Phorus PR1 Receiver
Owner’s Manual
i
Table of Contents i
Safety Information - Warnings and Cautions 1
System Requirements 2
What’s Included 3
Overview 4
Setup 5
Standard Wi-Fi Setup - Steps 1-4 6
Standard Wi-Fi Setup - Steps 5-6 7
Standard Wi-Fi Setup - Steps 7-9 8
Wi-Fi Protected Setup (WPS) 9
Naming a PR1 Receiver 10
Wi-Fi 11
Wi-Fi - Fine Tuning Your System 12
Wi-Fi - Static IP Conguration 13
Bluetooth 14
Line Out 15
Settings 16
Factory Reset 17
Troubleshooting 18
Table of Contents
Safety Information - Warnings and Cautions 1
Safety Information - Warnings and Cautions
Common sense warnings about liquids, re, heat, and
small objects:
• Do not install near any heat sources, such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
• To reduce the risk of re or electric shock, do not expose
this product to rain or moisture. The product should not be
exposed to dripping or splashing.
• Do not let objects or liquids enter the product as they
may touch dangerous voltage points or short-out parts that
could result in a re or electric shock.
• Clean only with a dry cloth. Unplug this product from the
wall outlet before cleaning.
• Do not place any open ame sources, such as lighted
candles, on or near the product.
• Do not expose the product to excessive heat, including
direct sunlight or re and storage or use inside cars in
hot weather, where it can be exposed to temperatures in
excess of 140°F (60°C). Doing so may cause the power
supply to generate heat, rupture, or ignite. Using the
product in this manner may result in a loss of performance
and shortened life expectancy.
Things not to do with your power supply:
• This product is intended to be used only with the power
supply provided.
• The power supply must be used indoors only. It is neither
designed nor tested for use outdoors, in recreational
vehicles, or on boats.
• Do not step on, throw, or drop the product or power
supply or expose them to a strong shock.
• Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
• Unplug this apparatus during lightning storms to prevent
damage to this product.
• To prevent risk of re or electric shock, avoid overloading
wall outlets, extension cords, or integral convenience
receptacles.
Leave it to the professionals:
• Make no modications to the product or accessories.
Unauthorized alterations may compromise safety,
regulatory compliance, system performance, and will void
the warranty.
• Refer all servicing to qualied service personnel. Servicing
is required when the product has been damaged in any
way: such as power supply cord or plug is damaged; liquid
has been spilled or objects have fallen into the product; the
product has been exposed to rain or moisture, does not
operate normally, or has been dropped – Do not attempt to
service this product yourself. Opening or removing covers
may expose you to dangerous voltages or other hazards.
If any of these have occurred please call Phorus to be
referred to an authorized service center near you.
The importance of this manual:
• Keep these instructions for future reference.
• Heed all warnings in this owner’s manual.
System Requirements 2
Here’s what you’ll need to connect your PR1
Receiver to your router:
1. An Android phone or tablet with at least
version 2.2 of the Android Operating System.
2. A Wi-Fi access point or router broadcasting
with 802.11g/n.*
3. The password for your wireless network.
System Requirements
Hide Password
********
Android 2.2 (or greater)
802.11g/n
Network Password
*An 802.11b router may be used, but it will effectively
stream to only one Play-Fi device.
What’s Included 3
Thank you for purchasing a PR1 Receiver!
You’re about to enjoy an unparalleled, rich audio
experience directly from your Android phone
or tablet. Your system includes the following
components.
• PR1 Receiver
• USB-to-Micro USB
• 3.5mm Aux Cable
• Y-Split Audio Cable
• Power Adapter
• Quick Start Guide
What’s Included
Overview 4
This is your PR1 Receiver. It’s going to be a big
part of your life, so let’s get you introduced.
Front
Power Button
Volume Up Button
Volume Down Button
Mute: Press both Volume Up and Down
Bluetooth Setup Button
Wi-Fi Setup Button
Back
Reset Button
Power Port
Factory Port (do not use)
USB Port (for Android device charging)
Line Out
Overview
Setup 5
The PR1 Receiver streams music over your
existing Wi-Fi network. One great feature of
the PR1 Receiver is that it’s really simple to set
up. There are two methods for connecting the
Receiver to your home network. You can perform
the Standard Wi-Fi Setup or WPS. Standard Wi-
Fi Setup lets you set up multiple Play-Fi Devices
(Speakers and/or Receivers) at once. WPS is
very easy to perform, but only lets you set up one
PR1 Receiver at a time.
We’ll learn about the Standard Wi-Fi Setup rst,
since not every router is capable of WPS.
Setup
Setup 6
Before starting, make sure the system
requirements are met and that you have all the
components from the What’s Included section.
1. For best results place your PR1 Receiver(s)
near your router. You may move Receiver(s) after
setup is complete.
2. Plug-in your PR1 Receiver(s). Your Receiver
will automatically power on. The Wi-Fi light will
blink quickly while the Receiver is starting up.
3. Wait until the white Wi-Fi light goes from a fast
blink to a slow pulse. When it’s pulsing it is in
Wi-Fi Setup Mode and broadcasting to the world,
“I’m looking for Android devices!”
4. Connect your Android phone or tablet to the
same Wi-Fi network that you want to connect
your PR1 Receiver(s). Download and install the
free Play-Fi App from the Google Play Store or
the Amazon App Store.
- Continued on next page
Standard Wi-Fi Setup - Steps 1-4
Setup 7
5. Launch the Play-Fi App and it will detect any
PR1 Receivers in Standard Wi-Fi Setup Mode.
6. The Play-Fi App will ask you to enter your
Wi-Fi network’s password (if required). After
connecting, your PR1 Receiver may perform a
software update. This may take several minutes.
Do not unplug your Receiver, turn off your
Android device, or leave the network during the
update.
- Continued on next page
Standard Wi-Fi Setup - Steps 5-6
Manually Enabling the Receiver’s Wi-Fi Setup Mode
If this is not your rst time setting up, if you’re in a new
location, or if you want to change from one network
to another, hold down the Wi-Fi button on the PR1
Receiver for 8 seconds. You will hear one chime and
then a second chime. When you hear the second
chime release the button. The Wi-Fi light will begin
pulsing indicating that Wi-Fi Setup Mode is active.
Alternative Network
If you want to set up a PR1 Receiver to connect to a
network other than the one you’re currently connected
to, press the Alternative Network button on the Enter
Network Password screen.
Setup 8
7. The Play-Fi App will ask you to name your
Receiver. There are several names to choose
from or create your own by choosing Custom
Name at the end of the name list.
8. If you set up your Receiver near your router
now is the time to power it off, move it to where
you want to listen, and power it back on.
9. When you are done simply select the music
you want to play in the Play-Fi application on
your Android device.
Please visit the following website for help with
setup or any other issues you may have.
http://support.phorus.com
Standard Wi-Fi Setup - Steps 7-9
Setting Up PR1 Receivers After Launching the App
The Play-Fi App only looks for devices in Standard Wi-Fi
Setup Mode when it is launched. To detect a Play-Fi
device after launching the app, go to the Home screen,
select Settings and then Add Play-Fi Device.
