POK SA - ZI Les Guignons - 10400 Nogent-sur-Seine - FRANCE
T
el
:
03
25
39
84
78
-
F
ax
:
03
25
39
84
90
-
Email
:
[email protected] -
Site
W
eb
:
ww
w
.pok.fr
1
Presentation
Doc 1822 EN
Rev-A : 20/02/12 The technical informations included in this document might change without any warning. Contact our sales service for further details.
Diameter DN40 (1.5") DN65 (2.5") DN80(3") DN100 (4")
Reference 29342 29383 29390 29396
Note : references without coupling, any type available, has to be precised when the order is placed.
Characteristics Details
Construction • Body in aluminium alloy
• Case in grivory charge with glass
Maximum pressure of use 16 bar / 230 PSI
Working temperature -10°C to 70°C (14°F to 158°F)
Waterproofness IP65
Working ow rates limits
•DN 40 (1.5") : 100 l/min to 1000 l/min (26GPM to 260 GPM)
•DN 65 (2.5") : 300 l/min to 2500 l/min (80 GPM to 660 GPM)
•DN 80 (3") : 500 l/min to 3000 l/min (130 GPM to 800 GPM)
•DN 100 (4") : 1000 l/min to 5000 l/min (260GPM to 1350 GPM)
Accuracy About 3% (if use within the working ow rate limits)
Flow rate results shown in GPM or l/min (parameter dened in factory
Pressure results shown in PSI or bar (parameter dened in factory)
Power supply 9V Battery (6LR61)
Bluetooth Connection kit sold separately
USB 5m USB Cable sold separately
Software Software for PC (Windows XP, Vista, Seven only) sold only with
the USB or Bluetooth® kit.
Bluetooth version 2.0
