HUNTER-PRO

Installation Manual

Supplement

ZONE DOUBLING

P/N

44100

84 Rev. A (Jan-2003)

PIMA Electronic Systems Ltd.

5 Hatzoref Street, Holon 58856, Israel

℡

+972-3-5587722



+972-3-5500442



support@pima-alarms.com



http://www.pima-alarms.com

Last printed on:

2003

2:30

החא

Last saved on:

2003

2:19

החא

PIMA Electronic Systems Ltd. does not represent that its Product may not be compromised and/or

circumvented, or that the Product will prevent any death, personal and/or bodily injury and/or damage to

property resulting from burglary, robbery, fire or otherwise, or that the Product will in all cases provide

adequate warning or protection. The User understands that a properly installed and maintained

equipment may only reduce the risk of events such as burglary, robbery, and fire without warning, but it

is not insurance or a guarantee that such will not occur or that there will be no death, personal damage

and/or damage to property as a result.

PIMA Electronic Systems Ltd. shall have no liability for any death, personal and/or bodily injury and/or

damage to property or other loss whether direct, indirect, incidental, consequential or otherwise, based

on a claim that the Product failed to function.

Warning:

The user should follow the installation and operation instructions and among other things test

the Product and the whole system at least once a week. For various reasons, including, but not limited

to, changes in environment conditions, electric or electronic disruptions and tampering, the Product may

not perform as expected. The user is advised to take all necessary precautions for his/her safety and the

protection of his/her property.

This document may not be duplicated, circulated, altered, modified, translated, reduced to any form or

otherwise changed, unless PIMA’s prior written consent is granted.

All efforts have been made to ensure that the content of this manual is accurate. Pima retains the right to

modify this manual or any part thereof, from time to time, without serving any prior notice of such

modification.

Please read this manual in its entirety before attempting to program or operate your system. Should you

misunderstand any part of this manual, please contact the supplier or installer of this system.



You can contact us at:

PIMA Electronic Systems Ltd.

5 Hatzoref Street, Holon 58856, Israel

http://www.pima-alarms.com

HUNTER-PRO Installation Manual Supplement - ZONE DOUBLING

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

iii

able of ContentsT

Table of Contents

Introduction .....................................................................................................1

Upgrading an Existing HUNTER-PRO..................................................................... 1

Upgrade Kit Contents...................................................................................................... 2

Zones Connection Options ..................................................................................... 2

Connecting and Configuring...........................................................................3

Connecting the Doubled Zones .............................................................................. 3

Connecting Without an EOL Resistor .............................................................................. 3

Connecting With an EOL Resistor ................................................................................... 4

Connecting Normally Open Detectors............................................................................ 5

When Doubling Some of the Zones ................................................................................ 5

Configuring HUNTER-PRO for Zone Doubling....................................................... 6

Table of Contents

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

This page was intentionally left blank

HUNTER-PRO Installation Manual Supplement - ZONE DOUBLING

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

ntroductionI

Introduction

Zone Doubling is a cost-effective way to expand the eight-zone

HUNTER-PRO control panel up to 16 zones. The zone doubling is done

without any hardware add-on. Zone doubling uses the same HUNTER-

PRO panel, the smoke input and adding a resistor and diode to each of

the doubled zones.

While using the Zone Doubling feature, the doubled zones cannot be

protected with two EOL resistors. More detailed description of different

connecting options, can be found in this HUNTER-PRO Installation

Supplement.

Upgrading an Existing HUNTER-PRO

The Zone Doubling feature is supported with HUNTER-PRO version 2k and

up. Also required is a 16Kb E

PROM (i.e., the U2 CHIP should be 24C16).

When upgrading an earlier version of HUNTER-PRO, both the EPROM and

the E

PROM should be replaced (see Figure 1).

