Polygroup TG76M3AJIC03 Manual de usuario

MODEL #: TG76M3AJIC03 / TG76M3AJIC01 / TG76M3AJIC04

Fig. B - Tree and Light Assembly

Fig. A - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

*Electrical Rating For The Tree

(For Indoor Use Only)

2.04 A 120 V 60 Hz

3. Each tree section is numbered with a sticker. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into

the assembled stand. Make sure the pole is firmly inserted and secured into the stand.

5. Remove the protective cap from the upper section(s) and insert into the lower section(s). Continue until the tree top is

inserted.

6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch

hinges.

7. Connect the plug(s) securely to the extension cord(s) as per the color labels indicated in Fig. B and insert the green label

extension cord plug into the wall outlet. Your entire tree should now be lit. If some bulbs do not light or flickers, search for

any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in order to maintain the performance and life

expec tancy of your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out

one to the right, one to the left and one at the center of the main stem.

(See Fig. C)

Top view Side view

Fig. C

Insert

Green Label

Plug Into Wall

Outlet

Tree top

Section 2

Section 1

Insert Red Label

Plugs Into Red

Labeled Extension Cord

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR 1-888-919-0070

NEED HELP?

TREE ASSEMBLY INSTRUCTIONS

Congratulations onpurchasing your new tree from Polygroup®! Carefully follow the instructions below on how to quickly and

easily set up your new tree.

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to fill

any gaps. Your Christmas tree is now complete and ready to be decorated.

For Pre-lit Trees, If The Tree Does Not Illuminate

STORAGE INSTRUCTIONS

Loose Hinge Pin

TROUBLESHOOTING TIPS

1. Remove all ornaments and decorations. For pre-lit trees, first unplug extension cord from the wall outlet and then disconnect light

extension cord between each section of the tree.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section below

and fold all branches toward the pole.

3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and rotate the upper pole in both

directions. Lift up the upper pole again.

4. Continue by gently lifting straight up each section(s) from the section below and fold all branches toward the pole until the bottom

section is removed from the tree stand.

5. Carefully place all tree sections into shipping box and tape it shut.

6. When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to excessive heat or humidity

may damage your tree.

7. Keep out of reach of pets and children.

1. Please check to make sure that all plugs are properly connected according to the color labels indicated in

Fig.B

and the power

cord is plugged into the wall outlet. Refer to assembly guide for instructions.

2. Please check for blown fuses at the light string plugs and power cord plug. Replace as needed.

Note: Please make sure to use appropriate replacement fuses as indicated on the light string plug and power cord plug.

3. Please check for loose, broken or missing light bulbs and replace as needed.

1. Extra hinge pins are included for repairing the hinges.

Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secureusing

the retainer washer.

(See Fig. D)

SPARE PARTS

Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs and fuses are also included. If extra parts are needed, please

contact our customer service center.

CUSTOMER SERVICE FOR CHRISTMAS TREES

Customer Name:

Address(No P.O. Boxes):

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070

or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
