MODEL NUMBERS

MH-16-TTC / MH-32-TTC / MH-47-TTC

User’s Manual &

Operating Instructions

GENERAL HAZARD WARNING:

FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEAT-

ER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM

HAZARDS OF FIRE, EXPLOSION, BURN. ASPHYXIATION, AND/OR CARBON MONOXIDE POISONING.

ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR

SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN IN-

STRUCTIONS MANUAL, LABEL, ETC. CONTACT THE MANUFACTURER.

DANGER

CONSUMER: READ AND SAVE THESE INSTRUCTIONS

FOR OUTDOOR USE. INDOOR USE PERMITTED ONLY FOR:

The temporary heating of adequately ventilated buildings or

structures under construction, alteration or repair.

FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES,

SUCH AS BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY

FROM THE HEATER AS RECOMMENDED BY THESE INSTRUCTIONS. NEVER USE THE HEATER IN

SPACES WHICH DO OR MAY CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS

SUCH AS GASOLINE, SOLVENTS, PAINT THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS.

WARNING

Factory ID: 522

1 Industrial Blvd #101, Sauk Rapids, MN 56379 USA • Toll Free (800) 641-6996

Fax: 320-251-2922 • Web: www.masterindustrialproducts.com • Email: [email protected]

PROPANE TANK TOP

HEATER

Locating Your Serial Number:

Your serial number can be found in the bottom left hand corner of the heater’s instruction hang-tag.

It will begin with the letters “PGTT” followed by 8 digits. For Example: PGTT12345678. Have your Se-

rial Number ready before calling customer service at 800-641-6996.

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

TABLE OF CONTENTS

Safety Information......................................................2-4

Speciﬁcations..................................................................5

Features........................................................................5-6

What’s in the Box.............................................................7

Assembly

......................................................................

8-9

Operation....................................................................10-12

Maintenance and Storage...........................................12

Troubleshooting Guide.................................................13

Exploded View

.........................................................

...

.14

Parts List..........................................................................14

Warranty...........................................................................15

SAFETY INFORMATION

NOT FOR HOME OR RECREATIONAL VEHICLE USE.

WARNING

This is an unvented portable heater. It uses air (oxygen) from the area in which it is

used. Adequate combustion and ventilation air must be provided. Refer to VENTILA-

TION on Page 11.

WARNING

Carbon Monoxide Hazard This heater produces carbon monoxide, which has no

odor. Burning the heater in an enclosed space can kill you. Never use the heater in

enclosed spaces such as a tent, a camper, any vehicle or recreational vehicle (RV), enclosed shelter,

or any other enclosed areas.

DANGER

Not for use in residential living areas or in non-adequately ventilated enclosed spac-

es. Never bring or store a propane cylinder indoors.

DANGER

This heater is designed and approved for use as a construction heater in accordance with Standard

ANSI Z83.7-2011/CSA 2.14-2011. CHECK WITH YOUR LOCAL FIRE SAFETY AUTHORITY IF YOU HAVE

ANY QUESTIONS ABOUT APPLICATIONS. Other standards govern the use of fuel gasses and heating

products for speciﬁc uses. Your local authority can advise you about these.

If the information in this manual is not followed exactly, a ﬁre or explosion may result

causing property damage, personal injury or loss of life.

DANGER

DO NOT OPERATE THIS HEATER UNTIL YOU HAVE READ AND THOROUGHLY UN-

DERSTAND THESE SAFETY AND OPERATING INSTRUCTIONS.

Failure to comply with the precautions and instructions provided with this heater can result in death,

serious bodily injury, property loss or damage from the hazards of ﬁre, explosions, burns, asphyxiation

or carbon monoxide poisoning. Only persons who can read and understand these instructions should

use or service this heater.

WARNING

This product contains chemicals, including lead, which are known to the State of

California to cause cancer and birth defects or other reproductive harm. For more

information go to www.P65Warnings.ca.gov.

WARNING

FOR OUTDOOR USE. INDOOR USE PERMITTED ONLY FOR: The temporary heating

of adequately ventilated buildings or structures under construction, alteration or repair.

WARNING

Do not use with or around birds, foul, or poulty.

DANGER

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

SAFETY INFORMATION

The products described in this manual are pro-

pane direct-ﬁred heaters. Direct-ﬁred means that

all of the combustion products of the heater enter

the heated space. This appliance is rated at 98%

combustion eciency, but does produce small

amounts of carbon monoxide.

Carbon monoxide is toxic. Humans can tolerate

only small amounts of carbon monoxide and so

precautions should be taken to provide proper

ventilation. Failure to provide proper ventilation

in accordance with the instructions in this manual

can result in death.

People with breathing problems should consult a

physician before using this heater.

Early signs of carbon monoxide poisoning re-

semble the ﬂu. Symptoms of improper ventilation /

carbon monoxide poisoning are:

Headache • Dizziness • Nausea • Dry Mouth

Sore Throat • Burning of Nose and Eyes

If you experience any of these symptoms:

GET FRESH AIR AT ONCE! Have your heater

serviced and check for proper ventilation. Some

people are more affected by carbon monoxide

than others. These include: pregnant women,

those with heart or lung problems, anemia or those

under the influence of alcohol or at high altitudes.

FOR OUTDOOR USE. INDOOR USE PERMIT-

TED ONLY FOR: The temporary heating of

adequately ventilated buildings or structures

under construction, alteration or repair! Pro-

vide at least a three square foot (2,800 sq cm)

opening of outside air for every 100,000 Btu /

Hr heater rating. Refer to “Ventilation” on page

11 for further instructions.

WHAT TO DO IF THE SMELL OF GAS IS PRESENT:

–DO NOT attempt to light the heater.

–Extinguish any open ﬂame.

–Shut o gas to heater.

–If odor continues, contact your local gas

supplier or ﬁre department.

–DO NOT touch or use any electric switch or

any electric device that can cause a spark.

–Immediately call your gas supplier from a

neighbors phone. Follow the gas suppliers

instructions.

–If you can not reach your gas supplier, call

the ﬁre department.

–Service must be done by a qualiﬁed service

agency.

NEVER store or use gasoline or other ﬂammable

vapors and liquids in the vicinity of this heater.

NEVER store

a propane (LP) cylinder not connected

to this heater in the vicinity of this heater.

NEVER

connect heater to an unregulated gas supply.

NEVER

obstruct the ﬂow of combustion and

ventilation air. (The front and rear of heater).

NEVER use duct work in front or rear of heater.

NEVER modify this heater or operate a heater that

has been modiﬁed.

NEVER service, move or handle heater while still hot

or operating

NEVER use heater in occupied dwellings.

NEVER use heater in a tent.

RISK OF INDOOR AIR POLLU-

TION!

WARNING

CARBON MONOXIDE POISONING

MAY LEAD TO DEATH!

DANGER

RISK OF BURNS, FIRE AND EX-

PLOSION!

WARNING

PROPANE IS AN

EXPLOSIVE GAS!

DANGER

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

Keep all combustible materials away from this heater.

Minimum Clearance From Combustibles

Sides Top Front Rear

36 in. 60 in. 60 in. 36 in.

ALWAYS install the heater so that it is not directly

exposed to water spray, rain, dripping water, or wind.

ALWAYS provide adequate clearance for accessibility,

combustion and ventilation (air supply) while heater is

operating.

–Use heater in accordance with all local codes.

In the absence of local codes, refer to The

National Fuel Code, ANSI Z223.1.

–This heater is shipped from the factory

for use with propane (LP) gas only. Do not

convert to any other gas. Installation must

conform to local codes, or in their absence,

with the standard for the Storage and Handling

of Liquefied Petroleum Gases ANSI/NFPA 58

and the Natural Gas and Propane Installation

Code CSA B149.1.

–Gas supply connections should be checked by

using a 50/50 soap and water solution. Never

use a ﬂame to check for gas leaks.

–Do not direct heater discharge towards the LP

cylinder unless it is at least 20 feet from the

heater.

–Use only the regulator and hose assembly

provided with this heater. Inspect the

regulator/hose assembly prior to each use of

the heater. If there is excessive abrasion or

wear, or if the hose is cut, replace it with the

proper assembly shown in the parts list, prior

to using the heater.

Minimum and Maximum Inlet Pressure

MH-16-TTC MH-32-TTC MH-47-TTC

Min. 5 PSI

Max. 200 PSI

SAFETY INFORMATION

The hose assembly shall be

protected from trac, building

material and contact with hot surfaces both

during use and while in storage.

WARNING

RISK OF FIRE! ALWAYS ATTACH THE HEATER IN AN UPRIGHT VERTICAL

POSITION. ALWAYS LOCATE HEATER ON A STABLE AND LEVEL SURFACE!

WARNING

CAUTION! HOT WHILE IN OPER-

ATION. DO NOT TOUCH. KEEP

CHILDREN, ANIMALS, CLOTHING AND COM-

BUSTIBLES AWAY FROM HEATER.

WARNING

For use with propane (LP)

gas only.

WARNING

DO NOT use any LP cylinder

larger than 20 lbs.

WARNING

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

FEATURES

MH-16-TTC

Regulator

SPECIFICATIONS

Model # MH-16-TTC MH-32-TTC MH-47-TTC

BTU 12 / 14 / 16,000 25 / 28 / 32,000 36 / 40 / 47,000

Fuel Consumption (Lbs./hr) 0.56 / 0.65 / 0.74 1.16 / 1.30 / 1.49 1.67 / 1.86 / 2.18

Maximum Operating Hours 35.9 / 30.8 / 27.0 17.2 / 15.4 / 13.4 12.0 / 10.8 / 9.2

Required Cylinder Lbs. 20 20 20

Fuel Type Propane Propane Propane

Heating Area (Ft.2) 300 / 350 / 400 620 / 700 / 800 900 / 1000 / 1175

Specications subject to change without notice.

Front Guard

Heat Reﬂector

Rear Guard

Ignition Hole

Tip Over Switch

Safety Valve

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

FEATURES CONT.

MH-32-TTC

Regulator

Front Guard

Heat Reﬂector

Rear Guard

Ignition Hole

Tip Over Switch

Safety Valve

MH-47-TTC

Mounting Bolt Knob

Hose

Front Guard

Heat Reﬂector

Safety Valve

Mounting Bolt Knob

Hose

Rear Guard

Ignition Hole

Regulator

Tip Over Switch

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

WHAT’S IN THE BOX

MH-16-TTC

MH-32-TTC

MH-47-TTC

(1) Mount and Unit with Single

Burner Head

(1) Unit with Two Burner

Heads

(1) Mount

(1) Mount (1) Unit with Three Burner

Heads

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

ASSEMBLY

Model MH-32-TTC:

Tools Needed:

–Medium Phillips head screwdriver.

1. Place the tank collar bracket on top of the

center plate. Be sure the mounting bolt knob is

on bottom as shown in Figure 1.

2. Insert machine screw into top hole using

Phillips head screwdriver.

3. Insert 2nd machine screw into bottom hole.

This will secure the tank collar bracket to the

center plate.

Model MH-47-TTC:

Tools Needed:

–Medium Phillips head screwdriver.

1. Insert the mounting bolt knob into the tank

collar bracket.

2. Place tank collar bracket on the swivel bracket.

3. Place the plane washer on the tank collar

bracket and then insert the support bolt

(see Figure 2)

4. See Figure 3 on page 9 for determining burner

position options.

DO NOT adjust burner heads while heater is operating.

WARNING

Regulator

Knob

Fuel Connector Nut

Machine

Screws

Mounting Bolt Knob

Tank Collar Bracket

Tip over Switch

Assembly

Swivel

Manifold

Mounting

Bolt Knob

Plane Washer

Wing Nut

Regulator

Knob

Fuel Connector Nut Tank Collar Bracket

Swivel Bracket

Figure 1 Figure 2

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

ASSEMBLY

MH-47-TTC (Continued):

–To have all 3 burners face front, the plane

washer should be to the right side of tank collar

bracket (see Figure 3).

–To have far left burner face back, the plane

washer should be to the left side of tank collar

bracket (see Figure 3).

Figure 3

Connecting Heater to LP Cylinder:

Be sure to read and understand all of the Safety

Information in this manual before connecting

the heater to the LP cylinder. Installation must

conform to local codes and with the Standard for

the Storage and Handling of Liquefied Petroleum

Gasses and ANSI/NFPA 58.

Inspect the hose and regulator prior to each

use of the heater. If there is excessive abrasion

or wear, or if the hose is cut, replace it with the

proper assembly shown in the parts list prior to

using the heater.

Model MH-16-TTC:

1. Be sure that the control knob on the regulator is

in the “OFF” position.

2. Line up the threads on the fuel connector nut

with the threads on the LP cylinder valve. Turn

fuel connector nut COUNTERCLOCKWISE to

tighten. Fully tighten the nut, being careful not to

over tighten.

3. Slowly open the LP cylinder valve.

Models MH-32-TTC / MH-47-TTC:

1. Be sure that the control knob on the regulator is

in the “OFF” position.

2. Line up the slots in the tank collar bracket with

the tank collar ring and slide into place. Be

sure the mounting knob is to the outside, and

tighten.

3. Line up the threads on the fuel connector nut

with the threads on the LP cylinder valve. Turn

fuel connector nut COUNTERCLOCKWISE to

tighten. Fully tighten the nut, being careful not to

over tighten.

4. Slowly open the LP cylinder valve.

Check all connections for leaks using a 50/50

mixture of dish-soap and water. Any bubbles

that appear show a leak. Remove and reconnect

the Connector Nut to the valve.

DO NOT direct the heater dis-

charge towards any propane

cylinder located within 20 feet of the heater.

WARNING

NEVER LEAVE HEATER UNATTENDED

WHILE BURNING OR WHILE CONNECTED

TO A FUEL SOURCE

OPERATION

Propane Supply / Information:

Propane (LP)

This heater is not supplied with a propane cylinder.

Use only an approved propane cylinder.

LP Characteristics

–Flammable, explosive under pressure, heavier

than air and pools in low areas.

–In its natural state, propane has no odor, but

for your safety an odor that smells like rotten

cabbage has been added.

–Contact of propane (LP) gas with the skin can

cause freeze burns.

–Heater is manufactured for use with propane

gas only. DO NOT attempt to convert to any

other gas. Such modiﬁcations are dangerous

and will void the warranty.

–When heater is not in use, LP Cylinder must be

turned OFF.

–Be sure that the LP Cylinder is located on a level

and stable surface.

–DO NOT use this heater in a basement or below

ground level. Propane is heavier than air and

will always seek the lowest level. If you suspect

a leak, shut o the valve at the LP Cylinder

immediately.

The Propane (LP) cylinder must also be equipped

with the following:

–A collar to protect the gas valve.

–A shut-o valve terminating a LP cylinder valve

outlet as speciﬁed in the American National

Standard for Compressed Gas Cylinder Valve

Outlets and Inlets Connections.

–A safety relief valve having direct

communications with the vapor space of the LP

cylinder.

–The heater must operate on vapor withdrawal

from the operating cylinder.

The amount of Propane (LP) used with this heater

varies. Both factors are:

–The amount of gas in the cylinder of LP.

–The temperature of the LP tank and its

surroundings.

–Always keep LP cylinder fastened and upright.

–Avoid tipping the LP cylinder on its side when

connected to a regulator, since this may cause

damage to diaphragm in the regulator.

–Handle valves with care.

–Never connect an unregulated LP cylinder to a

construction heater.

–DO NOT subject LP cylinder to excessive heat.

–Tightly close the gas shuto valve on the LP

cylinder after each use.

–All ﬁttings must be protected when

disconnected from the LP cylinder.

–Never store an LP cylinder inside a building or

in the vicinity of a gas burning appliances.

Propane is safe to use when

properly handled. Careless

handling of the LP cylinder could result in a ﬁre

and or an explosion.

CAUTION

The disconnected tank must

never be stored in a building,

garage or any other enclosed area.

CAUTION

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Calentador de Pinnacle

Pinnacle

Pinnacle ProTemp PT-80-OFR Manual de capacitación

Pinnacle

Pinnacle Protemp PT-150T-DFV Manual de capacitación

Pinnacle

Pinnacle Protemp PT-80V-LPC-A Manual de capacitación

Pinnacle

Pinnacle MASTER MH-360A-TTC Manual de capacitación

Pinnacle

Pinnacle Remington REM-40-GFA-B Manual de capacitación

Pinnacle

Pinnacle REMINGTON REM-45-KFA-O Manual de capacitación

Pinnacle

Pinnacle Protemp PT-35-HS Manual

Pinnacle

Pinnacle MASTER MH-80-OFR Manual de capacitación

Pinnacle

Pinnacle Remington REM-360A-TTC-O Manual de capacitación

Pinnacle

Pinnacle ProTemp PT-18PNCH-A Manual de capacitación

Pinnacle

Pinnacle Protemp PT-170T-IDF-EU Manual

Pinnacle

Pinnacle Heat-Stream HS-18-PCH Manual

Pinnacle

Pinnacle MH-45-KFA Manual de capacitación

Pinnacle

Pinnacle Master MH-70-SS-A Manual de capacitación

Pinnacle

Pinnacle MASTER MH-03-240-GH Manual de usuario

Pinnacle

Pinnacle HEAT-STREAM HS-45-KFA Manual

Pinnacle

Pinnacle REMINGTON REM-16-TTC-O Manual de capacitación

Pinnacle

Pinnacle ProTemp PT-125-OFR-A Manual

Pinnacle

Pinnacle Remington REM-45-KFA-B Manual de capacitación

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
