From Bicom Systems Wiki

Contents

1 Introduction

■

2 Requirements

■

2.1 Identifying phone model

■

2.2 Phone firmware

■

2.3 DHCP server

■

2.4 PBXware version

■

3 Installation

■

3.1 Power adapter

■

3.2 Power over Ethernet (PoE)

■

3.3 Find the phone IP address

■

3.4 Reset to factory settings

■

4 Registering phone

■

4.1 Manual configuration

■

4.2 Auto Provisioning

■

4.3 Using TLS

■

5 Configure BLF

■

5.1 Extension Settings

■

6 Additional Configuration Template

■

Introduction

This Configuration Guide is written as general guide on how to configure the Poly Edge B30

phone model to work with PBXware 6.6.1.

Requirements

Identifying phone model

To start and successfully complete registration of your Poly Edge B30 phone you need to know

which phone model you will setup.

From the back of each Poly Edge B30 phone there are exact model information that you should

check. Although different phone models can have exactly the same requirements and

installation procedure, phone models can also have significantly different requirements and

installation procedure, so that ignorance of your own model may result in the inability to

successfully set up your phone.

Phone firmware

Make sure that your phone is loaded with appropriate firmware version, 1.0.1.

■

To find out the firmware version of your Poly Edge B30 phone model open a new browser

■

window and enter your phone IP address in order to access the phone web administration

interface login screen. Example: http://192.168.1.22.

■

factory default login details are username: admin and password: admin.

Go to Status in left navigation menu.

■

Click on System Status.

■

Under Product Information section you can see Software Version field that contains

■

information about firmware version.

DHCP server

Fully configured and operational DHCP server.

PBXware version

PBXware version 6.6.1

In order to find out the PBXware version:

■

Navigate to Settings: About.

■

On the top of About page is a code similar to this one PBXware Edition: Business, Release:

6.6.1. (387597b7), Running: 16.16.1-gc-c0d40968, PBXware Proxy v6.6.1 (7009484),

API: 6, libmemcached version: 1.0.18, where Release denotes the exact version of your

PBXware.

Installation

This chapter describes how to install and connect the phone to the electrical power and data

network as well as how to apply factory settings.

The following topics are covered:

Power adapter

■

Power over Ethernet (PoE)

■

Factory Settings

■

Power adapter

Connect the Network and Power

Connect the DC plug on the power adapter to the DC port on the phone and connect the other

■

end of the power adapter into an electrical power outlet.

Connect the ethernet cable between the Internet port on the phone and the network port on a

■

router or switch to access LAN.

NOTE: If you are using Power over Ethernet (PoE), you don't need to connect the AC adapter.

Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant.

Power over Ethernet (PoE)

Connect the Network (only)

Using a regular ethernet cable, your phone can be powered from a Power over Ethernet (PoE)

compliant router or switch.

Connect the Ethernet cable between the Internet port on the phone and an available port on

■

the in-line power router or switch.

NOTE: If you are using Power over Ethernet (PoE), you don't need to connect the AC adapter.

Make sure the Ethernet cable and router or switch is Power over Ethernet (PoE) compliant.

Find the phone IP address

Find out your Poly Edge B30 phone IP Address.

Press Home button.

■

Go to Product Information.

■

The IP address will be displayed on the top of the display.

Reset to factory settings

This step is not required for brand new out-of-the-box phones, however, if the phone has been

already used then it is a must.

Open a new browser window and enter your phone IP address in order to access the phone

■

web administration interface login screen. Example: http://192.168.1.22.

■

factory default login details are username: admin and password: admin.

Click on System Management menu.

■

Click on Device update menu.

■

Under section Reset Configuration click on Reset button in order to reset the phone to

■

factory settings. Phone will be reset to the factory settings and reboot.

Wait some time for device to reboot.

■

NOTE: Do not unplug or remove power to the phone while it is updating firmware and

configurations.

Registering phone

This chapter describes how to identify Poly Edge B30 phone model, requirements that must be

met and how to register the phone using manual configuration or auto provisioning.

The following topics are covered:

Manual configuration

■

Auto provisioning

■

Manual configuration

This chapter describes how to set UAD settings, create PBXware extension and register the

phone.

