Planet VIP-450 Manual de usuario

Command ReferenceGuide

VIP-450SIPcommandReference Guide

The VIP-450 is aSIPversion 2.0compliant voicegateway,whichintegrates a

web-basedgraphicaluser interface, andcommandlineadministrationthatcan cover

most configurations andapplication demands.

PLANETVIP-450SIPReferenceGuide

TABLE OF CONTENTS

1.ABOUT THISGUIDE 3

2. SIPCOMMAND REFERENCE. ...3

3. DIALPLAN SETUP.. .. 5

4. CALLTRANSFER ..5

5. CONFIGURATION EXAMPLE ... .6

PLANETVIP-450SIPReferenceGuide

ABOUTTHIS GUIDE

This VIP-450 SIP(SessionInitiation Protocol) Reference Guide provides SIPconfiguration commands.

Before starting configurations, it is suggestedtocheck the SIPconnectionrequirement carefully,then

configure therequired valueinmachine. If you re not surewhich parametersshould be inserted, please

check thisguide for correspondingparameters to establish the voice connection onyour side. Inthe

meantime, more VOIPconcept and machinedesignalgorithm can be referredin the user smanualCD for

more understandings.

This Guide contains thefollowing information:

SIPCommand Reference: Thischapterillustrates howtousethesip command for the Internet

TelephonyGateway(ITG), toregister with the SIPproxyserver.

Dial PlanSet Up: Shows the differencebetween the H.323and SIPprotocol.

Call Transfer: This chapter illustrates the operations of call transfer.

ConfigurationExample: This chapter showsyou how to set up the ITGtostart up your call.

Before readingthis guide,itisbest thatyouarefamiliar withthe “QUICK INSTALLATION GUIDE”and

youknowthe network configurations, aswell as the dialplan set up.

PLANETVIP-450SIPReferenceGuide

1. SIPCOMMANDREFERENCE

showsip reg

- displays the informationofregistration

showsip cfg

- displays theconfigurationof registration

showsip proxy

- displays theconfigurationof proxy server

showsip dns_ip

- displays theconfigurationof DNS server

showsip info_sw

- displays theinformationswitch

showsip auto_reg

- displaysauto-registrationon/off whenreboot

showsip nat_call

- displaysnat_call switch

showsip outboundproxy

- displays theoutbound proxy

set sip reg add

- used toadd registration information

set sip regadd [reg_num][expires][#registrar] [ip][port] {name | 0} {passwd|

0} {ipport …}

PLANETVIP-450SIPReferenceGuide

Syntax description

reg_num the phone number to beregistered

expires how long thereg_numistore-register

#registrar the number ofregistrar

ip IPofthe registrar

port port oftheregistrar

name [thename for authentication| 0 forno authentication]

passwd [thepasswordforauthentication | 0forno authentication]

set sip reg del

- used todeleteregistrationinformation

set sip reg del [reg_num]

Syntax description

reg_num the phone number to bedeleted

set sip cfg

- used tosettheconfigurationof sip

set sip cfg [udp_ctl_port] [rtp_data_port]

Syntax description

udp_ctl_port <udp controlport>|( 0 : defaultport willbe used)

rtp_data_port <rtpdataport>|( 0 : defaultport willbeused)

set sip proxy

- used tosettheconfigurationof sip

set sip proxy [#proxy_svr] [ proxysvr-1 nwa ] { proxy svr-2nwa}…

Syntax description

#proxy_svr numberof proxyserver | 0toremove existingserver

proxysvr nwa <ip> <port>

set sip actreg

PLANETVIP-450SIPReferenceGuide

- used tosend out theregistration

set sip actreg

set sip dns_ip

- used to setthe domain nameserver.TheIPdomainshould bein

numericalformat

set sip dns_ip [ip]

Syntax description

ip <x.x.x.x> | 0 to remove dns ip

set sip info_sw

- used tosetthesipprocess informationswitch

set sip info_sw[on/off]

set sip auto_reg

-used to setregistration auto start when rebootin thecondition ofregistration

serveris set

set sip auto_reg [on/off]

set sip nat_call

-used to setnat_callswitchon/offwhether thegateway in public IP is toreceive

calls from the privateIPor not.Thedefaultis on

set sip nat_call [on/off]

set sip outboundproxyadd

- used toadd outbound proxy

set sip outboundproxyadd [ip/hostname] [port]

set sip outboundproxydel

- used todeleteoutboundproxy

set sip outboundproxydel

PLANETVIP-450SIPReferenceGuide

2. DIAL PLAN SETUP

Here, we list the differencesbetweenthe H.323 and SIPdialplanconfigurations. If you arenot familiar

with machine dialplansetup,please referto theVIPQuick Installation Guide and the User s manual

formoreunderstandings of thedialplanoperationsin machine.

Calling destination inPLANET H.323voice gateways canbeadded via following commands:

atpm dadd [dest_id] h323 [destipaddr] [port]

atpm dadd [dest_id] dns [desthost name] [port]

In VIP-450 the “h323”part in the command is replaced by “sip”:

atpm dadd [dest_id] sip [dest ip addr] [port]

atpm dadd [dest_id] dns [desthost name] [port]

3. CALL TRANSFER

VIP-450 supports unattended call transfer.

3-1The Operations

When aremote sessionis established, bothends ofthe partiescan transferacall toanother location

bypressing theFlash/Transfer keypad on the phoneset.

3-2Operation Recovery

When theuseris transferringacalltoadestination thatdoes not exist on the dialplan, an

out-of-service tone willbegenerated. PressingtheFlash/Transferkeypad can bring usersback to

theoriginal session.

4. CONFIGURATION EXAMPLE

Now,it is assumedthat youare registering toaproxyserver(referred toregistrar). Theinformation for

registration is as follows:

ITGIP: 211.20.1.5

Registered ID: 2001

PLANETVIP-450SIPReferenceGuide

ExpiredTime: 500

ProxyServer IP: 211.20.1.1

ProxyServer Port: 5060

Set the information of registration.

ITG>set sip reg2001 500 1 211.20.1.5506000

Then youneed set up theserver.

ITG>set sip cfg 00

Then youneed set up theserver.

ITG>set sipproxy1211.20.1.15060

In ordertosupport the complete function, you needto set a port cid number.Weassume port 0isused.

ITG>set port 0cid number 2001

Next, youneed tosave the information andsend out the registration.

ITG>config activate

ITG>config store

ITG>set sipactreg

*Note: Before startingthefirst call,you need toset up the dialplan.Don tforget touse “sip”whenyou

type “atpm dadd”.
