Pioneer BDR-XD08UMB-S Manual de usuario

USB 3.2 Gen1 (USB Type-C®) / 2.0 Slim Portable BD/DVD/CD Writer

Graveur de BD/DVD/CD portable mince USB 3.2 Gen1 (USB Type-C) / 2.0

BDR-XD08UMB-S

Owner’s Manual

Manuel de l’utilisateur

2BDR-XD08UMB-S En

Thank you for purchasing this Pioneer product. Before using the drive, please ensure that you read all

warnings, cautions, notices, and other important safety information in this owner’s manual, which also

contains important information including regulatory data, the software license agreement, details on

product registration, service procedures, and guidelines on installation and use. Be sure to keep this

manual in a safe place.

Contents

Operating System ....................................................................................6

Before Use ...............................................................................................7

IMPORTANT SAFETY INSTRUCTIONS.................................................8

Cautions in Usage.................................................................................. 11

Features ................................................................................................. 13

Part Names and Functions..................................................................... 15

Operations.............................................................................................. 17

Connection............................................................................................. 19

Downloading and Installing CyberLink Media Suite

(with Product Key) .................................................................................. 21

Useful Functions.....................................................................................22

Specications.........................................................................................27

Problems and Solutions .........................................................................29

Others ....................................................................................................32

BDR-XD08UMB-S En

Precautions Regarding Use

• Pioneer accepts no liability for the loss of any data and limits its responsibility for any failure of the

product to perform properly as provided in the product’s One Year Limited Warranty. It is strongly

recommended to regularly back up all critical data.

• Care must be taken not to infringe copyright restrictions under the laws of each country. If this

device is used to record copyrighted materials, approval must be obtained from the respective

respective copyright holders may result in legal penalties. YOU ARE RESPONSIBLE FOR YOUR

USE OF THIS PRODUCT. Pioneer disclaims any and all responsibility for any legal damages

resulting from the use of this device in the unauthorized copying of copyrighted materials.

• All names of corporations, products, and systems listed herein, even when the (™) or (®) symbols

are omitted, are considered the registered trademarks of the respective owners.

• Specicationsandtheexternalappearancemaybesubjecttochangewithoutnotice.

• Images used in this Owner’s Manual may be different from actual product.

WARNING

Thisproduct’sclassicationhasbeendeterminedunderIEC60825-1:2014,SafetyofLaser

Products.ThisClass1productcontainsalaserdiodeclassiedasClass3B.Toensurecontinued

safety, do not remove any covers or attempt to gain access to the inside of the product. Refer all

servicingtoqualiedpersonnel.

CLASS 1 LASER PRODUCT

Thefollowingcautionlabelappearsonyourunit:

Location:bottomoftheunit

CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES

OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS

RADIATION EXPOSURE.

CAUTION : THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE

EYE HAZARD.

4BDR-XD08UMB-S En

FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany

interference received, including interference that may cause undesired operation.

 ProductName: BD/DVD/CDWRITER

 ModelNumber: BDR-XD08UMB-S

 ResponsiblePartyName: PioneerElectronics(USA)Inc.

 Address: 2050W.190thStreet,Suite100,Torrance,CA90504

 Phone: (800)421-1404

 URL: https://www.pioneerelectronics.com/PUSA/

NOTE

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

— Reorient or relocate the receiving antenna.

— Increase the separation between the equipment and receiver.

— Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

— Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Information to User

Alterationsormodicationscarriedoutwithoutappropriateauthorizationmayinvalidatetheuser’s

right to operate the equipment.

WARNING

TOPREVENTTHERISKOFELECTRICSHOCK,DONOTREMOVECOVER(ORBACK).NO

USER-SERVICEABLEPARTSINSIDE.REFERSERVICINGTOQUALIFIEDSERVICEPERSONNEL.

BDR-XD08UMB-S En

WARNING

THISPRODUCTISNOTWATERRESISTANT.Topreventareorshockhazard,donotplaceany

containerlledwithliquidnearthisequipment(suchasavaseorowerpot)orexposeittodripping,

splashing, rain or moisture.

