Pilz PSSuniversal Guía del usuario

System Description — No. 21256-EN-04

Programmable control systems PSS®

PSSuniversal

_Name_Bookmark2_

This document is a translation of the original document.

All rights to this documentation are reserved by Pilz GmbH & Co. KG. Co ies may be made

for internal ur oses.

Suggestions and comments for im roving this documentation will be gratefully received.

Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS ®, SafetyEYE®,

SafetyNET ®, the s irit of safety® are registered and rotected trademarks of

Pilz GmbH & Co. KG in some countries.

SD means Secure Digital.

_Name_Bookmark2_

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected] 1

Contents

Contents Page

Chapter 1 Introduction

1.1 Validity of the documentation 1-1

1.2 Overview of the documentation 1-2

1.3 Definition of symbols 1-3

Chapter 2 Overview

2.1 General 2-1

2.2 Objective of the PSSu system 2-2

2.3 Features of the PSSu system 2-3

2.4 System software for PSSu systems 2-4

Chapter 3 Safety

3.1 General guidelines 3-1

3.2 Intended use 3-2

3.3 Use of qualified personnel 3-3

3.4 Failsafe inputs/outputs 3-4

Chapter 4 Basics

4.1 Structure of a PSSu system 4-1

4.2 Module layout 4-3

4.3 Module descriptions 4-5

4.4 Module bus 4-7

4.5 Connections on the base modules 4-9

4.5.1 Connection levels on input/output mod-

ules

4-9

4.5.2 Colour marking on the connection levels 4-10

4.6 Connections on the compact modules 4-11

4.7 Maximum system expansion 4-12

4.7.1 SafetyBUS p and standard bus systems 4-13

4.7.2 Number of modules and number of inputs/

outputs on a PSSu system

4-14

4.7.3 Maximum current load 4-15

4.7.3.1 Maximum current load capacity on the

supply voltage modules

4-15

4.7.3.2 Maximum current load capacity based on

temperature

4-16

4.8 Device description files 4-17

4.9 Local enable principle 4-19

4.10 Slots on a PSSu system 4-21

4.11 Addressing the modules 4-22

4.11.1 Addressing principle 4-22

4.11.2 Addresses and bit requirement of a PSSu

system

4-23

4.11.3 Status bytes 4-24

Contents

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]

4.11.4 Configurations that impact the address

and bit requirement

4-25

4.11.5 Overview of the modules' bit requirement 4-26

4.11.6 Example: Bit requirement and addressing 4-29

4.11.7 Optimisation of module layout 4-32

4.12 Supply voltage and insulation 4-39

4.13 Supply groups 4-42

4.14 Reaction times of the PSSuniversal 4-44

4.14.1 Scan time of a PSSu system 4-45

4.14.2 Input/output processing time 4-45

4.14.3 Input reaction time 4-46

4.14.4 Output reaction time 4-47

Chapter 5 PSSuniversal on SafetyBUS p

5.1 Configure PSSu for SafetyBUS p 5-1

5.2 Circuit examples 5-3

5.2.1 1-channel actuator with feedback loop and

local enable

5-3

5.2.2 2-channel actuator with feedback loop and

local enable

5-6

Chapter 6 Commissioning

6.1 Procedure 6-1

6.1.1 Assembly of the PSSu systems in the

PSSuniversal Assistant

6-2

6.1.2 Programming in the SafetyBUS p

Configurator

6-3

Chapter 7 Diagnostics

7.1 Diagnostic data of electronic modules 7-1

7.2 Head module's error stack 7-4

Chapter 8 Appendix

8.1 Glossary 8-1

8.2 Modules' hexadecimal code 8-5

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected] 1-1

1.1 Validity of the documentation

1 Introduction

11000IntroductionIntroduction1-1.1Validity of the documentation1100Validity of the documentation1-][Einführun g PSSu Gül tigkeit Sys A

This documentation is valid for PSSu systems in system environment A.

A PSSu system in system environment A may be used in the

Decentralised system PSSu I/O with SafetyBUS p

Decentralised system PSSu I/O with ST fieldbuses such as CANopen,

DeviceNet

Not in the automation system PSS 4000

It is valid until new documentation is published.

The latest documentation is always enclosed with the product.

1.2 Overview of the documentation

1 Introduction

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]

1-2

1.2Overview of the documentation1200Overview of the documentation1-][Einfhrung Sys bersicht

1 Introduction

The introduction is designed to familiarise you with the contents, struc-

ture and specific order of this system description.

2 Overview

This chapter contains a brief description of what constitutes a PSSu sys-

tem.

3 Safety

This chapter must be read as it contains important information on safety

regulations.

4 Basics

This chapter describes the PSSu system as a whole and provides con-

figuration guidelines.

5 PSSu systems on SafetyBUS p

This chapter shows how the PSSu systems are connected to

SafetyBUS p.

6 Commissioning

This chapter describes the commissioning process step-by-step and

explains the aids that are available.

7 Diagnostics

This chapter contains a description of the available diagnostic proce-

dures.

8 Appendix

The appendix contains information in table format.

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected] 1-3

1.3 Definition of symbols

1 Introduction

1.3Defi nition of symb ols1300Defi nition of symb ols1-Einfhrung Zeichen

Information that is particularly important is identified as follows:

DANGER!

This warning must be heeded! It warns of a hazardous situation

that poses an immediate threat of serious injury and death and

indicates preventive measures that can be taken.

WARNING!

This warning must be heeded! It warns of a hazardous situation

that could lead to serious injury and death and indicates preven-

tive measures that can be taken.

CAUTION!

This refers to a hazard that can lead to a less serious or minor

injury plus material damage, and also provides information on

preventive measures that can be taken.

NOTICE

This describes a situation in which the product or devices could

be damaged and also provides information on preventive meas-

ures that can be taken.

INFORMATION

This gives advice on applications and provides information on

special features, as well as highlighting areas within the text that

are of particular importance.

1 Introduction

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]

1-4

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected] 2-1

2.1 General

2Overview

22000OverviewOverview2-2.1General2100General2-][Uebersicht PSSu-System Sys A

A PSSu system is assembed from a variety of modules, to suit the func-

tions required. The modular structure makes it easier to react to modifi-

cations and adjustments.

The scope of a PSSu system can also be adapted retrospectively, e.g.

Extending the number of I/Os

Modifying the I/O technology

(e.g. by using relay outputs instead of semiconductor outputs)

Adding I/O functions

(e.g. by retrospectively adding analogue evaluation, counter func-

tions, temperature evaluation)

PSSu systems can be assembled for

Safety-related tasks

Module selection must be based on failsafe modules (FS modules).

Non-safety-related tasks

Standard modules (ST modules) may be selected.

Safety-related and non-safety-related tasks

The PSSu system can be assembled using a mixture of FS and ST

modules.

SafetyBUS p is the preferred system to use for safety-related networked

tasks.

Data transfer via SafetyBUS p is based on CAN technology. The safety

of the data transfer is achieved through the protocol. The protocol in-

cludes the following security mechanisms:

Formation of CRC sums

Echo mode

Connection tests

Addressing tests

Time monitoring functions

2.2 Objective of the PSSu system

2Overview

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany

Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]

2-2

2.2Objective of the PSSu system2200Objective of the PSSu system2-][Uebersicht Zie lsetzu ng Sys A

The objective in using PSSu systems is to achieve the following:

Standard and safety in one product

Multifunctionality

Function and performance range tailored exactly to the application

Flexibility and expandability

Less work involved in installation, commissioning and maintenance

Greater availability

Uncomplicated control of safety-related systems

Standardised functionality for safety-related components
