Issue 1.3 November 2022

40/42-850A/852A User Manual

PXI/PXIe MEMS Fiber Optic Multiplexer Module

Page (II) MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy and reference should be made to the safety instructions for

provisions of lifting and moving.

LASER PRODUCT

This product is capable of switching laser optical signals.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Hardware Interlock ................................................................2.2

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI/PXIe Modules ...4.1

Module Architecture..............................................................4.2

Programming The Module ....................................................4.3

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting .........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Relay Lookup Tables.............................................................7.1

Component Layout................................................................7.2

CONTENTS

Page (VI) MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the PXI/LXI chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

WARNING - RISK OF INJURY SYMBOL

This product may be specically designed to switch optical signals. Under no circumstances look

into the end of an optical output or an optical cable attached to an optical output. LASER RADIATION

CAN SERIOUSLY DAMAGE YOUR EYESIGHT.

Read and understand the safety information of the laser source connected to the optical switch.

Page (VIII) MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

Page (VIII) REED RELAY MODULE 40-110/115/120/125

pickering

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user

I/O signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• Modules are not accessed to EN 60825, users should observe the safety instructions and laser

class for the 3rd party laser source.

• The module may be capable of switching optical signals from a laser device; do not stare directly

at the user I/O ports.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

PXI/PXIe MEMS Fiber Optic Multiplexer 40/42-850A/852A

pickeringtest.com

ISSUE 1.2 NOV 2022

Ch 1

Ch 2

Ch 3

Ch 4

Com

Ch 5

Ch 6

Ch 7

Ch 8

Com

Ch 1

Ch 2

Ch 3

Ch 4

40/42-852A

8-Channel Fiber Optic Multiplexer

40/42-850A

4-Channel Fiber Optic Multiplexer

yAvailable as PXI or PXIe Modules

ySingle 8 to 1 or Single 4 to 1 Fiber Optic MUX

yAvailable With Optional Hardware Interlock

yHigh Density 1 or 2 Slot Width Modules

yFC/APC, FC/PC or SC/PC Connectors

ySmall Form Factor Connectors LC or

MU (mini SC)

ySingle Mode & Multi-Mode Versions

yLong Operating Life, High

Repeatability & Temperature Stability

yFast Switching Time

yLED Indication Included on Speciﬁc Models

yVISA, IVI & Kernel Drivers Supplied for Windows

yPXI Versions Supported by PXI or LXI Chassis

y3 Year Warranty

The 40-850A (PXI) and 42-850A (PXIe) are 4-channel MEMS

ﬁber optic multiplexers and the 40-852A (PXI) and 42-852A

(PXIe) are 8-channel MEMS ﬁber optic multiplexers. They

are available with different connector styles to suit most

applications: FC/APC (for optimal performance), FC/PC

and SC/PC for general applications and LC and MU for

high density applications.

These multiplexers use MEMS (Micro-Electro-Mechanical-

Systems) based optical switches to route the common to a

channel by redirecting the optical signal. This is achieved

using micro-mechanical mirrors driven by a highly precise

mechanism activated via an electrical control signal.

MEMS offers many advantages over traditional optical

prism technology as used in the 40-810/815/820 modules.

MEMS offers similar optical performance but with lower

price, higher packing density, faster operate time and much

longer operating life.

Pickering can construct custom optical systems to

customers precise requirements. We have a large range

of electrical switching modules which can form a complete

PXI based telecom switching solution.

Applications for these multiplexers can be found in ﬁber

network conﬁguration, ﬁber optic component test or where

optical signal routing is required.

40-850A

4-Channel MUX,

FC/PC Connectors, With

Hardware Interlock

Option

40-852A

8-Channel MUX,

LC Connectors,

Without

Hardware

Interlock

Alternative Optical Switching Products

We also offer larger switching populations and alternative

architectures in plug-in module format hosted by our

LXI Scalable Chassis. The 65-280 range includes 2x2,

4x4, 5x5, 8x8 and 16x16 optical matrices, and the 65-281

range includes SPST, 2:1, 4:1, 8:1 16:1 and 32:1 optical

multiplexers. All conﬁgurations are available with single or

multi-mode ﬁbre and a choice of connectors.

Page 1.2 MEMS FIBER OPTIC MULTIPLEXER MODULE 40/42-850A/852A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

MEMS Fiber Optic MUX, 40/42-850A/852A

pickeringtest.com

Speciﬁcations

Power Requirements - 40-850A & 40-852A

+3.3 V +5 V +12 V -12 V

150 mA 300 mA (typ 220 mA) 0 0

Power Requirements - 42-850A & 42-852A

+3.3 V +12 V

150 mA TBD

General Speciﬁcation (All versions)

Fiber Switch Type:

Internal Fiber Type:

MEMS

SM 9/125

Wavelength:

Insertion loss (4 channel versions):

Insertion loss (8 channel versions):

Return loss (APC version):

Return loss (other versions):

Polarization dependent loss (PDL):

Repeatability:

Crosstalk:

Optical Input Power:

1240 to 1640 nm

1 dB Typ

1.5 dB Typ

60 dB Min

55 dB Min

0.05 dB Max

±0.01 dB Max

-60 dB Max

300 mW Max

Thermal Stability:

(-10 to 75 °C insertion loss variation)

0.2 dB Max

Expected Life: >>109 operations

Maximum Switching Time:

Cycle Rate:

1 ms

500/sec

Additional Speciﬁcation (MM versions)

Fiber Switch Type:

Internal Fiber Type:

MEMS

MM 62.5/125 or

50/125

Wavelength:

Insertion loss (4 channel versions):

Insertion loss (8 channel versions):

Return loss (other versions):

Polarization dependent loss (PDL):

700 to 1700 nm

1 dB Typ

1.5 dB Typ

55 dB Min

0.05 dB Max

Connectors

40-850A & 40-852A - PXI bus via 32-bit P1/J1 backplane

connector.

