Plantronics B230-M Manual de usuario

B230-M

QUICK

START3 EASY STEPS

SET UP,

CONNECT, CALL

QUICK START GUIDE

GUIDE DE DÉMARRAGE RAPIDE

GUÍA DE INICIO RÁPIDO

GUIA DE INÍCIO RÁPIDO

plantronics.com/support

BLUETOOTH WIRELESS

HEADSET SYSTEM

Micro USB

Charger

BT300-M USB Adapter

Voyager PRO UC v2

USB Charging Cable

Software and User Guide CD

Soft Gel Eartips (Small & Large) and

Foam Eartip Covers

Carry Case

What’s in the box

Step 1 Set up your headset and computer

Install the software

To use all the features of your system, install the Plantronics software from

the CD included or download it at plantronics.com/software.

Once the software is installed, Windows users can access the utility by

selecting Start > Programs > Plantronics > Plantronics Control Panel.

Charge your headest

To calibrate your headset and provide optimal performance fully charge the

headset before using. Connect the AC charger to an outlet and the headset.

The headset LED will be solid red to indicate that the headset battery is

charging. When fully charged the LED goes off.

Note To charge the headset with USB charging cable the PC must be on and in

an active state. Charge times using the USB cable will be longer.

Try on your headset

The headset comes conﬁgured for the right ear, with the medium eartip

installed, however you can replace it with the small or large eartip provided.

For the best sound clarity and comfort, make sure you have a secure ﬁt.

Replace the eartip for a better ﬁt

Grip the eartip and gently push it into the speaker housing.1

Rotate it a quarter turn to the left to unlock.2

Pull the eartip away from the headset.3

Headset features

345

1 Volume/Mute button

Increase/decrease volume

Mute during a call

Music or audio: pause/play

Tap + or – buttons per level change

1-second press of both + and – buttons

2Call button

Take a call or end it

Call Back/Redial

Initiate phone’s voice-dialing

Reconnect lost connection

1 tap

2 taps

2-second press until tone heard

1 tap

3 Micro USB charging port With the AC charger, a full charge takes 90

minutes.

4 Power button

On or off

Battery level voice alerts

Activate pairing mode

2-second press

1 tap

Press until LED ﬂashes red/blue

5 LED

Charging

Battery status

Pairing mode

Solid red. When fully charged, LED is off.

Low = 2 red ﬂashes, Critically low = 3 red ﬂashes

Flashes red/blue

Attach a new eartip

Align the tabs on the eartip with the slots on the speaker housing.4

Gently push the eartip into housing while turning it a quarter turn to the5

right. The eartip will stop rotating when it is locked.

You may want to add a foam eartip cover for additional comfort.

Wearing the headset

Guide the earloop behind your ear and position the headset so that the1

speaker and eartip rest comfortably in your ear.

Pivot the boom up to point the microphone toward the corner of your mouth.2

Quick-turn adjustment for the left ear

Pivot the boom into an upright position.1

Rotate the boom and speaker to the other side of the headset and lower it2

before ﬁtting your other ear.

Step 2 Connect (Pair) your headset to your mobile phone

VoyagerPRO UC v2

  

Ready1

Activate the Bluetooth feature on your phone, then use the phone’s settings

to add/search/discover new Bluetooth devices.

BlackBerry® Settings/options > Bluetooth: On > Search for devices.

iPhone Settings > General > Bluetooth > On (starts the search for devices)

Android Phone Settings > Wireless > Bluetooth: On > Scan for devices

Set2

To activate Bluetooth pairing mode, press and hold the power button until

LED ﬂashes red/blue to indicate pairing mode.

Connect3

Select• VoyagerPRO UC v2 from the list of Bluetooth devices shown on your

phone.

If phone asks for a passcode, enter four zeros• 0000. You may see **** on

screen.

Some phones also ask to conﬁrm headset connection after pairing.•

Headset LED will stop ﬂashing red/blue once your phone and headset are•

successfully paired/connected.

Step 3 Call Making calls with Microsoft Ofﬁce Communicator

You can make Microsoft Ofﬁce Communicator calls with your computer using

your Bluetooth adapter which comes automatically paired with your headset.

Ensure the headset is powered on.1

Ensure Microsoft Ofﬁce Communicator is running on your PC.2

Insert the USB adapter into USB Port on the PC. The LED on the adapter will3

ﬂash blue to indicate the adapter is connecting to the headset. The LED will

become solid blue to indicate the adapter is powered on and is connected to

the headset.

Set the headset and microphone volume to a comfortable level using the4

Microsoft Ofﬁce Communicator “Set up Audio and Video” page.*.

Place a call using Microsoft Ofﬁce Communicator. The audio connection to5

your headset will activate automatically when your recipient’s phone begins

to ring. The LED on the adapter will slowly ﬂash blue while you are on an

active call.

* Consult Microsoft Ofﬁce Communicator Help for more information.

Learn More

To learn more about your system features, change default settings or

read troubleshooting tips, refer to the user guide on the CD or online at

plantronics.com/documentation. You can also view online FAQ at

plantronics.com/support. Technical support is available at 1.800.544.4660.

Advanced Features

Auto Answer:

When you are not wearing your headset.

When you have an incoming call on

your mobile or softphone, simply put

on the headset and the call will be

answered automatically. You do not

have to press the call button.

Auto Pause:

When you are listening to streaming

audio.

When you are steaming audio from

your mobile phone or PC. Simply

remove the headset and the streaming

audio pauses. Place your headset back

on and the streaming audio resumes.

Auto Transfer:

Whether you are wearing your headset

or not.

If you are not wearing your headset

and there is an incoming call, the

audio will be routed to the mobile

phone. When you place the headset

on your head, the audio will be routed

back to the headset and will Auto

Answer. In the case where the headset

is already being worn, the audio will

be in the headset and you will need to

press the Call Button to answer the

call.

Auto Lock:

When you are not wearing your headset

This feature locks out the call button

to prevent an accidental call when the

headset is not worn.

Plantronics, Inc.

345 Encinal Street

Santa Cruz, CA 95060

United States

Tel: 800-544-4660

plantronics.com

trademarks or registered trademarks of Plantronics, Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by Plantronics, Inc. is under license. All other trademarks are the property of their respective owners.

Patents US 5,210,791; Patents Pending

84592-04 (09.10)