HUNTER

PRO

EXPANSION CARD

SERIALKEYBOARD

T AUD

CONT

JP2 JP4

U2 E2PROM

24C16

U3 EPROM

REP 2l

Figure 1 - Replacing the EPROM and the E

PROM

IMPORTANT!

Before attempting to replace the memory chips, the control panel MUST be

DISCONNECTED from all power sources (i.e., AC and DC).

Connecting and Configuring

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

Upgrade Kit Contents

The upgrade kit includes the following items:



HUNTER-PRO EPROM with version 2l



16Kb E

PROM



8 Diodes



8 Resistors

Zones Connection Options

The Zones can be connected in one of the configurations described in

Table 1.

Table 1 - Zones Connection Options

Option Number

of Zones

EOL Configuration Detector Type

No Zone

Doubling

Up to 8 None, 1, or 2 EOL

resistors on all eight zones

NC or NO on all

eight zones

Zone

Doubling

Up to 16 When all zones are

doubled:

•

None or 1 EOL resistor

When some of the zones

are doubled:

•

None, 1, or 2 EOL

resistors on un-doubled

zones

•

None or 1 EOL resistor

on all other zones

For zones 1 trough

•

NC type ONLY

For zones 9

through 16:

•

NC or NO type

detectors

NOTE:

If two EOL resistors are required for all 16 zones, an eight zones expansion card (EXP-

1001) should be used instead.

HUNTER-PRO Installation Manual Supplement - ZONE DOUBLING

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

ntroductionI

Connecting and

Configuring

Connecting the Doubled Zones

Connecting Without an EOL Resistor

Zones 1 through 8 are connected with a serial 10K

Ω

resistor to the zone

inputs on the control panel (see Figure 2). Zones 9 to 16 are connected

with a serial diode to the zone inputs (i.e., zone 9 is connected to zone

input 1, 10 to 2, etc.) and uses the SMOKE input instead of the GND (see

Figure 2).

10K ¼W

Z1 Z2 Z3 Z4 -+Z5 Z6 Z7

F 5A 250VAC

TMPR

ON/

OFF

ALARM

KEYBOARD

JP5

S2 C N.O N.C -

RELAY SMOKE

-+INOUT

LINE SET

F4F3

Diode

Zone 1 (NC)

(zones 2 to 8

are connected

the same way)

Zone 9 (NC)

(zones 10 to 16

are connected

the same way)

Figure 2 - Zone Doubling Without EOL Resistors

Connecting and Configuring

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

IMPORTANT!

Pay attention to the polarity (direction) of the diode when connecting it (see Figure 3).

Figure 3 - Connecting the Diode

Connecting With an EOL Resistor

Zones 1 through 8 are connected as without an EOL resistor (i.e., a serial

10K

Ω

resistor to the zone inputs on the control panel; see Figure 4). Zones

9 to 16 are connected with a serial diode and resistor to the zone inputs

(i.e., zone 9 is connected to zone input 1, 10 to 2, etc.) and uses the

SMOKE input instead of the GND (see Figure 4).

10K ¼W

Z1 Z2 Z3 Z4 -+Z5 Z6 Z7

F 5A 250VAC

TMPR

ON/

OFF

ALARM

KEYBOARD

JP5

S2 C N.O N.C -

RELAY SMOKE

-+INOUT

LINE SET

F4F3

Diode

Zone 1 (NC)

(zones 2 to 8

are connected

the same way)

Zone 9 (NC)

(zones 10 to 16

are connected

the same way)

10K ¼W

Figure 4 - Zone Doubling With EOL Resistors

This side is

connected to the

SMOKE input

HUNTER-PRO Installation Manual Supplement - ZONE DOUBLING

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM

ntroductionI

NOTE:

Figure 4 illustrates how to connect NC (Normally Closed) type detectors; for NO

(Normally Open) type read the following.

Connecting Normally Open Detectors

As a rule, when using Zone Doubling Feature, Zones 1 through 8 can

include ONLY Normally Closed (NC) type detectors. The NO detectors

(with the EOL resistor) should be installed as illustrated in Figure 5.