42-850A & 42-852A - PXIe bus via XJ3 and XJ4 backplane

connectors.

Signals via front panel connectors, for connector positions

please refer to the operating manual:

• 40/42-85xA-01x FC/APC connectors

• 40/42-85xA-11x FC/PC connectors

• 40/42-85xA-21x SC/PC connectors

• 40/42-85xA-31x MU (mini SC) connectors

• 40/42-85xA-41x LC connectors

• 40/42-85xA-51x ST connectors

• Interlock: 1 x 4-pin female 00 series connector*

(40/42-85xA versions with hardware interlock option)

*Mating half supplied when hardware interlock option

ordered.

Other Connector Types

Pickering can manufacture ﬁber optic switch modules

with other connector types, please contact sales ofﬁce for

further information.

Hardware Interlock

The 40/42-850A and 40/42-852A modules are

available with an optional hardware interlock.

The interlock, when activated, will return all

optical switches to their default unpowered state

(assuming the switches are fully functional) and

also provide error notiﬁcation via the software

interface. The interlock feature can be daisy-

chained between additional hardware interlock

enabled modules for example to allow one signal

to disable multiple cards. For further details

please refer to the Hardware Interlock section

within the user manual.

The hardware interlock feature is not available

on 40/42-850A-4xx or 40/42-852A-4xx modules

due to the size of the LC connectors.

Note: LED indication is not available for modules

with the hardware interlock feature.

100 Ω

+3.3 V

GND

External

Wire Link

Front Panel

Connector

Interlock

Daisy-chain

Interlock

Detection

Circiuitry

Processor Relay Driver(s)

SPI Serial

Comms

Output Enable

SPI Serial

Comms

Output Enable

Drive

Outputs

Optical

Switches

Interlock Signal Routing Diagram for 40/42-850A &

40/42-852A Versions With Hardware Interlock Option

Interlock Connector

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Multiplexor de Pickering

Pickering

Pickering 40-659A Manual de usuario

Pickering

Pickering 50-670C Manual de usuario

Pickering

Pickering 60-850 Manual de usuario

Pickering

Pickering PXI Power MUX BRIC 40-571 Manual de usuario

Pickering

Pickering 40-737 Manual de usuario

Pickering

Pickering 40-615A Manual de usuario

Pickering

Pickering PXI 40-785B Manual de usuario

Pickering

Pickering LXI 60-802 Manual de usuario

Pickering

Pickering 40-659A Manual de usuario

Pickering

Pickering 40-612A Manual de usuario

Pickering

Pickering 40-680 Manual de usuario

Pickering

Pickering 40-760 Manual de usuario

Pickering

Pickering 42-204 Manual de usuario

Pickering

Pickering 40-655A Manual de usuario

Pickering

Pickering PXI 40-740 Manual de usuario

Pickering

Pickering 40-652A Manual de usuario

Pickering

Pickering 40-784A Manual de usuario

Pickering

Pickering PXI Power MUX BRIC 40-571A Manual de usuario

Pickering

Pickering 20-745 Manual de usuario

Pickering

Pickering PXI 40-660 Manual de usuario

Pickering

Pickering 40-570A Manual de usuario

Pickering

Pickering 40-614C Manual de usuario

Pickering

Pickering 40-660A-001 Manual de usuario

Pickering

Pickering SYSTEM 10 Manual de usuario

Manuales populares de Multiplexor de otras marcas

Campbell

Campbell AM416 Manual de usuario

Paradyne

Paradyne SIM2000 Manual de usuario

Panasonic

Panasonic WJFS616 - SWITCHER Manual de usuario

Lanex

Lanex TM-77 Manual de usuario

Bosch

Bosch VSS8394/01T Manual de usuario

Quark-Elec

Quark-Elec QK-A035 Manual de usuario

ADTRAN

ADTRAN Frameport 768 Manual de usuario

Elo TouchSystems

Elo TouchSystems E247 Manual de usuario

Paradyne

Paradyne Hotwire 8786 Manual de usuario

RFL Electronics

RFL Electronics 9508D UCC Manual de usuario

Miranda

Miranda AMX-101i Manual de instrucciones

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manual de usuario

GE StoreSafe SDVR-10 Manual de usuario

American Fibertek

American Fibertek MTX-8410C Manual de usuario

ADC

ADC HiGain ELU-319 5E Manual de usuario

Paradyne

Paradyne Hotwire 8774 Manual de usuario

American Fibertek

American Fibertek MTX-8810C-SL Manual de usuario

Viessmann

Viessmann 5229 Manual de usuario
