Planet VIP-254 Series Manual de usuario

SIP IP Phone

VIP-254T_254PT

Quick Installation Guide

Overview

This quick installation guide describes the objectives; organization and basic

installation of the PLANET VIP-254T/VIP-254PT SIP IP Phone (“IP Phone”

in the following term), and explains how to establish your rst voice over IP

communication via PLANET product. Also, this guide shows you how to nd

additional information on related products and services.

Respective model/descriptions are shown below:

VIP-254T: SIP IP Phone

VIP-254PT: 802.3af PoE SIP IP Phone

The VIP-254 series IP Phone integrate web-based graphical user interface that

can cover most congurations and machine status monitoring. Via standard, web

browser, you can congure and check machine status from anywhere around the

world.

Table of Contents

Preparation before beginning administration on the IP Phone............................... 5

Installation ................................................................................................ 5

Administration Interface.............................................................................. 7

Web conguration access: .................................................................... 7

Network Interface quick congurations .................................................. 8

Voice communication samples..........................................................................10

Peer to peer (P2P) mode.....................................................................10

SIP Proxy mode .................................................................................10

Quick reference in CD-ROM guide ....................................................................12

Document Objectives

This guide provides physical installation, network congurations, and Internet

access establishment information for the PLANET IP Phones.

Document Organization

This guide is organized as follows:

• Preparation before beginning administration on PLANET IP Phone

• Administration interface

• Network Interface quick congurations

• Internet access setup guide

Preparation before beginning administration on the IP

Phone

Installation

VIP-254T: SIP IP Phone (2 x RJ-45)

VIP-254PT: 802.3af PoE SIP IP Phone (2 x RJ-45, 1 x PoE for LAN interface)

Step 1: Connecting Handset

DC5V

Handset

Step 2: Connecting Power AC Power and Network

Plug the Ethernet cable into the back of the base station. Plug the

other end of the Ethernet cable into your already prepared network

connection.

LAN

Power Adapter (5V DC)

NOTE: Use only the power adapter shipped with the unit to ensure

correct functionality.

DC5V

Step 3: Adjust the stand angle.

Press and hole the button of right side

to change the stand mount angle.

1PC RJ-45 connector, to maintain the existing network structure,

connected directly to the PC through straight CAT-5 cable

2LAN

RJ-45 connector, for Internet access, connected directly to

Switch/Hub through straight CAT-5 cable.

The LAN interface also can be connected with 802.3af PoE

switch or converter for power supply (VIP-254PT only)

35V DC 5V DC Power input outlet.

4Handset RJ-11 connector, connected directly to the Handset.

Note

For VIP-254PT, either PoE or AC adapter can be deployed at one

time

Administration Interface

The IP Phone provides GUI (Web based, Graphical User Interface) for machine

management and administration. Key pad administration also available for simple

conguration.

Web conguration access:

To start IP Phone web conguration, you must have one of these web browsers

installed on computer for management

• Microsoft Internet Explorer 6.0.0 or higher with Java support

Default IP address of IP Phone is 192.168.0.1. You may now open your web

browser, and insert http://192.168.0.1 in the address bar of your web browser

to logon IP Phone web conguration page.

IP Phone will prompt for logon username/password, please enter: root / null (no

password) to continue machine administration.

Note

In order to connect machine for administration, please locate your

PC in the same network segment (192.168.0.x) of IP Phone. If

you’re not familiar with TCP/IP, please refer to related chapter on

user’s manual CD or consult your network administrator for proper

network configurations.

Network Interface quick congurations

Execute your web browser, and insert the LAN IP address (default: 192.168.0.1)

of SIP IP Pohne in the adddress bar. After logging on machine with username/

password (default: root / no password), browse to “Network” --> “Network

settings” conguration menu:

Parameter Description

IP address LAN IP address of the IP Phone

Default: 192.168.0.1

Mask LAN mask of the IP Phone

Default: 255.255.255.0

Default Gateway Gateway of the IP Phone

Default: 192.168.0.254

Connection Type Data required.

Fixed IP The ISP will assign IP Address, and related information.

DHCP client In most circumstances, it is no need to congure the

DHCP settings.

PPPoE The ISP will assign PPPoE username / password for

Internet access.

After conrming the modication you’ve done, Please click on the Submit button

to apply settings and browse to “Save & Reboot” menu to reboot the machine to

make the settings effective.

Save Change to Flash Memory

Most of the IP Phone parameters will take effective after you modify, but it is

just temporary stored on RAM only, it will disappear after your reboot or power

off the IP Phone, to save the parameters into Flash ROM and let it take effective

forever, please remember to press the Save & Reboot button after you modify

the parameters.