10K ¼W

Z1 Z2 Z3 Z4 -+Z5 Z6 Z7

F 5A 250VAC

TMPR

ON/

OFF

ALARM

KEYBOARD

JP5

S2 C N.O N.C -

RELAY SMOKE

-+INOUT

LINE SET

F4F3

Diode

Zone 1 (NC)

(zones 2 to 8

are connected

the same way)

Zone 9 (NO)

(zones 10 to 16

are connected

the same way)

10K ¼W

Figure 5 - Connecting NO Detectors (Zones 9 through 16)

When Doubling Some of the Zones

When not doubling all the zones, the following should be taken into

consideration:



The upper un-doubled zones should be permanently bypassed, as

they are not present (e.g., if zones 7 and 8 are not doubled, zones 15

and 16 should be bypassed).



Each lower zone has its upper doubled zone match (i.e., zone 1 is

matched with zone 9, zone 2 with zone 10, etc.)

Connecting and Configuring

Last printed: 1/12/2003 2:30 PM

Last saved: 1/12/2003 2:19 PM



When un-doubled zones are connected with two EOL resistors, all

other (doubled and regular) zones should be programmed as NOT

protected with EOL resistors; i.e., the EOL characteristic (“E”) should

be disabled (“-“) in the Zone Characteristic menu.

NOTE:

If two EOL resistors are required for all 16 zones, an eight zones expansion card (EXP-

1001) should be used instead.

Configuring HUNTER-PRO for Zone

Doubling

The new version has some additional screens in the System Configuration

menu.

To enter the Zone Doubling configuration screen

[

Master Code

→

SERVICE

→

[

Technician Code

→

HOME 2

→

ENTR

(eight

times)

System Configuration, Screen 8 (new) is displayed (see Figure).

W 1 J MWireles s

- - -

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

W For future use.

1 For future use.

J For future use.

M Zone Doubling feature; when enabled (+), the zone-doubling feature

is enabled and the HUNTER-PRO can support up to 16 zones without

expanding the hardware.

After enabling the Zone Doubling, the 16 zones can be configured using

the standard Zone Characteristics menus.

Otros manuales para hunter-pro

Tabla de contenidos

Otros manuales de Sistema de seguridad de Pima

Pima

Pima SRO743 Especificaciones técnicas

Pima

Pima HUNTER-PRO 896 Manual de usuario

Pima

Pima FORCE Series Manual de usuario

Pima

Pima HUNTER-PRO RXN-9 Manual de usuario

Pima

Pima Hunter-Pro 832 Manual de usuario

Pima

Pima hunter-pro Manual de usuario

Pima

Pima hunter-pro Manual de usuario

Pima

Pima FORCE Manual de usuario

Pima

Pima VISION Manual de usuario

Pima

Pima CAPTAIN-i 4410061 Manual de usuario

Pima

Pima Captain 6 Manual de usuario

Pima

Pima VISION Manual de usuario

Pima

Pima Hunter-Pro Series Manual de usuario

Pima

Pima hunter-pro Manual de usuario

Pima

Pima Hunter-Pro 32 Manual de usuario

Pima

Pima AlarmView Manual de usuario

Pima

Pima HUNTER-PRO 32 RXN-9/416 Manual de usuario

Pima

Pima N-406 Manual de usuario

Pima

Pima Hunter-Pro 832 Manual de usuario

Pima

Pima Captain 8 Hunter-Pro 832 Manual de usuario

Pima

Pima Sentinel Manual del operador

Pima

Pima HUNTER-PRO RSA Manual de usuario

Pima

Pima FORCE Instrucciones de funcionamiento

Pima

Pima Hunter-Pro 832 Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario

Pima hunter-pro Guía de configuración

Manuales populares de Sistema de seguridad de otras marcas