ForPLUGGABLEEQUIPMENT,thesocket-outletshallbeinstalledneartheequipmentandshall

be easily accessible.

CAUTION

ThisproductsatisesFCCregulationswhenshieldedcablesandconnectorsareusedtoconnect

the unit to other equipment. To prevent electromagnetic interference with electric appliances such

as radios and televisions, use shielded cables and connectors for connections.

6BDR-XD08UMB-S En

Operating System

Operating Environment (Windows®)

DVD/CD disc recording and playback

• SupportedOS:Windows11,Windows10,Windows8.1

Blu-ray disc recording and playback

• SupportedOS:Windows11,Windows10,Windows8.1

Ultra HD Blu-ray playback

TheIntelSoftwareGuardExtensions(IntelSGX)featureisarequirementfortheCPUand

motherboardrmwaretoplayDRM(digitalrightsmanagement)protectedcontentonUltraHDBlu-ray

movie discs on a Windows platform.

Note

IntelSGXhasbeenremovedfromIntel11thgenerationandnewerCPUs,andsupportforSGXmaybe

removedonnewversionsofInteldriversorutilityprogramssuchasIntelSGXandIntelManagement

Enginedriversandrmwareinthefuture.Suchchangescouldcausetheseplatformstolosesupport

for Ultra HD Blu-ray movie disc playback.

• Refer to the Pioneer website for details on playback environments.

https://www.pioneerelectronics.com/PUSA/Computer/Computer+Drives/BDR-XD08UMB-S

The required operating environment may differ depending on the OS or applications used.

Please consult with software or OS providers regarding any questions about the OS or applications.

Operating Environment (macOS®)

• SupportedOS:OSXElCapitan®10.11, macOS Sierra®10.12, macOS High Sierra®10.13, macOS

Mojave®10.14,macOSCatalina®10.15, macOS Big Sur®11, macOS Monterey®12

Mac®does not support Ultra HD Blu-ray playback.

BDR-XD08UMB-S En

Checking accessories

□Owner’s manual (including warranty information and application product key)

□USB cable (Type-A)

□ USBexchangecable(Type-A→Type-C)

• Download the application software from the website at

https://jpn.pioneer/cyberlink_soft/en.php

The application download key (product key) is attached to back of this Owner’s manual.

• If any accessories are not included, please contact the dealer from which you purchased this

product.

• Please download the Pioneer BD Drive Utility from the Pioneer website.

https://pioneer.jp/device_e/product-e/ibs/device_e/dev00001r_e.html#DriveUtility

TheDriveUtilityletstheusercongurevariousdrivefunctionssuchasadjustingthereadingmethodif

correct reading of a music CD is not possible, and setting the PureRead function, which minimizes the

occurrence of data interpolation resulting from errors.

For details, refer to "Useful Functions" on page 22.

Information on the product

https://www.pioneerelectronics.com/PUSA/Computer/Computer+Drives/BDR-XD08UMB-S

Before Use

8BDR-XD08UMB-S En

IMPORTANT SAFETY INSTRUCTIONS

WARNING

Measures in the event of abnormalities

• CONTINUINGTOUSETHEDEVICEUNDERABNORMALCONDITIONS,SUCHASWHERE

THEREISSMOKE,ABNORMALSMELLS,STRANGENOISES,ORSIMILARMAYLEADTOFIRE

ORELECTRICSHOCK.IMMEDIATELYREMOVETHEUSBCABLEFROMTHEDEVICE(IF

USINGANACADAPTER,UNPLUGTHEPOWERPLUGFROMTHEOUTLET).ENSURETHATNO

MORESMOKEISBEINGEMITTED,ANDCONTACTYOURDEALERFORREPAIR.ATTEMPTING

TOREPAIRTHEDEVICEYOURSELFISDANGEROUS,ANDSHOULDNOTBEATTEMPTED.

• If water or other foreign matter have entered the device, remove the USB cable from the device (if

using an AC adapter, unplug the power plug from the outlet), and contact your dealer. Continuing to

usethedevicemayleadtoreorelectricshock.