The following topics are covered:

UAD settings

■

Creating extension

■

Registering phone

■

UAD Settings

UAD settings

Open a new browser window and enter the IP address in order to access the PBXware web

■

administration login screen. Example: http://192.168.1.10.

■

Navigate to Settings:UAD.

■

Make sure Poly Edge B30 UAD is enabled. To check the UAD status click on the edit icon

■

corresponding to your Poly Edge B30 phone.

Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.

■

Click on the Save button to save changes.

■

Creating extension

Creating Extension

Add Extension

Navigate to Extensions. Click on Add Extension.

■

The standard options window will be shown below.

■

Select Poly Edge B30 phone model from the UAD select box.

■

Select Location: Local or Remote.

■

Local is for all extensions registered on the LAN and Remote is for all extensions

registered from remote networks, WAN, Internet etc.

Click on the Next step button.

■

Extension values

Enter values into the required field text boxes.

REQUIRED FIELDS:

Name

■

Enter a name for the extension being created. Example: John Smith.

E-mail

■

Enter the e-mail address associated with this extension. This e-mail address will receive all

system notification messages. Example: [email protected]

Department

■

Department to which extension will belong to. Example: Sales.

Click on the Save button.

■

Registering Phone

This chapter describes how to register Poly Edge B30 phone using Hostname or IP Address.

The following topics are covered:

Hostname or IP Address

■

Hostname or IP Address

Open a new browser window and enter your phone IP address in order to access the phone

■

web administration interface login screen. Example: http://192.168.1.22

■

factory default login details are username: admin and password: admin.

Click on Service Providers and select Profile A.

■

Enter or set the following details into the SIP section.

■

REQUIRED FIELDS:

Proxy Server

■

Enter the Hostname or IP Address of the PBXware.

- Example for Hostname: voip.bicomsystems.com

- Example for IP Address: 192.168.1.10

Registrar Server

■

Enter the Hostname or IP Address of the PBXware.

- Example for Hostname: voip.bicomsystems.com

- Example for IP Address: 192.168.1.10

Click on Voice Services and select SP1 Service.

■

X_DisplayLabel

■

Usually the same number as the Phone Number.

X_DisplayNumber

■

Usually the same number as the Phone Number.

AuthUserName

■

Your Extension number.

AuthPassword

■

The Secret of the extension as received in the e-mail associated with this extension.

Example: _%Z4M3*Ts9y7. A password is generated automatically for each newly created

extension.

Click on the Submit button, then Reboot button.

■

You'll have to wait sometime prior for the device to reboot. If everything is done as above

■

described, you should have successfully registered your phone to PBXware. Dial *123 to verify

registration.

Auto Provisioning

This chapter describes how to set UAD settings, create PBXware extension and register the

phone using DHCP or Static IP address.

The following topics are covered:

UAD Settings

■

Creating Extension

■

Registering Phone

■

UAD Settings

UAD settings

Open a new browser window and enter the IP address in order to access the PBXware web

■

administration login screen. Example: http://192.168.1.10.

■

UAD settings.

Navigate to Settings:UAD.

■

Make sure Poly Edge B30 UAD is enabled. To check the UAD status click on the edit icon

■

corresponding to your Poly Edge B30 phone.

Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.

■

Click on the Save button to save changes.

■

Creating Extension

Add Extension

Navigate to Extensions. Click on Add Extension.

■

The standard options window will be shown below.

■

Select Poly Edge B30 phone model from the UAD select box.

■

Select Location: Local or Remote.

■

Local is for all extensions registered on the LAN and Remote is for all extensions

registered from remote networks, WAN, Internet etc.

Click on the Next step button.

■

Extension values

Enter values into the required field text boxes.

REQUIRED FIELDS:

Name

■

Enter a name for the extension being created. Example: John Smith.

E-mail

■

Enter the e-mail address associated with this extension. This e-mail address will receive all

system notification messages. Example: [email protected]

Auto Provisioning

■

Set to Yes.

MAC Address

■

Enter Poly Edge B30 phone MAC address. Example: 9CADEF123456. MAC address can

be found at the back of the phone.

Click on the Save button.

