Philips D215 Hoja de información del producto

D210

D215

www.philips.com/welcome

Short user manual

05.en

Important safety

instructions

Warning

•The Electrical network is classified as hazardous.

The only way to power down the charger is to

unplug the power supply from the electrical outlet.

Ensure that the electrical outlet is always easily

accessible.

•Refer to safety information before using the

product.

•This product complies with European R&TTE

directive 1999/5/EC.

•Use only the power supply listed in the user

instructions.

•Use only the batteries listed in the user instructions.

•Do not allow the product to come into contact

with liquids.

•Risk of explosion if battery is replaced by an

incorrect type.

•Dispose of used batteries according to the

instructions.

•When the handset rings or when the handsfree is

activated, keep the handset away from your ear to

avoid hearing damage.

Display icons

It displays the connection between the handset

and the base.The more bars are shown, the

better the signal strength is.

It remains steadily on when browsing incoming

calls in the call log.

It indicates an outgoing call in the redial list.

Itasheswhenthereisanewmissedcallor

when browsing new missed calls. It remains

steadily on when browsing the missed calls in

call log that are already read.

Itasheswhenreceivingincomingcall.Itremains

steadily on during a call.

The speaker is on.

The ringer is off.

D215only:answeringmachine:itasheswhen

there is a new message or when the memory is

full. It remains steadily on when the telephone

answering machine is turned on.

Voicemessagesindicator:ashesfornew

messages, is steady for reviewed messages.

* This is network dependent

It is displayed when you scroll up/down a list or

increase and decrease the volume.

There are more digits on the right. Press to

read.

ECO+

The ECO+ mode is activated.

1Overview

In call

Enter the option menu.

Access the redial list.

Adjust the volume.

Recall (network dependent).

End calls.

Enter a pause (press and hold).

Turn the speaker on/off.

Mute/unmute the microphone.

In menu

Conrm/Select/Entertheoptionmenu.

Cancel / back

Up / down

Exit menu.

Standby

Access the main menu.

Access the redial list.

Phonebook

Call log

Make and receive calls.

Switch the handset on/off (press and hold).

Make intercom call (press and hold).

Lock/unlock the keypad (press and hold).

Make and receive calls through the speaker.

/ D215 only:

Listen to new message from the answer

machine. / Access the answer machine menu.

In text input

Delete text.

Enter a space.

Switch upper/lower case.

Microphone

Earpiece

Loudspeaker

(back side)

/ (D215)

(D210)

Display icons

D215D210

Find

handset

Loudspeaker

(back side)

Find

handset

2Connect

Multi-handset version only.

1 2 3

1 2

3Get started

Congure your phone Charge your phone

Charge 8 hours

1 The batteries are pre-installed in the handset. Pull the

battery tape off from the battery door before charging.

2 Whenusingyourphoneforthersttime,youseea

welcome message (country dependent).

3 Set the country and language if prompted.

4 Set the date and time.

•If the time is in 12-hour format, press / to select

[am] or [pm] (country dependent).

> 70%

40% - 70%

10% - 40%

< 10%

Flashing: low battery

Scrolling: charging in progress

Phonebook

Add record

1 Press .

2 Select [Phonebook] > [Add new].

3 Follow on-screen instructions.

Call from the phonebook

1 Press .

2 Select a record and press .

Direct access memory

You have 2 direct access memories (Keys 1 and 2).

To dial the saved phone number automatically, press

and hold on the keys in standby mode.

Depending on your country, keys 1 and 2 are

preset to the voice mail number and information

service number of your service provider respectively.

(network dependent).

Call log

Call from the call log

1 Press .

2 Select a record and press .

View record

Press > > [View].

