PNI CT25PE Manual de usuario

PNI CT25PE

Smart thermostat / Интелигентен термостат

Intelligenter Thermostat / Termostato inteligente

Thermostat intelligent / Intelligens termosztát / Termostato

intelligente / Slimme thermostaat / Inteligentny termostat

Termostat inteligent incastrabil

EN User manual .................................... 3

BG Ръководство за употреба .......... 22

DE Benutzerhandbuch ......................... 44

ES Manual de usuario ........................... 65

FR Manuel utilisateur ........................... 86

HU Használati utasítás .......................... 107

IT Manuale utente ............................... 128

NL Handleiding ..................................... 149

PL Instrukcja obsługi ............................ 172

RO Manual de utilizare .......................... 191

Introduction

PNI CT25PE is a programmable ﬂush mounted thermostat

for electric underﬂoor heating, which turns the heating

system on and o according to the set temperature. You

can set dierent temperatures for dierent time periods

and days.

The thermostat can work and display the temperature in 3

ways:

- according to the ﬂoor sensor

- according to the built-in air sensor

- according to both sensors

How quickly the air in the room heats up does not depend

on the settings of the thermostat, but on the size and the

design of the heating system.

The thermostat has a direct 230V output for electric

underﬂoor heating systems.

Special warnings

As the product must be connected to a 230V mains

supply and to a heating equipment, the installation must

be performed only by qualiﬁed personnel, in order to

avoid irreparable damage to the product or to the heating

equipment to which it is connected, defects which are not

subject to warranty.

Forthe ﬁrst conﬁguration of thethermostat,we recommend

that you call a specialist.

Main features

• Illuminated LCD screen

• 3 operating modes : Eco, Manual and Scheduled

• 4 programmable periods for each day of the week

• Display the set temperature and the room temperature

• Opened window detection function

• Key lock function

• Anti-freeze function

Technical speciﬁcations

• Power supply: 230V

• Maximum load: 16A

• Temperature range that can be set: 5°C ~ 35°C

• Displayed temperature range: 0 ~ +50°C

• Sensor: NTC 10K

• Temperature measurement accuracy: ± 0.1°C

• Temperature setting step: ± 0.5°C

• WiFi 2.4Ghz

• Transmission power: 100mW

• Water resistance: IP30

• Housing: ABS with ﬁre standard UL94-5

Product description

Child protection active

(keys locked)

No external sensor

alarm

Over-heating

protection

WiFi signal level

On/Off

Settings

Down

Open window

detection

Hour

Day of the week

Current period

Connecting the thermostat to the WiFi network

and adding it to the Tuya Smart application

Note: Make sure you have your mobile phone connected to the

2.4GHz WiFi network and the GPS location enabled. For a

quick setup, make sure the phone and thermostat are as close to

each other as possible (1-3 m).

WARNING:

Make sure you have a 2.4 Ghz wireless network available and

that you have connected your phone to it. The new generation

routers and phones also come equipped with a 5 Ghz wireless

network activated, and the devices connect automatically on

this frequency. The thermostat cannot be connected to the

5 Ghz wireless network because it only works on the 2.4 Ghz

frequency. To conﬁgure the router and the 2.4 Ghz wireless

network, call a specialist.

1. Connect your phone to the WiFi network.

2. Download the app Tuya Smart.

Android iOS

3. Open the application, create an account and log in.

4.Add the thermostat to the application by pressing the +

icon in the upper right corner of the screen or by pressing

the Add device button (this button shows only when you

do not have any devices added to the application).

5. Select the option Small Home Appliances on the left side

of the screen.

6. From the list of devices displayed on the right side of the

screen, select Thermostat (Wi-Fi).

7. Select the WiFi network you want to connect to and add

the password. Click Next.

8.In the next interface, select the option EZ Mode from the

upper right corner.

9. Long press the key from the thermostat to enter the

pairing mode. Then, press the key ˄. The icon will

blink on the screen.

10. Then check Conﬁrm the indicator is blinking rapidly.

Click Next.

11. The application will start scanning nearby devices.

12. After you identify your device, you will receive the

Added Successfully conﬁrmation.

13. To ﬁnish, click the Done button.

From the application, you can turn the thermostat on and

o, you can change the operation mode of the thermostat

(Manual, Eco, Auto) or you can set the weekly program.
