Pioneer Avm-p900ruc Manual de usuario

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.

PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2000 K-ZZY. MAY 2000 Printed in Japan

ORDER NO.

CRT2518

AVM-P9000R

MULTI-CHANNEL AV MASTER UNIT

AVM-P9000R UC

Service

Manual

AVM-P9000R EW

AVM-P9000 ES

CONTENTS

1. SAFETY INFORMATION ............................................2

2. EXPLODED VIEWS AND PARTS LIST.......................3

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...10

4. PCB CONNECTION DIAGRAM ................................34

5. ELECTRICAL PARTS LIST ........................................52

6. ADJUSTMENT..........................................................85

7. GENERAL INFORMATION .......................................87

7.1 DISASSEMBLY ...................................................87

7.2 IC ........................................................................88

7.3 OPERATIONAL FLOW CHART.........................105

8. OPERATIONS AND SPECIFICATIONS...................106

AVM-P9000R/UC

-Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby

-Manufactured under license from Digital Theater Systems, Inc. “DTS” and “DTS Digital Surround” are trademarks

of Digital Theater Systems, Inc.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

1. SAFETY INFORMATION(AVM-P9000R/UC)

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.

Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair

complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.

If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so

and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of

California to cause cancer, birth defects or other reproductive harm.

Health & Safety Code Section 25249.6 - Proposition 65

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

2. EXPLODED VIEWS AND PARTS LIST

2.1 PACKING

EW Model

UC, ES Model

20 21

27 30

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

NOTE:

-Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List.

-Screws adjacent to ∇mark on the product are used for disassembly.

-PACKING SECTION PARTS LIST

Part No.

Mark No. Description AVM-P9000R/UC AVM-P9000R/EW AVM-P9000/ES

1 Cord Assy CDE5905 CDE5905 CDE5905

2 Cord Assy CDE5906 CDE5906 Not used

3 Cord Assy CDE5908 CDE5908 CDE5908

4 Cord Assy CDE6016 CDE6016 CDE6016

5 Cord Assy CDE6305 CDE6305 CDE6305

6 Antenna Cord CDH1265 CDH1265 CDH1265

7 Cord Assy CDE6365 CDE6365 CDE6365

8 Cord Assy CDE6368 CDE6368 CDE6368

9 Cable CDE6366 CDE6366 CDE6366

* 10 Screw Assy CEA2440 CEA2440 CEA2440

11 Screw BNC40P120FZK BNC40P120FZK BNC40P120FZK

* 12 Polyethylene Bag CEG1158 CEG1158 CEG1158

13 Screw HMF40P080FZK HMF40P080FZK HMF40P080FZK

* 14 Polyethylene Bag CEG1101 CEG1101 CEG1101

15 Polyethylene Bag CEG1181 CEG1057 (Cover) CEG1057 (Cover)

16 Carton CHG4085 CHG4083 CHG4084

17 Sub Carton CHG4089 CHG4089 CHG4089

18 Contain Box CHL4085 CHL4083 CHL4084

19 Protector CHP2280 CHP2280 CHP2280

20 Fastener CNM3728 CNM3728 CNM3728

21-1 Owner’s Manual CRB1591 CRB1585 CRB1593

21-2 Owner’s Manual CRB1592 CRB1586 CRB1594

21-3 Owner’s Manual Not used CRB1587 CRB1595

21-4 Owner’s Manual Not used CRB1588 CRB1596

21-5 Owner’s Manual Not used CRB1589 CRB1597

21-6 Owner’s Manual Not used CRB1590 Not used

* 21-7 Card ARY1048 Not used Not used

* 21-8 Warranty Card Not used CRY1157 Not used

21-9 Polyethylene Bag CEG1116 CEG1116 CEG1116

22 Remote Control Assy CXB6029 Not used CXB6028

23 Angle CNB2351 CNB2351 CNB2351

24 Clamper CNV1343 CNV1343 CNV1343

25 Remote Control Main Assy Not used CPN1639 Not used

26 Polyethylene Bag Not used CEG1011 Not used

27 Battery Not used CEX1021 Not used

28 Sheet Not used CNM5288 Not used

29 Sheet Not used CNM5472 Not used

30 Holder Not used CNS4502 Not used

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

-Owner's Manual

Model Part No. Language

AVM-P9000R/UC CRB1591 English

CRB1592 French

AVM-P9000R/EW CRB1585 English

CRB1586 Spanish

CRB1587 German

CRB1588 French

CRB1589 Italian

CRB1590 Dutch

AVM-P9000/ES CRB1593 English

CRB1594 Spanish

CRB1595 Portuguese(B)