Save record

1 Press > > [Save number].

2 Follow on-screen instructions.

Delete record

1 Press > > [Delete].

2 Follow on-screen instructions.

Redial list

Call from the redial list

1 Press .

2 Select a record and press .

Save record

1 Press > > [Save number].

2 Follow on-screen instructions.

Delete record

1 Press > > [Delete].

2 Follow on-screen instructions.

Telephone answering machine

(for D215 only)

Record an announcement

1 Press > [Answ. Machine] >

[Announcement].

2 Follow on-screen instructions.

Listen to the incoming messages

Press > [Answ. Machine] > [Play].

Delete an incoming messages

1 When you listen to the message, press to

enter the options menu.

2 Select [Delete], then press toconrm.

You can register additional handsets to the base

station.

1 Press .

2 Select [Services] > [Register], then press

toconrm.

3 Press and hold on the base station for 5

seconds.

4 Enter the system PIN/passcode (0000).

5 Press toconrmthePIN/passcode.

» Registration is complete in less than 2 minutes.

Restore default settings

You can reset your phone settings to the original

factory settings.

1 Press .

2 Select [Services] > [Reset], then press to

conrm.

3 Follow on-screen instructions.

Note

•You may recall the original PIN/passcode by

following this procedure.

4Enjoy

Technical data

Battery

•Philips: 2 x AAA NiMH 1.2 V Rechargeable

550 mAh batteries

Use only the supplied batteries.

Adapter

Base and charger:

Meic:

MN-A102-U130

Tenpao:

S003IB0600040

Input: 100-240 V~

50/60 Hz 200 mA

100-240 V~

50/60 Hz 150 mA

Output: 6 V 400 mA 6 V 400 mA

Phonebook with 50 entries

Call log with 20 entries

Talk time: 16 hours

Standby time: 180 hours

Note

•YoucaninstallaDSL(digitalsubscriberline)lterto

prevent noise and caller ID problems caused by the

DSL interference.

•YoucanndtheDeclarationofConformityon

www.p4c.philips.com.

No signal bar is displayed on the screen.

•The handset is out of range. Move it closer to the

base station.

•If the handset displays [Unregistered], register

your handset (see the section on “Register

additional handsets”).

If I fail to pair (register) the additional handsets to

the base station, what do I do?

Your base memory is full. Access > [Services]

> [Unregister] to unregister the unused handsets

and try again.

My handset is in searching status, what do I do?

•Make sure that the base station has power supply.

•Register the handset to the base station.

•Move the handset closer to the base station.

I cannot change the settings of my voice mail, what

do I do?

The voice mail service is managed by your service

provider but not the phone itself. Contact your

service provider to change the settings.

No display

•Make sure the batteries are charged.

•Make sure there are power and phone

connections.

The handset on the charger does not charge.

•Make sure the batteries are inserted correctly.

•Make sure the handset is placed properly on the

charger.The battery icon animates when charging.

•Make sure the docking tone setting is turned on.

When the handset is placed correctly on the

charger, you can hear a docking tone.

•The charging contacts are dirty. Disconnect the

powersupplyrstandcleanthecontactswitha

damp cloth.

•Batteries are defective. Purchase new ones with

thesamespecications.

Bad audio (crackles, echo, etc.)

•The handset is nearly out of range. Move it closer

to the base station.

•The phone receives interference from the nearby

electrical appliances. Move the base station away

from them.

•The phone is at a location with thick walls. Move

the base away from them.

The handset does not ring.

Make sure the handset ringtone is turned on.

The caller ID does not display.

•The service is not activated. Check with your

service provider.

•The caller’s information is withheld or unavailable.

Frequently asked questions

www.philips.com/support

To access the user instructions online, use the

reference model number written on the product

label at the bottom of the base station.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product is

covered by the European Directive 2002/96/EC.

2014 © WOOX Innovations Limited.

Philips and the Philips’ Shield Emblem are

registered trademarks of Koninklijke Philips N.V.

and are used by WOOX Innovations Limited

under license from Koninklijke Philips N.V.

UMS_D210/215

63 90_EN_V1.0

WK14242

0168
