PLANTRONICS EXPLORER™300 Series

BLUETOOTH®HEADSET

USER GUIDE_

72357-01 (04-06)

Visit www.plantronics.com/productregistration to register your product online so

we can provide you with the best possible service and technical support.

WELCOME

Thank you for purchasing a Plantronics headset.

Let us provide you with the best possible service and technical support. After you

reviewthis user guide, if you need additional assistance or have any product

questions, please contact:

•Plantronics Technical Assistance Center at 866-363-BLUE (2583)

•www.plantronics.com/support

Before getting started, please review the safety booklet included in the package.

TABLE OF CONTENTS

Package Contents & Features 3

Charging & Powering 5

Pairing 6

Adjusting Fit 7

Using Your Headset 8

Indicator Lights 9

Accessories 10

Troubleshooting 12

Product Specifications 12

Technical Assistance 13

Warranty 13

Regulatory Notices 14

PACKAGE CONTENTS & FEATURES

PLANTRONICS EXPLORER 330

Indicator light

Call control button

Microphone

Adjustable ear loop

Ear tip

Charging jack

Indicator light

Call control button

Microphone

Adjustable ear loop

Ear tip

Charging jack

PLANTRONICS EXPLORER 340 AND 350

PACKAGE CONTENTS & FEATURES

In-car charging

cradle (shown

with vent clip)

AC power adapter

Vent clip

Vehicle

charging

adapter

USB headset

charger

Dash mount

Cradle Mount Options

PLANTRONICS EXPLORER 350

PLANTRONICS EXPLORER 330 & 340

CHARGING & POWERING

Before using, you must first charge your headset.

20 minutes = minimum charge

2hours = full charge

Light is solid red when battery is charging.

NOTE For the best user experience, keep your headset fully charged.

CAUTION Do not use headset while charging and do not connect the charger while

the headset is in use.

CHARGING

POWERING

Press the control button for 2 seconds to power on. Press the control button for

3seconds to power off.

Explorer 330 & 340 Explorer 350

PAIRING

Begin with headset turned off.

1. Press call control button for

6seconds. Release button when

indicator light flashes blue and

red. Headset is ready to pair with

Bluetooth device.

NOTE The headset can pair to

multipleBluetooth devices, but

will only connect to one device

at a time. The headset will auto-

maticallyconnect to the last

device to which it was connected.

2. Whilethe headset is flashing red

and blue, use the phone menu

to search for Bluetooth devices

and select “3XXPlantronics”.

3. When prompted for passkey enter

0000. Headset will flash blue when

paired successfully.

1. 2.

Before using your headset for the first time, you must pair it with your Bluetooth®

phone or device. Be sure the headset is fully charged. For set up and pairing

instructions with Bluetooth devices other than mobile phones, please consult your

Bluetooth device user guide.

ADJUSTING FIT

Place ear loop

behind ear.

Position speaker and

align microphone with

mouth.

Right Ear Left Ear

Lift ear loop. Swivel ear loop to the right or left for

right or left ear wearing.

Pivot headset to

place speaker

intoear.

1. 2.

3. 4. 5.

USING YOUR HEADSET

ADJUSTING THE VOLUME

ANSWERING/ENDING/MAKING CALLS

Briefly push up or down on the call control button for incremental volume steps.

You will hear two tones (high tone followed by low tone) at the volume limit.

WARNING For your comfort, health, and safety, do not exceed moderate

listening levels.

For best performance, position your mobile phone on the same side of your body

as the headset.

To answer or end a call, briefly press the call control button.

Tomake a call, enter number on your phone, press send, and the call is

automatically transferred to headset; no need to press call control button.

USING YOUR HEADSET

ADDITIONAL FEATURES

INDICATOR LIGHTS

Headset Status Headset Indicator Light

Powering on Blue flashes. Repeat.

Powering off Red appears and goes off.

Charging battery Red solid light.

Low battery Red flashes.

Pairing mode Blue/red flashes for 120 seconds.

Missed call Purple flashes. Double press the call control

button to cancel.

Ringing Purple flashes. Briefly press call control button

toanswer the call. Press call control button for

2seconds to reject the call.

Redialing Last Number

To activate last number redial, double

press the call control button. You will

hear a high tone after each double

key press.

Using Voice Dialing

With the headset on, press the call

control button for 2 seconds to

activate the voice dialing.

NOTE To use voice activated dialing,

the voice dialing feature must be

enabled on your phone. See your

Bluetooth phone manual for

instructions.

Rejecting a Call

When receiving an incoming call,

press the call control button for

2seconds to reject the call.

Switching a Call From Phone to Headset

To switch an active call from your

phone to your headset, press the

call control button for 3 seconds.

Switching a Call From Headset to Phone

To switch an active call from your

headset toyour phone, press the

call control button for 2 seconds.

ACCESSORIES

INCLUDED ACCESSORIES

In-car charging cradle and in-vehicle charging adapter – for Explorer 350 only

1. Select vent clip or dash mount option. Attach to rear of in-car charging cradle.

NOTE Select the mounting option that allows the charging cradle to not interfere

with car controls.

2. Insert charging plug into slot on bottom of charging cradle. Be sure to slide to

top of slot.

3. Attach charging cradle to dash mount or vent.

IMPORTANT Clip onto lowest vent slot. Be sure the headset is not directly in the

vent air flow. If headset cannot be positioned out of air flow, use dash mount

instead.

4. Place ear tip as shown in the top of the cradle. Gently press the bottom of the

headset to plug the charging adapter into the charging jack. Then plug in-vehicle

charging adapter into vehicle power.
