Polaroid POLWFSC Manual de usuario
Wi-Fi Security Camera
User Manual
POLWFSC
2
Welcome
Welcome to your experience with Polaroid products.
All Polaroid products we bring to you are manufactured to the highest standards of performance and
safety. As part of our philosophy of customer service and satisfaction, your purchase is backed by a
comprehensive 1 Year Warranty.
This user manual tells you all you need to know about setting up and using your new product.
Please take special note of any important safety and usage information presented with the symbol.
3
Contents
Welcome 2
Contents 3
Unpack And Prepare 4
What's in the box 4
Controls and Connections 5
Product Overview 5
Installation 6
Operation 7
Application Installation 7
Registration and Login 8
Add Device 8
Using The Application On Windows 10
Specications 11
Compliance and Responsible Disposal 12
4 | UNPACK AND PREPARE
Before setting up your new Turntable, check you have
everything:
A. Wi-Fi Security Camera
B. Micro USB Cable
C. Power Adaptor
D. Screws (4)
E. Masonry Plugs (4)
F. Warranty Certificate
G. General Safety Warnings
H. User Manual
Unpack And Prepare
What's in the box
D E F G
H
PRODUCT OVERVIEW | 5
Base (top view) Base (bottom view)
Controls and Connections
1. Microphone
2. Wi-Fi Indicator Light
3. Power Indicator Light
4. Wi-Fi Button
5. Micro SD/TF Card Slot
6. USB Interface
7. Button for detaching the camera
(press and pull to seperate)
8. Power-Line Clip
9. Screw Holes
Product Overview
1
2
4
5
8
8 9
6
7
3
6 | INSTALLATION
Installation
1. Unscrew the support beam and remove from base.
2. Use a sharp object (i.e. screw driver) to separate the base and take o the top cover.
3. Mount the base onto the wall using the included screws.
4. Place the top cover back onto the base and screw the support beam on. Attach the camera to the
support beam.
You can place the camera on a desk or mount it to a wall.
To mount it on a wall, follow these steps:
1234
OPERATION | 7
Operation
Application Installation
• Turn the camera on.
• Scan the QR code (you can also scan the code on the
rating label of the product) to download and install
the application.
• For iPhones, search ‘Clever Dog’ in the App store. For Androids,
search ‘Clever Dog’ in the Google Play store.
Download from
App store
Download from
Google Play
8 | OPERATION
Registration and Login
• Open the application and press “Sign Up” to register. If you already have an account, press “Sign In.”
Add Device
• Upon entering the homepage, press "+" and
select "Intelligent Camera." Select the first
camera icon towards the left of your device.
• Check that the Wi-Fi indicator flickers in a
blue light. If not, press the Wi-Fi button until
the light flickers in blue and then select "Yes".
• Note: If asked to allow the application to
access your device's location, press allow.
13 4
2
Note: As the application is
constantly being updated, the
interface screen may slightly vary
to the above picture.
12 3
OPERATION | 9
• For Android: on the add device screen, you
will see a list of cameras. On the back of your
camera, refer to the CID number for the correct
device name. The device name will be "DOG-
[CID] number." Select "DOG-xxxxxx" then
go onto the set Wi-Fi page. Select your Wi-Fi
network and enter the password. The camera
will now connect to the network.
• Note: if the above fails, please operate as the
method used for iPhones (see below).
• For iPhones: go to system settings and press
“WiFi”. Choose “DOG-XXXXXX” to connect,
and enter 11111111 for the password. Once
completed, go back to the application and
press “Next.”
• The screen will show “added successfully.”
and now is ready for use.
10 | OPERATION
Using The Application On Windows
Besides the application for Android and iOS phones, it is also
available for Windows. To download the application for Windows:
1. Go on www.cleverdog.com.cn
2. Click “Service Centre”
3. Click “App download”
Once installed, you can view the real time content on Windows the
same way as you would on your mobile device.