CRB1596 Chinese

CRB1597 Arabic

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

2.2 EXTERIOR

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

1 Screw BSZ30P060FMC

2 Screw BSZ30P060FZK

3 Screw BSZ30P200FMC

4 Screw(M2.6x10) CBA1147

5 Cord Assy CDE6305

6 Fuse(10A) CEK1136

7 Cap CNS1472

8 Resistor RS1/2PMF102J

9 Cord Assy CDE6307

10 Cord Assy CDE6368

11 Transistor(Q804,813) 2SD2396

12 Fuse(4A) CEK1001

13 Cord Assy See Contrast table(2)

14 Chassis CNA2292

15 Case See Contrast table(2)

16 Holder CNC8964

17 Cushion CNM7001

18 Insulator CNM6988

19 Tuner Amp Unit See Contrast table(2)

20 Screw BMZ26P160FMC

21 Screw BSZ26P060FMC

22 Screw BSZ26P100FMC

23 Cord Assy CDE6442

24 IC(IC800,801,802) BA05ST-V5

25 Clamper CEF1007

26 Pin Jack(CN101) CKB1037

27 Pin Jack(CN200) CKB1045

28 Pin Jack(CN920) CKB1046

29 Terminal(CN402) CKF1059

30 Plug(CN202) CKM1131

31 Connector(CN900) CKM1192

32 Plug(CN800) CKM1278

33 Plug(CN802) CKM1325

34 Plug(CN803) CKS-555

35 Connector(CN201) CKS2601

36 Connector(CN860) CKS3124

37 Connector(CN160) CKS3414

38 Connector(CN801) CKS3582

39 Connector(CN260) CKS3596

40 Connector(CN350) CKS3644

41 Connector(CN1) See Contrast table(2)

42 Connector(CN100) CKS4124

43 Connector(CN185) CKS4362

44 Connector(CN661) CKS4363

45 Connector(CN660) CKS4364

46 Antenna Jack(CN401) CKX1056

47 Holder CNC4569

48 Holder CNC7047

49 Holder CNC7533

50 Holder CNC8205

51 Holder CNC8274

52 Holder CNC8819

53 Holder CNC8820

54 Holder CNC8821

55 Holder CNC8826

56 Heat Sink CNC8827

57 Buss Bar CNC8841

58 Buss Bar CNC8842

59 Holder See Contrast table(2)

60 Insulator CNM5967

61 Heat Sink CNR1570

62 FM/AM Tuner Unit See Contrast table(2)

63 Holder CNC7532

64 GDC Unit CWM7146

65 Connector(CN1601) CKS4365

66 Shield CNC9134

67 Shield CNC9135

68 Sheet CNM6866

69 DSP Unit CWM7147

70 Connector(CN2701) CKS4366

71 Shield CNC9107

72 Shield CNC9108

73 Sheet CNM6866

74 Remote Control Assy See Contrast table(2)

75 Cover See Contrast table(2)

76 Fan Motor CXM1154

77 Screw ISS26P055FUC

78 Remote Control Main Assy See Contrast table(2)

79 Case See Contrast table(2)

80 Sheet CNM7002

81 Sheet CNM7003

82 IC(IC900,901) PAL005A

83 Cushion CNM7052

84 Spacer CNM7053

(1) EXTERIOR SECTION PARTS LIST

Mark No. Description Part No. Mark No. Description Part No.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

Part No.

Mark No. Description AVM-P9000R/UC AVM-P9000R/EW AVM-P9000/ES

13 Cord Assy CDE6370 CDE6370 CDE6386

15 Case CNB2573 CNB2573 CNB2592

19 Tuner Amp Unit CWM7150 CWM7151 CWM7152

41 Connector(CN1) CKS3645 CKS3645 Not used

59 Holder CNC8963 CNC8963 Not used

62 FM/AM Tuner Unit CWE1501 CWE1500 CWE1501

74 Remote Control Assy CXB6029 Not used CXB6028

75 Cover CZN5357 Not used CZN5357

78 Remote Control Main Assy Not used CPN1639 Not used

79 Case Not used CNS6050 Not used

(2) CONTRAST TABLE

AVM-P9000R/UC, AVM-P9000R/EW and AVM-P9000/ES are constructed the same except for the following:

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

AVM-P9000R,P9000

1234

Q2VDD VCC

BFM/AM TUNER UNIT

ATUNER AMP UNIT

CN401

IC 161

CA0008AM

IP-BUS DRIVER

RDS

DECODER

Q160

Q161

Q500

ASNB

B—

B+

BL+

B.U

11 12

20 24

8IPPW

ldet

COMP

L-OUT

IC 500

PM4009A

CF202

X901

VDD

VCC

LOCL

VDD

VCC

ANTENNA

Q201

Q401

Q204

Q202

T51 Q51 CF51 CF52 CF53

ANT1 TV

ANT2 TV

RF TV

AM RF

EEPROM

IC 3

BR9010FV

MIXER, IF AMP DET

IC 1

PML002A

FM/AM 1ST IF 10.7MHz

AM 2ND IF 450kHz

FM FRONT END

38 42 46

4439

45 55 57 61 74 75

25 24

4611444134 33

IC 2 PM4008A

22 10 1423 12 15 16 8 13 2 1

DI/DO

LOCH

CE2

CE1

SDBL

FMSD

CN160

Q400

IC 25

PML00

SRAM

IC 25

PML00

IC 25

PML00

IC 2407

NJM4558MD

IC 2408

NJM4558MD

IC 2401

TC9164AF

GAIN SELECTOR

reset

DSP UCOM

IC 2301

PD5572A

IC 2103

TC7S08FU

RX1

AIN3L

DSPPW

AIN1L

AIN2L

IC 2101

CS4226-BQ

SDIA0

YSS

AOUT1 21

AOUT3 23

AOUT5 25

AOUT6 26

SDOUT1 36

IC 2102

BA3131FS

Lch

RESET

SEL1

SEL0

XOUT

XIN

OPT

IC 2302

S-80734ANDYI

SEL0

SEL1

dmute 67

IC 2202

TC55V8128BFTI-12

CN2701

VTR_L

IP_L

TUN_L

11 SPIN_L

resetsw

OPT

CN660

VTR_L 52

IP_L 49

TUN_L 50

SP_L

DSPRST

DSPPW

/DSPPW 26

VDD

S650

CN1601

IC 1701

HD64412FI

RED

GREEN

BLUE

IC 1752

IC 1751

MSM5118165D-60TS

CDE

CLK0

112

CSYNC 115

VSYNC 118

IC 1893

TC7SET04FU

IC 1892

TLC2932

IC 1895

TC3W03FU

IC 1602

TC7SH04FU

X1702

7.977138MHz

IC 1894

TC74VHC4040FT

IC 1891

NJM78L03UA

IC 1601

PD3415A

IC 1652

PD8065A

IC 1651

PD8064A

IC 1831

BA7046F

IC 1841

TC74VHC123AFT

12 9

X1701

8.25MHz

CN1601CN661

IC 160

TA2050S

CN201

CN202

SPIN

OPTIN

DVDIN

VSEL

INFO

FAN

CN101

CN200

CN100

IC 101

BA3129F

IC 200

NJM4558MD

Q150

Q101

Q151

IC 100

BA3121F

Q102

CDE

Q2SYNC

HRET

VRET

COMP

IC 150

NJM2246M

Q260

RVMUTE

TVMUTE

REMIN

DSENS

NAVSEN

SEL1

SEL0

VPWR

RMMUTE

CCR

X500 12.58MHz

RVMUTE

TVMUTE

RMMUTE

16 5815 57

Q100

SDO 70

VOLPWM 71

VCAMUTE 31

SCL 69

RMSEL2

RESET

RMSEL

CN1

1CCG

2CCB

3SP+

13 SP—

19 MOREM

8DSEN

ACONT

14 PWRVI

Q200

IC 60

NJM4558MD

NAVI ISOLATOR

378

IC 230

NJM4558MD

3IC 232

NJM4558MD 7

IC 231

TDA7052BT

Q230

SP—

SP+

53IC 921

NJM2068MD 7

VSEL0 55

VSEL1 56

FVMUTE 54

IC 650

S-80734ANDYI

VDD

XTI XTO

28 29

X2101 12.288MHz

MUTERQ 41

X2301

10.00MHz

IC 802

BA05ST-V5

B.U

Q2401

Q2402

A+8V VREF_L

VREF_R

IC 2901

BA033FP

D+5V D+3.3V

40 1

TVMODE1

39 2

38 3

37 4

SPC

SPB

SPA

SPIN

DACK0 65

TIOCB1

100

XTAL

EXTAL

DACK

HSYNC

117

CLK1

106

SYSTEM

MICRO COMPUTER

IC 601 (2/2)

PE5154A

Q601

G8V

CCV

6CCV

Q680

IC 681

BA3834F

811

Q861 B.U

Q860

CN860

IC 2403

NJM4558MD

AOUT2 22

IC 2406

NJM4558MD

AOUT4

CDCERR 16

IC 2402

NJM4558MD

IC 2405

NJM4558MD

X1601 20MHz

SASEL2

SASEL1

SASEL0

SADATA

IC 1823

TC7WH125FU

IC 800

BA05ST-V5

B.U 365

Q2ON Q2ON

IC 801

BA05ST-V5

B.U

Q800

X500 3.648MHz

REMIN

CN185

IC 185

NJM4558MD

PEE 100

DVDPEE

REMIN

RESET

910

RL IN

RL OUT

VIDEO IN

VIDEO OUT

DDSP UNIT

CGDC UNIT

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM

3.1 BLOCK DIAGRAM(AVM-P9000R/UC)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Receptor de Pioneer

Pioneer

Pioneer VSX-C301-S Manual de usuario

Pioneer

Pioneer DMH-A345BT Manual de usuario

Pioneer

Pioneer VSX-9130TXH-K - 140 Watts A/V Receiver Manual de usuario

Pioneer

Pioneer AVH-X7500BT Manual de usuario

Pioneer

Pioneer EV-5DVD Manual técnico

Pioneer

Pioneer Elite SC-37 Manual de usuario

Pioneer

Pioneer MVH-X300BT Manual de usuario

Pioneer

Pioneer XV-HTD1 Manual de usuario

Pioneer

Pioneer PDP-R06G Manual de usuario

Pioneer

Pioneer VSX-84TXSI - AV Receiver Manual de usuario

Pioneer

Pioneer XR-A4800 Manual de usuario

Pioneer

Pioneer VSX-D458 Manual de usuario

Pioneer

Pioneer VSX-505RDS Manual de usuario

Pioneer

Pioneer Elite VSX-43TX Manual de usuario

Pioneer

Pioneer AVIC-9DVD Manual de usuario

Pioneer

Pioneer VSX-416-K Manual de usuario

Pioneer

Pioneer DVH-340UB Manual de usuario

Pioneer

Pioneer Elite VSX-33 Manual de usuario

Pioneer

Pioneer XV-HTD510 Manual de usuario

Pioneer

Pioneer Elite VSX-40 Manual de usuario

Pioneer

Pioneer X-HM82-S Manual de usuario

Pioneer

Pioneer SC-1222-K Manual de usuario

Pioneer

Pioneer VSX-1024-k Manual de usuario

Pioneer

Pioneer Elite VSX-90TXV Manual de usuario

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario

Pioneer avm-p900ruc Manual de usuario

Manuales populares de Receptor de otras marcas
