Pioneer DEQ-P800/UC Manual de usuario

ORDER NO.

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.

PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936

PIONEER CORPORATION 2004

DEQ-P8000/UC

CRT3263

MULTI-CHANNEL AV PROCESSOR

DEQ-P8000

/UC

DEQ-P6600

/EW

DEQ-P7650

/ES

Manufactured under license from Dolby Laboratories. "Dolby", "Pro Logic", and the double-D symbol

are trademarks of Dolby Laboratories.

"DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems, Inc.

This product cannot be operated independently. Combining DVH-P5000MP/UC etc for performing a

check of operation.

For details, refer to "Important symbols for good services".

K-ZZA. APR. 2004 printed in Japan

DEQ-P8000/UC

1234

SAFETY INFORMATION

-Service Precaution

1. You should conform to the regulations governing

the product (safety, radio and noise, and other

regulations), and should keep the safety during

servicing by following the safety instructions

described in this manual.

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.

Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely

complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void the

If you are not qualified to perform the repair of this product properly and safely, you should not risk

and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the

of California to cause cancer, birth defects or other reproductive harm.

Health & Safety Code Section 25249.6 - Proposition 65

repair

warranty.

trying to do so

state

[ Important symbols for good services ]

In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.

When you find the procedures bearing any of the symbols, be sure to fulfill them:

2. Adjustments

To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.

In accordance with the procedures or instructions described in this manual, adjustments should be performed.

3. Cleaning

For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,

proper cleaning should be performed to restore their performances.

5. Lubricants, glues, and replacement parts

Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying

glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the

prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed

ones should be used.

4. Shipping mode and shipping screws

To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or

the shipping screws should be installed before shipping out in accordance with this manual, if necessary.

1. Product safety

You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and

should keep the safety during servicing by following the safety instructions described in this manual.

DEQ-P8000/UC 3

5678

CONTENTS

SAFETY INFORMATION......................................................................................................................................2

1. SPECIFICATIONS.............................................................................................................................................4

2. EXPLODED VIEWS AND PARTS LIST.............................................................................................................8

2.1 PACKING....................................................................................................................................................8

2.2 EXTERIOR ...............................................................................................................................................10

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................12

3.1 BLOCK DIAGRAM....................................................................................................................................12

3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE)..............................................................................14

4. PCB CONNECTION DIAGRAM......................................................................................................................20

4.1 AUDIO CONTROL UNIT...........................................................................................................................20

5. ELECTRICAL PARTS LIST.............................................................................................................................24

6. ADJUSTMENT ................................................................................................................................................31

7. GENERAL INFORMATION .............................................................................................................................32

7.1 DIAGNOSIS..............................................................................................................................................32

7.1.1 DISASSEMBLY......................................................................................................................................32

7.1.2 CONNECTOR FUNCTION DESCRIPTION ..........................................................................................33

7.2 IC..............................................................................................................................................................34

7.3 OPERATIONAL FLOW CHART................................................................................................................41

7.4 CLEANING ...............................................................................................................................................42

8. OPERATIONS .................................................................................................................................................43

DEQ-P8000/UC

1234

1. SPECIFICATIONS

DEQ-P8000/UC 5

5678

DEQ-P8000/UC

1234

DEQ-P8000/UC 7

5678

DEQ-P8000/UC

1234

2. EXPLODEDVIEWS AND PARTS LIST

2.1 PACKING

OTES : • Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List.

• Screw adjacent to mark on the product are used for disassembly.

• For the applying amount of lobricants or glue, follow the instructions in this manual.

(In the case of no amount instructions,apply as you think it appropriate.)

DEQ-P8000/UC 9

5678

(1) PACKING SECTION PARTS LIST

(2) CONTRASTTABLE

DEQ-P8000/UC, DEQ-P6600/EW and DEQ-P7650/ES are constructed the same except for the following:

Owner's Manual,Installation Manual

Mark No. Description Part No.

1 Cord Assy CDE5880

2 Cord CDE6775

3 Cord Assy CDE7531

* 4 Screw Assy CEA2440

5 Screw BNC40P120FZK

* 6 Polyethylene Bag CEG1158

7 Screw HMF40P080FZK

* 8 Polyethylene Bag CEG1101

9 Polyethylene Bag CEG1116

* 10 Polyethylene Bag See contrast table(2)

11 Polyethylene Bag See contrast table(2)

12 Sub Carton CHG4691

13 Carton See contrast table(2)

14 Contain Box See contrast table(2)

15 Protector CHP2552

16 Angle CNB2351

17 Fastener CNM3728

18 Microphone Assy CPM1066

19 Filter See contrast table(2)

20 Optical Cable Connection Box See contrast table(2)

21-1 Owner's Manual See contrast table(2)

21-2 Installation Manual See contrast table(2)

21-3 Caution Card See contrast table(2)

* 21-4 Card See contrast table(2)

21-5 Owner's Manual See contrast table(2)

* 21-6 Warranty Card See contrast table(2)

22 Cable CDE6366

* 23 Clamper CNV1272

24 Clamper CNV1343

Mark No. Description Part No.

Mark NO Description DEQ-P8000/UC DEQ-P6600/EW DEQ-P7650/ES

* 10 Polyethylene Bag CEG1160 Not used CEG1160

11 Polyethylene Bag CEG1173 CEG-162 CEG-162

13 Carton CHG5244 CHG5243 CHG5242

14 Contain Box CHL5244 CHL5243 CHL5242

19 Filter CTX1054 Not used CTX1054

20 Optical Cable Connec-

tion Box CXC3584 CXC3584 Not used

21-1 Owner's Manual CRD3877 CRD3874 CRD3879

21-2 Installation Manual CRD3878 CRD3876 CRD3880

21-3 Caution Card CRP1310 Not used CRP1310

* 21-4 Card ARY1048 Not used Not used

21-5 Owner's Manual Not used CRD3875 Not used

* 21-6 Warranty Card Not used CRY1157 Not used

Part No. Language

CRD3877 English, French

CRD3878 English, French

CRD3874 English, Spanish, German

CRD3875 French, Italian, Dutch

CRD3876 English, Spanish, German, French, Italian, Dutch

CRD3879 English, Spanish, Portuguese(B), Traditional Chinese

CRD3880 English, Spanish, Portuguese(B), Traditional Chinese

DEQ-P8000/UC

1234

2.2 EXTERIOR
