Polygroup TG66FY012D00 Manual de usuario

MODEL #: TG66FY012D00

3. Each tree section is numbered with a sticker. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and insert it into the assembled stand.Make sure the

pole is firmly inserted and secured into the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch hinges.

7. Connect the light strings as per the color labels indicated in Fig. B and insert green label adapter into the wall outlet.Your entire tree

should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace

bulbs promptly in order to maintain the performance and life expectancy of your pre-lit tree.

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

Congratulations on purchasing your new tree from Polygroup®! Carefully follow the instructions below on how to quickly and

easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

*Electrical Rating For The Tree

(For Indoor Use Only)

Input: 120VAC, 60Hz, 0.16A

Output: 29V 0.28A

Fig. B - Tree and Light Assembly

Fig. A - Tree Stand Assembly

Click

Pull apart the legs of the stand so that they

are snapped into an x-shape, place the tree

stand on a level surface.

To close the stand, press the metal button

and fold the legs together.

Tree top

Section 1

Section 2

Adapter

To Be Plugged

Into Wall

Outlet

Insert Green

Label Extension

Cord into Adapter

Control box

Insert red Label

Plugs Into Red

Labeled Extension Cord

NEED HELP?

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR 1-888-919-0070

Top view Side view

Fig. C

1. Remove all ornaments and decorations. For pre-lit trees, first unplug adapter from the wall outlet and then disconnect light

extension cord between each section of the tree.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section

below and fold all branches toward the pole.

3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and rotate the upper pole in

both directions. Lift up the upper pole again.

4. Continue by gently lifting straight up each section(s) from the section below and fold all branches toward the pole until the

bottom section is removed from the tree stand.

5. Carefully place all tree sections into shipping box and tape it shut.

6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to excessive heat or

humidity may damage your tree.

7. Keep out of reach of pets and children.

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to

fill any gaps.Your Christmas tree is now complete and ready to be decorated.

STORAGE INSTRUCTIONS

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected according to the color labels indicated in Fig.B and the adapter

is plugged into the wall outlet. Refer to assembly guide for instructions.

2. Check for loose connection between light string plugs and extension cords.

3. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.

Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure

using the retainer washer. (See Fig. D)

TROUBLESHOOTING TIPS

Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs are also included. If extra parts are needed, please contact

our customer servicecenter.

SPARE PARTS

Lamp Replacement

Step 1.

Unplug from power source, by pulling out the adapter itself - do not pull on the power cord.

(For reference only)

Step 3. Replace with a new

spare LED lamp (included).

Step 2. Lift up the lamp lock tab, and

pull the bulb and its plastic base

straight out from the lampholder.

8. Begin to shape the branches and tips working from the bottomto the top. Start with tips farthest from the pole and fan out one to

the right, one to the left and one at the center of the main stem. (See Fig. C)

CAUTION:

1.To reduce the risk of fire and electric shock:

a) Use only the power supply that was provided with this product;

b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal, and

c) Do not mount or support strings in a manner that can cut or damage wire insulation.

2. Use only the adapter supplied with this product. Using a different adapter will damage the lights and may cause fire, or

electrical shock hazards.

Press the selector button on the “Dual Color Light Controller” or

“Remote Controller” to select among: 1. CLEAR AND MULTI-COLOR ALTERNATING;

2. CLEAR LIGHTS; 3. MULTI LIGHTS and (4) TURN OFF BOTH LIGHTS.

DUAL COLOR LIGHT CONTROLLER & REMOTE CONTROL

Light

Controller

Selector

Button

Remote

Controller

Insulation Tab

REMOTE CONTROL INSTRUCTIONS

1. Remove the insultation tab.

2. Press the button to select from different light functions (see DUAL COLOR LIGHT CONTROLLER & REMOTE CONTROL).

2. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed

with the correct polarity (+ and -).

3. Retighten the screw to close and secure the battery cover.

Cover

Battery

CR2032

BATTERY REPLACEMENT

1. Loosen the screw of the battery cover with a screwdriver (not included).

WARNING

1. DISPOSE USED BATTERY PROPERLY. OBSERVE LOCAL REGULATIONS REGARDING DISPOSAL OF HAZARDOUS WASTE.

2. ENSURE THE BATTERIES ARE INSTALLED CORRECTLY WITH REGARD TO POLARITY (+ AND -).

3. This product is powered by a lithium battery. Due to their small size, lithium batteries can easily be swallowed by children.

Ingestion of such batteries has been known to cause death.

4. This product contains a lithium battery which if swallowed has been known to cause death.

5. DO NOT EXPOSE LIGHT SET TO MOISTURE.

6. REMOVE BATTERIES WHEN NOT USED FOR AN EXTENDED PERIOD OF TIME, OR WHEN DEPLETED.

7. CLEAN THE BATTERY CONTACTS PRIOR TO BATTERY INSTALLATION.

8. The external flexible cable or cord of this luminaire cannot be replaced; If the cord is damaged, the luminaire shall be destroyed.

9. Dispose of used batteries properly by following directions on batteries.

10. Use only CR2032 batteries for the remote controller.

11. DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK.

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070

or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address(No P.O. Boxes):

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:
