Polaroid EZ1800 Manual de usuario

OPERATION MANUAL

Polaroid

EZ1800

35MM AUTOMATIC WINDING CAMERA WITH MANUAL ZOOM

1. After the last available picture on the film has been taken and the camera

will not advance the film anymore. Slide the rewind switch (16) towards

the " " direction to rewind the film cassette, see figure 8.

2. Open the back cover after the rewinding stops and remove the film for

processing.

Rewinding the film

The red eye reduction lamp (5) will be active while taking pictures using the

flash (Auto and Fill In flash modes). The lamp helps to reduce the unpleasant

red reflection, visible sometimes on pictures with flash.

1. Press the shutter button half way down to active the red eye reduction lamp.

2. Wait a moment and press all way down to take a picture.

Red eye reduction lamp

1. Turn the

mode dial to the

FILL IN flash mode,

see figure 7.

In this mode the camera will take a picture with the flash,

even under bright daylight conditions. Use this mode if the

subject (person) is under shade or in a shadow, for example

under a tree.

2. Wait a few seconds for the flash ready indicator to light up and take your picture.

Fill-in flash

1. Slide the battery cover (14) and open the battery

compartment.

2. Insert two AA size alkaline batteries. Follow the

steps in figures 1 and 2. Make sure that the batteries

' + ' and ' - ' terminals are in the correct position.

3. Close the battery cover.

Note:

Use only AA, alkaline batteries, do not use

rechargeable batteries and do not mix different types.

Replace the batteries if the recycle time on the

flash exceeds 15 seconds.

Turn OFF the flash after taking pictures, to extend

the battery life.

Loading batteries

Taking pictures

Set the mode dial (1) to the ON position, see figure 4.

2. Hold the camera steady, and compose your picture

looking through the viewfinder eye piece (11).

3. Turn the zoom ring (7) to zoom in on the

photographed scene, as you desire.

4. Press the shutter release button to take a picture.

Note:

After taking your pictures, set the mode dial to the

OFF position. That prevents the camera from

taking unintentional pictures. See figure 5.

Aim your subject with the sunshine behind you,

if possible

. Keep at least 1.2m (4 feet) distance from

your subject for proper focusing.

TOO MUCH FILM LOADING

CORRECT

4. Close the back cover.

5. Turn the mode dial to the ON position. Press the shutter release button (2) twice.

The

motor will advance the film and #1 will appear inside the exposure counter (15).

The camera is now ready for taking the first picture.

Note:

If #1 does not appear inside the exposure window, then the film was probably

not loaded correctly. Repeat the film-loading procedure.

1.Slide the back cover latch (13) and open the back cover (21).

2.Insert the film cartridge into the film chamber (18).

3. Pull out about 50 mm ( 3 inches ) of the film from the cartridge and position

the tip of the film above the take up spool until it reaches the ' film tip ' mark

on the body, see figure 3.

Use typical, 35mm color or B/W negative films with ISO 100, ISO 200,

ISO 400 speed.

Loading the film

Camera type : 35mm film, manual zoom motorized camera

Frame format : 24x36mm

Lens : 33mm to 50mm range zoom, aspherical lens

Focus : fixed focus, 1.2 m ( 4 feet ) to infinity

Exposure : F/10.5 to F/13.5 within 33mm to 50 mm zoom lens

Shutter speed : 1/125 sec.

Viewfindfer : Real image, zoom, clear viewfinder

Flash : Built in. Auto and Fill-in modes.

Flash range : with ISO 100 film, up to 2.5 m ( 8 feet )

ISO 200 film, up to 3 m ( 10 feet )

ISO 400 film, up to 3.5 m ( 12 feet )

Film advancing : Automatic

Film rewinding : Power rewinding

Power source : two AAAlkaline batteries

❥ Specifications subject to change without notice.

Specification

f33mm

f50mm

12. Film type window

13. Back cover latch

14. Battery cover

15. Exposure counter

16. Film rewind switch

17. Film take up spool

18. Film chamber

19. Film rewind shaft

20. Film sprocket wheel

21. Back cover

1. Mode dial

2. Shutter release button

3. CDS sensor

4. Viewfinder

5. Red-eye reduction lamp

6. Flash

7. Zoom ring

8. Lens

9. Whrist strap

10. Flash ready indicator

11. Viewfinder eye piece

Taking pictures with flash

1. Turn the mode dial to the ON position.

In this mode the camera is set to theAUTO flash mode.

The camera will fire a flash automatically, depending on

the brightness of the scene and speed of the used film.

2. Wait a few seconds for the flash ready indicator (10) to light up.

3. Compose your picture and press the shutter release button. The camera

will take a picture and the flash will fire, only if necessary.

Auto-flash

1. Do not disassemble the camera, there is a risk of electronic shock.

2.Do not expose the camera to extreme high or low temperature and humidity,

this may cause serious damage to the camera.

3.If necessary, clean the lens by gently wiping it with a clean, lint-free cloth.

Do not use chemicals or other cleaning agents. Remove the dust from

the film compartment by using an air blower.

4. Choking hazard and small parts, not for children under 6 years.

5. Do not take pictures toward the sun directly, this is harmful to your eyes.

6. Remove batteries if you do not plan to use camera for a long time.

7.Keep it in a cool and dry environment.

Camera care and storage

Please read this manual

carefully, before using the camera.
