AMPLIFICATION

››Power›Output:››110W›x›5›(1kHz,›THD›0.05%›@›8›ohms)

››80W›+›80W›(20Hz›–›20kHz,›THD›0.08%›@›8›ohms›FTC)

AUDIO FEATURES

››Texas›Instruments›Aureus™›DSP

››192›kHz/24-bit›DAC

››Dolby®›TrueHD

››Dolby›Pro›Logic›IIz

››Dolby›Digital›/›EX

››DTS-HD®›Master›Audio

››DTS®›96/24›/›DTS›Neo:6/DTS›Express

››Multi›PCM›Playback›(192›kHz)›via›HDMI

››SACD›Playback›via›HDMI›(2›ch)

››0.1›Step›Audio›Delay›(Lip›Sync)›(Max›9›Frame)

››Advanced›Surround›(Action,›Drama,›Entertainment›Show,›Advanced›

Game,›Sports,›Classical,›Rock/Pop,›Unplugged,›Extended›Stereo)

››Auto›Surround

››Stream›Direct

››Phase›Control›(bass›management›ensures›precision›low›frequency›

output)

››Front›Stage›Surround›Advance

››Advanced›Sound›Retriever›for›enhanced›PC›and›portable›audio›(2-ch)

››Midnight›Listening›Mode

››Auto›Level›Control›(2›ch.)

VIDEO FEATURES

››HDMI›(v.1.4›with›3D),›Deep›Color,›and›x.v.Color

CONVENIENCE

››30›Tuner›Presets

››SR›Remote›Control›Unit

››FL›Dimmer›(4›steps)

››Sleep›Timer›(30,›60,›90›minutes)

››Auto›Audio›Signal›Select

››LFE›Attenuator

CONNECTIVITY

››HDMI›(3›inputs›/›1›output)

››Bluetooth›Port›(Compatible›with›optional›Bluetooth›adapter›

AS-BT100)

››Front›Mini›Jack

››3›Digital›Inputs›(1›Coaxial,›2›Optical)

››Component›Video›Terminal›(2›Inputs,›1›Output)›Assignable

››Audio/Video›Inputs:›2A/4AV

››Audio/Video›Output:›1A/1AV›+›1V

››2.1›Preout›(Subwoofer›+›Surround›Back/Front›Height›Channels)

››Large›Speaker›Terminals›(FL/FR)

5.1-Channel A/V Receiver featuring HDMI®(v.1.4 with 3D),

Dolby®TrueHD & DTS-HD®Master Audio and

Bluetooth Capability*

VSX-520-K

*Optional›Bluetooth›Adapter›(AS-BT100)›required.

©›2010›Pioneer›Electronics›(USA)›Inc.

SPECIFICATIONS

››Power›Requirements:›AC›120›V/60›Hz

››Power›Consumption:›240›Watts

››Standby›Power›Consumption:›Less›than›0.4›Watts

››W›x›H›x›D:›16.55›x›6.23›x›13.71›inches

››Weight:›19.6›lbs

INTEGRATED TECHNOLOGIES

Speciﬁcations and design subject to modiﬁcation without notice.

PIONEER and the Pioneer logo are registered trademarks of Pioneer Corporation.

The impedances indicated are actual values that speakers can present to an ampliﬁer while playing

back music. They do not refer to the nominal rated impedances of speakers you use.

HDMI connection may not allow transmission of copyright protected material, depending on the

capability of the signal source.

DTS is a registered trademark & the DTS logos and Symbol are trademarks of DTS, Inc.

Bluetooth is a registered trademark of Bluetooth SIG, Inc. Bluetooth functionality requires a

compatible A2DP proﬁle Bluetooth-enabled device. Certain Bluetooth features may not be supported

by all compatible Bluetooth-enabled devices, and/or the functionality of such features may be limited

in certain devices.

Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

HDMI, the HDMI logo and High-Deﬁnition Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing, LLC.

“x.v.Color” is a trademark of Sony Corporation.

Texas Instruments, Aureus and design are trademarks of Texas Instruments Incorporated in the U.S.

or other countries.

CONNECTION DESCRIPTIONS

A. HDMI›A/V›Repeater›(3›in/1›out)

B. Bluetooth›Adapter›Port

C. 4›Composite›A/V›Inputs

D. 2›Assignable›Component›Video›Inputs

E. 3›Assignable›Digital›Inputs

F. Large›Speaker›Terminals›(Front›L/R)

CONNECTIONS

Rear›Panel

ABCDEF

5.1-Channel A/V Receiver featuring HDMI®(v.1.4 with 3D),

Dolby®TrueHD & DTS-HD®Master Audio and

Bluetooth Capability*

VSX-520-K