■

Registering Phone

This chapter describes how to register Poly Edge B30 phone using TFTP, HTTP or HTTPS.

TFTP, HTTP or HTTPS

Open a new browser window and enter your phone IP address, e.g. http://192.168.1.22.

■

Enter username and password and press Confirm button. NOTE: Factory default login

■

details are username: admin and password: admin.

Click on System Management link in the left navigation menu.

■

Click on Auto Provisioning link in the submenu, and in the ITSP Provisioning section enter

■

the following in the ConfigURL field:

NOTE: Our recommendation is to use the HTTP.

■

Example for Hostname using HTTP:

http://username:[email protected]/prov/phone$mac.cfg

Example for Hostname using HTTPS:

https://username:[email protected]/prov/phone$mac.cf

g,tls-profile=1

Example for IP Address using HTTP:

http://username:[email protected]/prov/phone$mac.cfg

Example for IP Address using HTTPS:

https://username:[email protected]/prov/phone$mac.cfg,tls-profi

le=1

Replace username and password with Auto Provisioning username and password.

■

Example for Hostname using TFTP:

tftp://voip.bicomsystems.com/phone$mac.cfg

Example for IP Address: tftp://192.168.1.10/phone$mac.cfg

Click on Submit button then Reboot button.

■

Auto provisioning process will start during phone reboot process, phone will pickup

■

appropriate configuration file from PBXware. If everything is done as above described, you

should have successfully registered your phone to PBXware. Dial *123 to verify registration.

Using TLS

NOTE: If you choose to use HTTPS as a protocol for registering your device, you will need to

Tabla de contenidos

Otros manuales de Teléfono IP de Poly

Poly

Poly VVX 150 Manual de usuario

Poly

Poly VVX D230 Manual de servicio

Poly

Poly VVX D230 Manual de usuario

Poly

Poly Polycom VVX Series Manual de usuario

Poly

Poly VVX 150 Manual

Poly

Poly Edge E Series Instrucciones de montaje

Poly

Poly VVX 450 Series Manual de usuario

Poly

Poly Edge E Series Manual de usuario

Poly

Poly Edge E Series Manual de usuario

Poly

Poly Edge E Series Manual de usuario

Poly

Poly Edge B Series Manual de usuario

Poly

Poly VVX 600 Instrucciones de funcionamiento

Poly

Poly VVX 350 Manual de usuario

Poly

Poly VVX D230 Manual de usuario

Poly

Poly Rove 20 Manual de usuario

Poly

Poly Edge E Series Manual de usuario

Poly

Poly Rove DECT Manual de usuario

Poly

Poly Edge B Series Manual de usuario

Poly

Poly VVX 300 Manual de usuario

Poly

Poly Edge B Series Instrucciones de montaje

Poly

Poly VVX D23 Manual de servicio

Poly

Poly VVX 250 Manual de usuario

Poly

Poly Edge E Series Instrucciones de montaje

Poly

Poly ROVE Instrucciones de montaje

Manuales populares de Teléfono IP de otras marcas

Alcatel

Alcatel 4028 Manual de usuario

Polycom

Polycom Polycom VVX 600 Manual de usuario

Polycom

Polycom SoundPoint IP 450 Manual de usuario

Cisco

Cisco SPA-500 Series Manual de usuario

Polycom

Polycom SoundPoint IP 650 Manual de usuario

Proximus

Proximus Maestro 3016 IP Manual de usuario

Fanvil

Fanvil X4 Manual de usuario

Cisco

Cisco 7962 Manual de usuario

Snom

Snom 320 Manual de usuario

Yealink

Yealink Yealink SIP-T46G Manual de usuario

Avaya

Avaya 4625SW Manual de usuario

Yealink

Yealink SIP-T52S Manual de usuario

Nortel

Nortel 1140E Manual de usuario

Nexotek

Nexotek NT-P500 Manual de usuario

Avaya

Avaya Integral 5 R3.0 Manual de usuario

GE 28320EE2 - Dect 6.0 InfoLink 2 Manual de usuario

Avaya

Avaya 4600 Series Manual de servicio

Mitel

Mitel MIVOICE OFFICE 400 6940 SIP Manual de usuario