• If the device is dropped or the cover damaged, remove the USB cable from the device (if using an

AC adapter, unplug the power plug from the outlet) and contact your dealer. Continuing to use the

devicemayleadtoreorelectricshock.

Operating Environment

• Operatingenvironmenttemperatureandhumidity:

+5°Cto+35°C(+41°Fto+95°F);lessthan85%relativehumidity(ensurecoolingventsnot

blocked)

Do not install this unit in a poorly ventilated area, or in locations exposed to high humidity or direct

sunlight(orstrongarticiallight).

• Ensure that water does not enter the device, and that it is kept dry. Do not use in locations with high

humidity.Doingsomayleadtoreorelectricshock.

• Donotuseinwetlocationssuchasinbathroomsorshowerrooms.Doingsomayleadtoreor

electric shock.

Installation

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(includingampliers)thatproduceheat.

• Slots and openings in the chassis are for cooling and proper operation of the unit. Do NOT block or

cover the openings. Do NOT place this unit on a bed, rug, etc. as this can block the openings. This

unit should not be placed in a built-in installation unless properly ventilated.

• Topreventarehazard,donotplaceanynakedamesources(suchasalightedcandle)onor

anywhere near the equipment.

• Donotplacenearopenames,suchasareplace,orheatsources.Doingsomayleadtoreor

deforming.

BDR-XD08UMB-S En

IMPORTANT SAFETY INSTRUCTIONS

WARNING

• Unplug the USB cable (if using an AC adapter, the power plug) from this device during lightning

storms or when unused for long periods of time.

• Duringoperation,donotsubjectthedevicetovibrationorshock,orpluginorunplugtheUSBcable(if

using an AC adapter, the power plug).

• During operation, do not move or pick up the device. The disc rotates at high speed, and picking up

ormovingthedevicemaydamagethedisc.Tomovethedevice,rstremovethedisc,andturnthe

power off.

• Do not remove the device cover, or modify the device. The interior of the device contains high-

voltageparts,anddoingsomayleadtoreorelectricshock.Askyourdealertocarryoutany

internal inspections, maintenance, and repairs. This device is a precision instrument, so refer

this product to an authorized dealer or service center if disassembly is required.

• Donotplaceanyobjectsonthisdevice,whichmaydamageitorcauseittobecomeunstableand

falloverorfalloff,potentiallyleadingtoinjury.

• Do not use discs that are cracked, deformed, or have been repaired with glue or other adhesives.

Discsrotateathighspeedwithinthedevice,andinthesecasesmayyoutandleadtoinjuryor

damage.

• DONOTLOOKINTOTHEINTERIOROFTHEDEVICEFROMGAPSINTHETOPCOVER.

LIGHTFROMLASERSMAYCAUSEVISUALIMPAIRMENTTOEYES.

• Avoidoperatingorlocatingthisdrivenearwaterorothersourcesofuid.

• Do not place this product on an unstable cart, stand, or table. The product may fall and become

seriously damaged.

• When using this device, ensure that you adhere to the displayed warnings and cautions from your

PC manufacturer.

WARNING

Ensure you abide by the following precautions, as failure to do so may lead to re or electric

shock.

• Connect cables to the device only after checking that the cables have not deteriorated and are not

damaged. Do not use any cables that have deteriorated or are damaged.

• Donotdisassembleormodifythedevice.Donotallowmetal,ammableobjects,chemicals,water

or other foreign matter to enter the device.

• Ensure that water does not enter the device, and that it is kept dry.

• Ensureitisusedwiththespeciedpowersupplyvoltage.

10 BDR-XD08UMB-S En

IMPORTANT SAFETY INSTRUCTIONS

In the following circumstances, turn off the device power, unplug the PC, and contact your

dealer or Pioneer.

• If the device smokes, or abnormalities such as strange smells or noises are observed.

• Ifwaterorforeignobjectshaveenteredthedevice.

• If the device has been dropped or the power cord, plug, or chassis is damaged.

When using an AC adapter compatible with this device, ensure that you observe the

following.

• DonotplaceanyobjectsonthepowercordorACadaptercord.Additionally,ensurethatthecords

do not become trapped under the device. Do not cover the cord with a rug or other items.

