Plantronics Explorer 50
User Guide
Congratulations on purchasing your new Plantronics product. This guide contains instructions for
setting up and using your Explorer 50 headset.
Please refer to the safety instructions for important product safety information prior to
installation or use of the product.
Welcome
3
Headset USB charge cable
NOTE Contents may vary by product.
What's in the box
4
Charge port
Call button
Volume button: Cycles through volume settings
Headset LED (indicator light)
Power button
Headset Overview
5
Be safe! Please read the separate safety guide for important safety information.
1Wearing your headset, power it on. The first time you do this it will begin the pairing process. You
hear “pairing” and the headset indicator lights flash red and blue.
2Activate Bluetooth®on your phone and set it to search for new devices.
•iPhone Settings > Bluetooth > On*
•Android™Settings > Bluetooth: On > Scan for devices*
NOTE *Menus may vary by device.
3Select “PLT_E50.”
If necessary, enter four zeros (0000) for the passcode or accept the connection.
Once successfully paired, you hear “pairing successful."
Press the Call button until the indicator light flashes red and blue and you hear "pairing."
Multipoint technology lets you pair a second phone and answer calls on either phone. To pair a
second or a new phone see "Activate pair mode."
Bluetooth headset has up to a 33 feet (10 meters) effective range. If you lose connection, your
headset will try to reconnect. If your headset doesn’t reconnect, tap the Call button or
manually connect through the phone’s Bluetooth device menu.
Your new headset has enough power to pair and make a few calls. It takes 2 hours to fully charge
the headset; the indicator light turns off once charging is complete.
Pair and Charge
Get Paired
Activate pair mode
Use two phones
Reconnect
Charge
6
You can wear your headset on your right or left ear. To adjust the fit, rotate the earloop as shown.
2
1
2
R L
1
Fit
7
Tap the Call button .
Tap the Volume button to cycle through preset levels.
While on an active call, press and hold the Volume button for 2 seconds. You hear “mute on” or
“mute off.”
To call your last number dialed, double tap the Call button .
Press the Call button for 2 seconds, wait for the phone prompt and then tell the phone to dial
the name of a stored contact.
When the headset is powered on and you are not on a call the voice prompts can be turned off by
pushing the volume button and the call button for more than 4 seconds.
The Basics
Answer or end a call
Adjust the volume
Mute
Redial
Voice dial (phone feature)
Toggle Voice Prompt
On/Off
8
Talk Time Up to 11 hours
Standby Time Up to 12 days
Operating Distance
(Range)
Up to 33 feet (10 meters), Class II
Headset Weight 11 grams
Charge Connector Micro USB charging
Battery Type Rechargeable non-replaceable lithium ion polymer
Charge Time
(Maximum)
2 hours for full
Power
Requirements
5V DC – 180mA
Bluetooth Version Bluetooth v3.0
Bluetooth Profiles Hands-Free (HFP) Profile 1.6 and Headset (HSP) Profile 1.2; Advanced Audio
Distribution Profile (A2DP)
Operating
Temperature
32°F - 122°F (0 - 50°C)
Storage
Temperature
-40°F - 185°F (-40 - 85°C)
Charging
Temperature
32°F - 104°F (0 - 40°C)
Specifications
9
EN
Tel: 0800 410014
FI
Tel: 0800 117095
NO
Tel: 80011336
AR
Tel: +44 (0)1793 842443*
FR
Tel: 0800 945770
PL
Tel: +44 (0)1793 842443*
CS
Tel: +44 (0)1793 842443*
GA
Tel: 1800 551 896
PT
Tel: 0800 84 45 17
DA
Tel: 80 88 46 10
HE
Tel: +44 (0)1793 842443*
RO
Tel: +44 (0)1793 842443*
DE
Deutschland 0800 9323 400
Österreich 0800 242 500
Schweiz 0800 932 340
HU
Tel: +44 (0)1793 842443*
RU
Tel: 8-800-100-64-14
Tel: +44 (0)1793 842443*
EL
Tel: +44 (0)1793 842443*
IT
Tel: 800 950934
SV
Tel: 0200 21 46 81
ES
Tel: 900 803 666
NL
NL 0800 7526876
BE 0800 39202
LUX 800 24870
TR
Tel: +44 (0)1793 842443*
*Support in English
Safety information: see the separate “For Your Safety” booklet
2-year limited warranty details: plantronics.com/warranty
Support
NEED MORE HELP?
plantronics.com/support
Plantronics, Inc. Plantronics BV
345 Encinal Street
Santa Cruz, CA 95060
United States
South Point Building C
Scorpius 140
2132 LR Hoofddorp, Netherlands
©2016 Plantronics, Inc. Plantronics, Plantronics Explorer and Simply Smarter Communications are trademarks of Plantronics, Inc. registered in the US and
other countries, and Explorer is a trademark of Plantronics, Inc. Bluetooth trademarks are owned by Bluetooth SIG Inc., any use by Plantronics, Inc. is
under license. iPhone is a trademark of Apple Inc., registered in the US and other countries. All other trademarks are the property of their respective
owners.
Patents pending
203761-06 (11.16)
