Philips QT4085 Manual de usuario

Vacuum Trimmer

QT4085

ENGLISH 6

DEUTSCH 14

FRANÇAIS 23

NEDERLANDS 32

ESPAÑOL 40

ITALIANO 49

PORTUGUÊS 57

NORSK 66

SVENSKA 74

SUOMI 82

DANSK 90

 98

TÜRKÇE 107

QT4085

Introduction

Dear customer, you have made the right choice!

Your new maintenance-free Philips vacuum beard trimmer combines

innovative technology and outstanding comfort of use.

The integrated vacuum mechanism absorbs cut-off hairs during use and

guarantees a clean washbasin after use.

The contour-following comb attachment, the self-sharpening cutting unit

and the adjustment ring for selecting hair lengths of 1.5 to 18mm

ensure excellent cutting results and time-saving operation.The high-

quality precision trimmer guarantees a precise and defined cut and the

ergonomic shape of the appliance allows pleasant and comfortable

handling.

Your new Philips vacuum beard trimmer is excellently suited for cutting

and contouring your beard and sideburns.

General description (fig. 1)

AComb attachment

BDetachable cutting unit

CFlexible hair guide

DHair-collection chamber & filter

EAdjustment ring (Precision Zoom Lock`)

FTurbo button

GOn/off button

HGreen charging light with battery-full indication

IRed battery-low light

JSocket for appliance plug

KPrecision trimmer

LPowerplug (2.5V/1500mA)

MCleaning brush

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Keep the appliance and the powerplug dry!

ENGLISH6

◗Check if the voltage indicated on the powerplug corresponds to

the local mains voltage before you connect the appliance.

◗Only use the powerplug supplied.

◗Keep the appliance out of the reach of children.

◗Charge, use and store the appliance at a temperature between

15cC and 35cC.

◗This appliance is only designed for trimming the human beard.

Do not use the appliance for any other purpose.

◗Do not use the appliance if the cutting unit is damaged or

broken, as this may cause injury.

◗If the powerplug is damaged, always have it replaced by one of the

original type in order to avoid a hazard.

◗If the appliance is subjected to a major change in temperature,

pressure or humidity, let the appliance acclimatise for 30 minutes

before you use it.

Charging

Charge the appliance fully before using it for the first time or after a

long period of disuse.

Make sure the appliance is switched off before you start charging it.

Charging takes about 70 minutes if the appliance is completely empty.

1Insert the appliance plug into the appliance and put the

powerplug in the wall socket.

Battery indications

◗The green light burns continuously during fast charging (fig. 2).

◗The green light starts blinking when the battery is full (fig. 3).

◗If the red light blinks when you switch the appliance off after

cordless use, the battery is low and needs to be charged (fig. 4).

◗If the red light blinks but the motor does not start running when

you press the on/off button, the battery is empty and needs to be

charged.

ENGLISH 7

Preparing for use

Always comb your beard or moustache with a fine comb before you

start trimming.

Using the appliance

Corded trimming

Do not run the appliance from the mains when the battery is fully

charged.

BIf the battery is low, you can also use the appliance from the mains:

1Switch the trimmer off, connect it to the mains and wait a few

seconds before switching it on.

2If the battery is completely empty, wait a few minutes before

switching the appliance on.

Turbo function

◗You can use the turbo function for greater suction power and

increased cutting speed.

1Switch the appliance on (fig. 5).

2Press the turbo button (fig. 6).

When you switch the appliance off, the turbo function will automatically

be deactivated.

Absorbing cut hairs

The suction system is activated automatically as soon as you switch the

appliance on. It absorbs cut hairs during every kind of use, i.e. trimming

with and without comb attachment and contouring.The flexible hair

guide follows the contours of the face and directs cut hairs towards the

nozzle of the vacuum mechanism.

We advise you to empty the hair-collection chamber after each

trimming session.When trimming long, dense beards it may also be

ENGLISH8

necessary to empty the hair-collection chamber during the trimming

session in order to maintain optimal suction performance (see chapter

'Cleaning', section 'Hair-collection chamber').

BTo ensure optimal functioning of the vacuum system, do not cut off

more than approx. 7mm of your overall beard length at a time. If you

want to cut your beard shorter, repeat the process one or more times.

Trimming with comb attachment

1Turn the adjustment ring (Precision Zoom Lock`) to the desired

hair length setting (see table) (fig. 7).

◗The setting will appear in the window below the adjustment ring

(Precision Zoom Lock`).

If you are trimming for the first time, start with the maximum hair

length setting (9).

2Switch the appliance on (fig. 5).

◗During trimming, you can use the turbo function for extra

suction power (fig. 6).

ENGLISH 9

Resulting hair length

1.5 mm

2.5 mm

4 mm

5.5 mm

7.5 mm

9.5 mm

12 mm

15 mm

18 mm

Setting

3To trim in the most effective way, move the trimmer against the

direction of hair growth. Do not move the trimmer too fast.

Make smooth and gentle movements and make sure the surface

of the comb attachment always stays in contact with the skin

(fig. 8).

4Switch the appliance off.

Trimming at the unique 'stubble look' setting

◗Use the trimmer with the comb attachment set to hair length

setting 1.This allows you to create a 'stubble look' (fig. 9).

Trimming without comb attachment

Use the trimmer without comb attachment to trim full beards and

single hairs.

1Remove the comb attachment (fig. 10).

BNever pull at the flexible top of the comb attachment.Always pull at

the bottom part.

2Make well-controlled movements and touch the hair lightly with

the trimmer.

Shaping with the precision trimmer

You can use the precision trimmer to shape your moustache and

sideburns, to define contours and to cut single hairs.

1Remove the comb attachment (fig. 10).

BNever pull at the flexible top of the comb attachment.Always pull at

the bottom part.

2Remove the cutting unit (fig. 11).

3Attach the precision trimmer (fig. 12).

4When you are using the precision trimmer, hold the appliance in

such a way that the trimmer is pointing upwards (fig. 13).

ENGLISH10