• Do not damage, modify, forcibly bend, twist, pull, or heat the power cord or AC adapter cord. Doing

somayleadtodamagetothecord,whichcanresultinreorelectricshock.

• Do not connect this device to a direct current (DC) power source (such as used on a ship). Doing

somayleadtoreorelectricshock.

• Do not use AC adapters other than those compatible with this device. Using other AC adapters may

leadtore.

• Do not plug in or unplug the power plug with wet hands. Doing so may lead to electric shock.

• When unplugging the power cord, do not pull on the cord. Doing so may lead to damage to the

cord,whichcanresultinreorelectricshock.Ensurethatyouholdtheplugwhenunplugging.

• Keep the power cord away from heat sources. Failure to do so may cause the insulation on the

cordtomelt,whichcanresultinreorelectricshock.

• Whenmovingthedevice,ensurethatthepowerplugisrstunpluggedfromtheoutlet,andthat

external connection cords are removed. Failure to do so may lead to damage to the cord, which

canresultinreorelectricshock.

Theindicatorsymbolsusedforthisproduct(includingaccessories)indicatethefollowing:

AC (Alternating Current)

DC (Direct Current)

Tabla de contenidos

Idiomas:

Otros manuales de Unidad de CD/CDR de Pioneer

Pioneer

Pioneer BDR-212V Manual de usuario

Pioneer

Pioneer BDR-208EBK Manual de usuario

Pioneer

Pioneer BDR-XS07TUHD Manual de usuario

Pioneer

Pioneer BDR-S12UHT Manual de usuario

Pioneer

Pioneer LaserMemory DR-U16S Manual de usuario

Pioneer

Pioneer BDR-XD08B Manual de usuario

Pioneer

Pioneer DR-504S Manual de usuario

Pioneer

Pioneer LaserMemory DR-U10X Manual de usuario

Pioneer

Pioneer BDR-S13UBK Manual de usuario

Pioneer

Pioneer BDC-2202 Manual de usuario

Pioneer

Pioneer DVR-111D Manual de usuario

Pioneer

Pioneer DR-UA124X-2 Manual de usuario

Pioneer

Pioneer DVR-S806 Manual de usuario

Pioneer

Pioneer BDR-XU03T Manual de usuario

Pioneer

Pioneer BDR-S13U-X Manual de usuario

Pioneer

Pioneer BDR-XD05S Manual de usuario

Pioneer

Pioneer DVD-106S Manual de usuario

Pioneer

Pioneer BDR-2213 Manual de usuario

Pioneer

Pioneer DVR-A05 Manual de usuario

Pioneer

Pioneer BDR-212UBK Manual de usuario

Pioneer

Pioneer BDR-XS07UHD Manual de usuario

Pioneer

Pioneer DVR-117D Manual de usuario

Pioneer

Pioneer DVR-112 Manual de usuario

Pioneer

Pioneer DR-R7181 Manual de usuario

Manuales populares de Unidad de CD/CDR de otras marcas

Philips

Philips CDD3610 Manual de usuario

QPS

QPS Que!Fire Manual de usuario

LG GCC-4241N Manual de usuario

Plextor

Plextor 12X-3 Guía

Samsung

Samsung SN-324B Manual de usuario

Teac

Teac CD-211E Manual de usuario

SmartDisk

SmartDisk Firewire CD-R/W Manual de usuario

Axis

Axis CD-ROM SERVER Manual de usuario

LG CRD-8322B Manual de usuario

Memorex

Memorex 32023234 - 52x32x52x External USB2.0 CD... Instrucciones de instalación

Yamaha

Yamaha CD Recordable/Rewritable Drive CRW3200 Manual de usuario

Sony

Sony CRX230AE Manual de usuario

Sony

Sony CRX - 160E Manual de usuario

Panasonic

Panasonic KX-LD742 Manual de usuario

Panasonic

Panasonic LK-MC606BP Manual de usuario

Panasonic

Panasonic CF-VCW Series Manual de usuario

LG CRD-8320B Manual de usuario

Conner

Conner CFP2107 Series Manual de usuario
