the hanger, simply reverse the procedure.
KNOW YOUR MI TOWER+ COMPONENTS
Page 5
7 ADJUSTABLE LEG AND CASTOR
The adjustable leg and castor allows for accurate positioning of
your MI TOWERin relation to your workplace. The leg can be
extended or retracted to allow for levelling and the brake must be
applied to prevent movement.
Adjustment Collar
Extend
Retract
Brake
OFF
ON
Engagement
Spring
KNOW YOURKIT LIST AND SPECIFICATIONS
Page 6
4 RUNG FRAME
TELESCOPIC OUTRIGGER
HATCH PLATFORM
GUARDRAIL BRACE PANEL
220MM ADJUSTABLE LEG
125MM LOCKING CASTOR
TOE BOARD SET
MITOWER+ WEIGHT (KG)
PLATFORM SAFE WORKING LOAD (KG)
GROUND CONDITIONS
3.55
4.35
12.20
4.15
0.85
2.45
6.50
Weight (Unit)
kg
6
4
1
4
4
4
1
87.20
240
2m
qty
8
4
2
6
4
4
1
114.80
240
3m
qty
10
4
2
7
4
4
1
126.05
240
4m
qty
COMPONENT MATRIX AND WEIGHTS
12
4
3
9
4
4
1
153.65
240
5m
qty
14
4
3
10
4
4
1
164.90
240
6m
qty
8m
7m
6m
5m
4m
3m
2m
1m
MI TOWER+ Platform Height
240kg
KNOW YOUR STORAGE AND TRANSPORT PACK
Page 7
TRANSPORT AND STORAGE
For ease of storage and of transportation,
MI TOWER+ has been designed so that all
components can be safely stored within the
tower’s base assembly. See illustration.
Product shown is MI TOWER+ 4m
TROLLEY COMPONENTS
1
2
3
4
5
GUARDRAIL BRACE PANELX2
TOE BOARD SET
HATCH PLATFORM
ADJUSTABLE LEG AND CASTOR X4
4 RUNG FRAME X2
1
2
3
5
4
SAFETY DOS AND DON’TS - ALWAYS
Page 8
ALWAYS Read and understand this guide before you begin assembly.
Ensure that all safety requirements are met and that MI TOWER+ is the correct access solution
for the task you wish to perform.
ordon o the ork area creatng a one th a radus that s m greater than the total heght
of MI TOWER+.
Wear the correct Personal Protective Equipment for the task being performed. Gloves, steel
toecap boots, a hard hat and suitable clothing must be worn by all persons.
Ensure that E s assembled and dsmantled b a ualfied competent person.
Tie back long hair and remove items of loose jewellery.
Perform a full risk assessment prior to assembling or using MI TOWER+ and abide by your
findngs
Prevent access to unauthorised persons if you have no ohter option but to leave MI TOWER+
unattended and if this is not possible then MI TOWER+ must be dismantled.
Carry tools and materials safely retained in a tool belt that allows freedom of movement.
Ensure you properly assess the risk/method if tools or materials are hoisted to the platform via
a rope.
Access platforms from within MI TOWER+ and via the 4 rung frames positioned at the platform’s
trap door end. Keep your feet in the middle of the rungs and grip the upper rungs with your
hands.
Erect MI TOWER+ on smooth level ground that is capable of supporting its own weight, the user
and any tools or materials without subsidence.
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
ALWAYS
SAFETY DOS AND DON’TS - NEVER
Page 9
NEVER Use MI TOWER+ if you don’t understand something in this guide; please contact the supplier
for advice.
Assemble, use, move or dismantle MI TOWER+ if you are tired or unwell or if you are under the
Use MI TOWER+ in adverse weather conditions which may endanger the user.
caused by buildings close to each other.
Assemble or use MI TOWER+ near overhead hazards such as power lines that are within reach
of MI TOWER+ or the user.
Ascend or descend your MI TOWER+ if both hands are not free.
Add banners, notice boards, etc. to MI TOWER+.
Use MI TOWER+ if contaminated by paint, chemicals, etc.
Overload the platforms (see component matrix page 5).
Suspend MI TOWER+ from another structure.
Lean from MI TOWER+ and never apply undue side force.
Stand on the guardrails, toe boards, boxes (or similar) to gain extra height. If the working
heght s nsucent ether construct E to the reured heght or use an alternate
Method.
Use damaged components in your MI TOWER+ assembly.
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
NEVER
